S3i Product & Service Manual
Index
Installation and Setup
Compatible Device & Service
Button layout & Status indication by LED
Connect your device to controller
Reset & Initializing to recover setup process
How to find compatible game information
Note and Useful tips
FQA in troubles in initial setup
Android GameHub Manual
Download & Installation
Feature Sets Overview
How to use utility feature
Windows Application Manual
Download and installation
Installation process
Registering Gamepad
Run windows utility application
Mapping Service Manual
Introduction, Download & Installation
Connection to phone, TV screen
How to setup mapping game
Play mapping games
How to edit by using menu including high-level setting
Installation and Setup
If any question, contact us https://shaks.channel.io/
SHAKS S2i/S3i/S5i/S5b supporting
of which is recognized as individual device by its corresponding host game device. For example,
when SHAKS is in android mode, it will connect to your android smartphone/tablet, it works like an
"android Gamepad". But, if you connect it to a windows PC, it does not work correctly (for example, haptic
no function), because SHAKS says "I am in android mode", but the PC can't hear it, although its Bluetooth
connection is made.
First, please note that S3i can be paired to one device with an exactly matched mode. It is auto re-pair to
the same device once paired, but If you wish to switch from one device to another, please delete
S3i Product & Service Manual
four (4)
modes, Android / Windows / iOS, and Mapping, each mode
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for SHAKS S2i
Summary of Contents for SHAKS S2i
- Page 1 “android Gamepad”. But, if you connect it to a windows PC, it does not work correctly (for example, haptic no function), because SHAKS says “I am in android mode”, but the PC can’t hear it, although its Bluetooth connection is made.
- Page 2 Stadia, X-cloud, Geforce, Luna. One step more, by our own SHAKS GameHub app, S3i let you to play AAA touch-gaming by console grade controller, name a few, Garena Free Fire, CoD, PUBG, Genshin Impact, Roblox, Slamdunk etc.
- Page 3 3 Step setup: In power-off status, press two keys simultaneously until booting. This setup is available from xxx 13 (Dec. 21, 2020) firmware. If you have older version, please upgrade it via SHAKS Gamehub app. See below how to do 3 step setup. 1. Select gamepad mode per your device in the table.
- Page 4 2. Change mode of gamepad by key or press “Hot Key* ” The default is Android mode. S3i remember the last selected mode until you change it. 3. Press the 'Select + Start' button for more than 3 seconds and find ‘SHAKS S3i xxxx ’ on the device & click to pair.
- Page 5 3. Bluetooth Pairing: Press [Select + Start] button simultaneously for 3 seconds. On your device, select “SHAKS S3i xxxx Win-MAC”. Once paired, the gamepad will remember and will reconnect automatically. Tips) - In case of Windows 10 or later, do not install any driver, already W10 has it. In case of Windows 7, please install “Xbox 360 driver”...
- Page 6 ; Play Call of Duty - In iPhone/iPad, COD is playable by S2i/S3i/S5i without any setting change. In the case of Android phone/tablet, two way is possible. : 1st, By using the “Touch-mapping” by ‘SHAKS GameHub" App. Please download this app from Google store, and refer to our manual.
- Page 7 - This was originally designed to be touch-only game, not supporting game controller. This is not something we can help you with. - For Android, you can play by using our mapping service in SHAKS GameHub app downloadable from Google Playstore.
- Page 8 2. Initializing the connection referring to this link 3. Go to your game setting menu, enable gamepad setting 4. Go to Shaks Windows app, do the key test 5. Check your BT dongle or power feeding 6. Go to BT setting and check BT on status : Mosue, Keyboard, Pen must be "On" connected.
-
Page 9: Download & Installation
The SHAKS Gamehub application is designed for a better gaming experience using SHAKS higher-end series S2i, S3x, and S5x, including the sniper, turbo, mouse setting, calibration of the analog stick, mapping feature, self-test, and FW remote update, etc. Also, it provides a compatible game list, its playing tips, manual, tutorials. - Page 10 SHAKS GameHub - Apps on Google Play Everyone Gaming Utility application to improve your gaming experience. Customizing your SHAKS gamepad keys up to your gaming style or your favorite game, even further your game console. Possible to convert touch into gamepad key control, "key- https://play.google.com/store/apps/details?id=com.aksys.shaksapp&pcampaignid=...
- Page 11 Installation and connection It shows the model name, ID, FW Version of the connected gamepad. If it needs to update to the latest FW or any trouble in connection, the below pop message appears. Any connection error Gamepad mode is changed but the phone connects it with the previous mode.
- Page 12 Feature Sets Overview You can find useful information to use gamepad series ; All Game List Supported by SHAKS Android Compatible Game List Touch-Mapping Game List in Android Product, Application Manual Video Tutorial When you search game name in "compatible game ��...
- Page 13 Application setting Function key setting Set function key as per your gaming style. Reach the location of function key in each model. . ‘Option is used same meaning as function. Function off : Disable Function button Turbo Pressing the selected button longer. then turbo action is being activated.
- Page 14 Available button assignable to turbo: A, B, X, Y, LB(L1), RB(R1), LT(L2), RT(R2) By pressing the function button, make LED #2 on (turbo stand-by), then push the selected button for turbo action. Sniper When you want to control precisely L/R joystick, you can set sniper enabled.
- Page 15 - R stick: press the wheel button to click Camera activation key (available only on Android mode, no support in mapping mode) When the camera application is running over the phone, click this function key to do the camera capture feature. No in the camera app, it works volume up key.
- Page 16 3. Calculating center value, waiting until complete. 4. Move the stick to each direction and wait until completed. Up→ down→ left→ right direction by turn. 5. All steps end, check its position point S3i Product & Service Manual...
- Page 17 [Calibration of trigger (LT/RT or L2/R2) ]: If the trigger value is not O when it is idle status without moving, or if it is not reaching the max value when the triggered is fully pulled. 1. Start trigger calibration (LT/RT) 2.
- Page 18 Release the connection of Gamepad: Release the connection of gamepad with the Android device. Rename gamepad: Select one of pre-set names or put your own name on gamepad - Basic - Xbox Wireless Controller - Microsoft X-box 360 pad - Customize the name Once the name is changed, the connection will ��...
- Page 19 Firmware Update SHAKS keeps developing a new feature, please use this feature to get your gamepad up-to-date. If there is a new release, a pop-up guide appears. For safety updates and to protect the device, update �� allow only in case of power plug-in by cable to an external power source.
- Page 20 Alarm Set to receive alarm message or not Allow drawing over other apps When you using the mapping service, this allows icons to work over the game screen. Initializing all app setting value Log out: log out from your ID or enter into again with another ID Back to Contents Customer support...
- Page 21 Application version number and its note Goto Google store and check its status Visit our SHAKS homepage Back to Contents Windows Application Manual Download and installation Please click here to download. Unzip “SHAKS_Setup.zip” driver file You will find these files and folders inside after unzip the downloaded file. Please select the correct version x86 or x64.
-
Page 22: Installation Process
For Windows 8 or later versions, you can install the Xbox 360 Controller Driver through Windows Update. You may need a little time to install. Installation process If the previous 1.x version is already installed, uninstall will be prompted. Uninstall old version first and re-run setup command. - Page 23 S3i Product & Service Manual...
- Page 24 Set the gamepad in "Win-MAC mode" before pairing via Bluetooth. 1. Change mode and power on S2 series and S3 series: Turn on the power by pressing SHAKS logo button with pressing “Select” button. The SHAKS gamepad will remember last booting mode, you can re-connect "Win-MAC mode"...
- Page 25 This program supports up to 4 x SHAKS Gamepads (S2 and higher model only) A. If SHAKS is not paired, pair SHAKS Gamepad through Bluetooth or push SHAKS button to awaken it. B. App will detect connected SHAKS gamepad automatically.
- Page 26 If user clicks a gamepad icon, selected SHAKS Gamepad will vibrate for 3 sec. E. Click the “Apply” button when done to save settings. NOTE: The “O” button customization for Windows will only be available if S2 gamepad has 190005 FW version or higher.
- Page 27 “O” functions will be activated and deactivated by pressing “O” button on Gamepad. Virtual Mouse -- Only “Android” mode This feature only works on “D-Input” mode. If you press the “O” button, function LED will be on and gamepad will simulate the mouse. Left stick: Move mouse cursor around Right stick up/down: Mouse wheel scroll A button: Mouse Left button click...
- Page 28 [ Calibration ] Left Stick, Right Stick: If there is problem on left and right stick's minimum and maximum values, correct them using calibration.. 1. Select the Left or Right stick button and click the start button. 2. Move the stick to the leftmost and release it. It will go back to the center. 3.
- Page 29 1.Select the Left or Right trigger button and click the start button. 2.Pull the trigger button and release it slowly. 3.Follow the calibration process step by step. Minimum value > Maximum value 4. All calibration processes are finished, click the "OK" button to save the calibrated value. F.
- Page 30 G. If a new Gamepad FW is available, an upgrade icon will be enabled. If you want to upgrade the gamepad, plugin USB cable to charge the battery. If the gamepad is not charging, you will see below the message box, canceling the update process. H.
- Page 31 SHAKS Mapping Services offered by SHAKS Gamepad is to open the new way to play game controller over the mobile touch-only game more comfortably and efficiently.
- Page 32 The Mapping Service is being provided by SHAKS GameHub Application, applicable for SHAKS higher range of series, S2i, S3i, and higher version. This app is not working with other branded products. We recommend reading this manual, and you may need to update the gamepad firmware via SHAK GameHub App.
- Page 33 Solution 2: if above 1 is not workable, do 1. Go to smartphone Bluetooth setting 2. Search gamepad paired in the list 3. Delete its connection log 4. Close the setting menu 5. After a few seconds, go back to Bluetooth setting screen, confirm its deletion 6.
- Page 34 Add games into the registered list You can add game one of 3 way below Search Game: Search game downloaded/installed in your phone, and find its mapping data from SHAKS server. Call from uploaded data: Register the game using mapping data by download from SHAKS server...
- Page 35 If the game is already installed, you can download mapping data directly. If not installed, the below message pops up. or you can download mapping data only, you can click SHAKS logo icon. Search by SNS code 1. Search mapping data by SNS code shared. input the code and search S3i Product &...
- Page 36 2. Download mapping data If the game is already installed, you can download mapping data directly. If not installed, the below message pops up. or you can download mapping data only, you can click SHAKS logo icon. Back to Contents Play mapping games With mapping data, a screen pops up.
- Page 37 SHAKS icon pops up to allow mapping edit option over the gameplay screen During gameplay, it is possible to edit the mapping as per the game scene or play style Go to see Mapping Edit section for detail Upload your file into cloud server...
- Page 38 Back to Contents How to edit by using menu including high-level setting Going into edit mode By touch SHAKS icon, the edit menu bar appears on the screen. total 16 buttons can be mapped in matching with gamepad key/button - A, B, X, Y, LB/RB (L1/R1 bumper), LT/RT (L2/R2 trigger)
- Page 39 going to the initial value - Button works On or Off) toggle type - Joystick action by L-stick: While pressing one button, if you move L-stick, it works like a joystick from the point of that button. This is useful to simulate drug-like action. 다...
- Page 40 Please edit it over "tutorial (training) mode" or a more safe scene. Load Screenshot. Contact us Web page: www.shaksgame.com �� Talk with us now via chat ℹ Instagram �� Facebook �� SHAKS Home https://www.amazon.com/stores/SHAKS/page/F4A51944-C2CD-4F89-BC03-5 A2419161EF1?ref_=ast_bln Back to Contents S3i Product & Service Manual...
