Exploded View & Miscellaneous Parts
No.
VXSTD P/N
➀
U44104002
TAPTITE SCREW M2X4NI
➁
U9900180
TAPTITE SCREW 2X5SUS(O-RING)
➂
U9900179
TAPTITE SCREW 2X22SUS(O-RING)
➃
U9900181
TAPTITE SCREW 2X3.5(CAP)
Non-designated parts are available only as part of a
designated assembly.
RA0467600 (Lot 1 ~ 23)
RA046760A (Lot 24 ~)
O RING
Description
Qty.
18
G6090164
LCD
RA0646600
LIGHT GUIDE(LCD)
RA0646800
INTER CONNECTOR
RF Unit
RA0646000
EXT CAP
RA008890A
➃
O RING
RA0646400
KNOB B
RA0646300
KNOB A
RA0577900
KNOB SCREW
RA0646100
CAP
RA0653700
WINDOW
4
2
1
➀
➀
➀
➀
➀ ➀
➀
➀
➀
➀
➀
➀
➀
➀
➀
➀
➁
➁
➂
RA0653600
➂
RING NUT
RA0645400 (Lot 1 ~ 43)
RA064540A (Lot 44 ~)
DOUBLE FACE TAPE
CP8159002 (DST:USA)
CP8159003 (DST:EXP)
CP8159004 (DST:EU)
CP8159005 (DST:AUS)
FRONT CASE ASSY
RA0646500
RUBBERKEY
RA0646700
REFLECTOR SHEET
CNTL Unit
➀
FR013010A
FPC CABLE
AF Unit
S6000414
GAP PAD TMS-M-5 6X6 (2 pcs)
RA0646200 (Lot 1 ~ 70)
RA1219000 (Lot 71 ~)
PACKING PAD
RA014030A
LATCH NAIL
➀
CP8155001
REAR CASE ASSY
➁
RA0645300
➁
HOLDER PTT
RA0645200
PTT KNOB
RA0140100
MASK SHEET
RA0141600
RUBBER PACKING
FNB-80LI
