NRS Relief DomeHome Quick Start Manual

UNHCR standard – self-standing family tent
Ideal to assemble
this tent.
70
75
193
inner 183
Packing list
A 1x Outer tent (guy lines pre-installed)
1x
B Inner tent (pre-installed)
C 1x Inner partition (pre-stitched in inner tent)
D 2x Grey poles (crossing arches)
1x Orange
E pole (middle arches)
F 2x Blue poles (front and back arch)
G 1x Green pole (ridge pole)
H 1x Shade cover (guy lines pre-attached)
14x
I J-pegs 30 cm length
J 6x T-pegs 40 cm length
K 1x Repair kit
1x
L Hammer
M 1x Assembly Manual
DomeHome
Technical drawing
(All measurements in cm)
Front view
233
inner 225
100
430
Top view
430
193
430
Side view
550
550
1
Place the package at the exact place where the tent will
be erected.
3
Rear view
Firmly join the colour-coded sections together.
100
430
Side view
5
233
430
Plane view
Push the tent upwards from inside at the middle while
grey poles
inserting
the base plates.
550
1 2
2
Min. 6 m
(i) Unpack the package and take aside the bags with
poles and accessories. (ii) Remove the bag.
(iii) Unroll the bundle.
4
D, E, F & G
Grey pole
Orange pole
Green pole
Slide the colour-coded poles through their
respective sleeves.
6
E
D
Slide the
orange poles
and into the tips of sleeves and insert the tips of the poles into the base
plates.
Watch the assembly video online:
nrsrelief.com/products/domehome/
PEGS
POLES
i
ACCESSORIES
ii
iii
A
E
G
- cross pole
- middle pole
- ridge pole D
F
blue front and back arches through the
