Electrolux E30WD75EPS Specifications

E30WD75EPS professional series
30" Warmer Drawer Specifications
• Product Weight – 49 Lbs.
• Voltage Rating – 120V / 600W / 60 Hz / 5 Amps
• 60" electrical cable supplied.
• Single phase 3-wire, 120 Volt, 60 Hertz AC only
electrical supply with ground required.
• Drawer fully extended (including handle) – 21-9/16".
• Full base required, capable of supporting 100 Lbs.
• Base must be level and cabinet front must be
square.
• Warmer Drawer can be used alone, or in
combination with any Electrolux ICON
Combination Warmer Drawer /
Built-In Oven Specifications
• To support Wall Oven when using in combination
with Warmer Drawer, two 3"-wide planks must be
installed as a base, capable of supporting 200 Lbs.
Do NOT use full base, since planks are necessary
to allow for proper air displacement.
NOTE: Refer to Product Installation Guide for detailed
instructions on the web at electroluxusa.com.
250 Bobby Jones Expressway
USA
• •
1-877-4electrolux (1-877-435-3287) electroluxusa.com
•
5855 Terry Fox Way Mississauga, ON L5V 3E4
CANADA • •
1-800-668-4606
electroluxca.com
•
E30WD75EPS 04/06
Smooth-Glide ™
Warmer Drawer
Drawer slides in and out with ease,
extending completely and safely for
convenient access to prepared foods.
Stainless Steel Interior Design
Entire inner drawer cavity is constructed of
smooth and durable, seamless stainless
steel for easy cleanup.
Humidity Control
Allows adjustment of humidity levels to
ensure that foods taste as they should
™ Wall Oven.
even after reheating.
Flexible Temperature Control
The true measure of a successful meal is
the ability to serve all courses hot, fresh
and at the peak of perfection. With our
600-watt mounted heating element, this
warmer drawer enables you to do just that
with thermostatic controls that range from
150 to 260 degrees. The blue indicator
light displays on/off status for added
safety.
Half-Width Rack
Drawer features a convenient half-width
rack for small dishes and breads, also
providing loading flexibility to accommodate
a variety of prepared foods.
10 "
Augusta, GA 30907
© 2006 Electrolux Major Appliances, NA
30" WARMER DRAWER
Humidity Control
Element "ON" Blue Pilot Light
Stainless Steel Drawer Interior
Half-Width Rack
SPECIFICATIONS
Cutout Dimensions –
Height
Width
Depth
Interior Warmer Drawer Cavity –
Full-Extension
Height
Width
Depth
Drawer Fully Extended (Including Handle)
Voltage Rating
60" Electrical Cable
Product Weight
Shipping Weight
UPC (0-57112-)
NOTE: Always consult local and / or national electric codes. Refer to Product
Installation Guide for detailed installation instructions on the web at
electroluxusa.com.
30"
High standards of quality at Electrolux Major Appliances mean we are constantly working to improve
our products. We reserve the right to change specifications or discontinue models without notice.
Yes
Yes
Yes
Yes
8-3/8" min.
8-5/8" max.
28-1/2" min.
28-3/4" max.
24"
13-1/4"
33-5/8"
29-1/4"
21-7/16"
120 V/ 600 W /
60 Hz / 5 Amps
Included
49 Lbs.
63 Lbs.
08912-6
26"
23 1 / "
4
7 / "
8
10 "
Printed in the U.S.A.
