Child Craft Kieran F03209 Manual

Child Craft Kieran F03209 Manual

Double dresser

Advertisement

Available languages

Available languages

Quick Links

This page is for printing and document
DO NOT scale the artwork for printing. Each page
has been scaled for proper scaling of parts.
Page 1 will be the cover page and rst page printed
after this speci cation page. Any blank pages needed will
be placed at the end of this booklet.
printer to arrange booklet pages in proper
Revisions:
A: Initial release. July/23/2020. WD
B: Changed quantity of Hardware "I" from 6 to 5. Added part 23101838. Step 5 letter change from "I"
to "V". 10/02/2020. RDA
formating speci cations only.
THIS PAGE DOES NOT PRINT.
sequence according to page number.
210 mm

Advertisement

loading
Need help?

Need help?

Do you have a question about the Kieran F03209 and is the answer not in the manual?

Questions and answers

Nicole DuPriest
May 23, 2025

These drawer locks will not stop locking making it impossible to open and close them freely. Is there a way to remove these locks or permanently disable them? They are making the drawers unusable

2 comments:
Mr. Anderson
May 25, 2025

To remove the drawers on the Child Craft Kieran F03209, follow these steps:

1. Fully extend the slide sections mounted on the cabinet.
2. Push the drawers in and out as needed to properly set the slides.
3. Once aligned, the drawers can be removed as shown in the section labeled "DRAWER REMOVAL."

There is no mention of specific drawer locks in the provided context. If the drawers are not moving, they may just need to be realigned with the slides. No disabling of locks is described or required.

This answer is automatically generated

Nicole DuPriest
May 27, 2025

@Mr. Anderson The directions literally say there are child locks on the drawers and tells you how to unlock them one by one but they keep re-locking each time we close each individual drawer. Just not practical

Nicole DuPriest
May 18, 2025

I didn’t put the drawers in the right order and now cannot get any of the drawers to make them all fit. Please help!!! I have moved the toggles and everything and it says just to pull out the drawer and nothing happens. I’m afraid I’m going to break it!

1 comments:
Mr. Anderson
May 23, 2025

To properly rearrange the drawers for the Child Craft Kieran F03209 and ensure they fit correctly:

1. Fully extend the slide sections mounted on the cabinet.
2. Mount the slide sections to the drawer.
3. Insert the drawer and push it in and out a few times to properly set the slides.

This process helps align the slides for smooth operation.

This answer is automatically generated

Summary of Contents for Child Craft Kieran F03209

  • Page 1 This page is for printing and document formating speci cations only. THIS PAGE DOES NOT PRINT. 210 mm DO NOT scale the artwork for printing. Each page has been scaled for proper scaling of parts. Page 1 will be the cover page and rst page printed after this speci cation page.
  • Page 2 1-330-723-0599 (Monday through Friday, 9:00a.m.– 4:00 p.m. Eastern Time). Please have the model number and manufacture date available when you call or write us at: Child Craft, 5216 Portside Dr., Medina, OH. 44256 ASSEMBLY INSTRUCTIONS Record the information for your product here: •...
  • Page 3: Parts List

    PARTS LIST Part Number Quantity Part Description A. Drawer Front-A 23101501-A Drawer Front-B 23101501-B Drawer Front-C 23101501-C Drawer Front-D 23101501-D Drawer Front-E 23101501-E 23101501-F Drawer Front-F Top Drawer Side-Left 23101502 Drawer Side-Left 23101508 Drawer Side-Right 23101509 Drawer Back 23101510 Drawer Bottom 23101503 Drawer Support Rail 23101378...
  • Page 4 STEP 1 N x 1 Q x 1 R x 1 BB x 4 S x 1 BB x 4 AB20405_G4 STEP 2 M x 1 DD x 8 O x 1 AA x 8 AA x 8 CC x 12 DD x 8 CC x 12 AB20405_G5...
  • Page 5 STEP 3 P x 1 BB x 6 BB x 6 AB20405_G6 STEP 4 T x 1 U x 1 EE x 36 EE x 36 AB20405_G7...
  • Page 6 STEP 5 A x 1 G x 1 V x 1 FF x 4 AB20405_G8 STEP 6 J x 1 K x 1 L x 1 FF x 5 AB20405_G9...
  • Page 7 STEP 7 GG x 2 HH x 1 HH x 1 AB20405_G10 STEP 8 x 5 Note: Steps 8-10 will be repeated during the assembly B x 1 of Drawer Fronts C, D, E and F. H x 1 I x 1 FF x 4 AB20405_G11...
  • Page 8 STEP 9 x 5 J x 1 K x 1 L x 1 FF x 5 AB20405_G12 STEP 10 x 5 GG x 2 HH x 1 AB20405_G13...
  • Page 9: Drawer Removal

    STEP 11 These slide sections mounted on cabinet must be fully extended for installation This Slide section mounted to drawer Drawers may need to be pushed in and out to properly set slides AB20405_G14 DRAWER REMOVAL AB20405_G15...
  • Page 10 WARNING WARNING Serious or fatal crushing injuries can occur from furniture tipover. To help prevent tipover: • Install tipover restraint provided. • Place heaviest items in the lower drawers. • Do not set TVs or other heavy objects on the top of this product. •...
  • Page 11 GUIDE D’ASSEMBLAGE IMPORTANT: le conserver pour référence ultérieure. Lisez attentivement. Child Craft s’efforce de la plus haute qualité dans notre produits, mais de temps en temps une partie ou problème manquant peuvent se produire lors de l’assemblage. Si des pièces sont manquantes ou brisées ou vous avez Commode Double Assemblée...
  • Page 12: Liste Des Pièces

    LISTE DES PIÈCES Numéro de pièce Quantité Description des pièces A. Façade Du Tiroir-A 23101501-A Façade Du Tiroir-B 23101501-B Façade Du Tiroir-C 23101501-C Façade Du Tiroir-D 23101501-D Façade Du Tiroir-E 23101501-E 23101501-F Façade Du Tiroir-F Tiroir Supérieur Gauche 23101502 Panneau Gauche de Tiroir 23101508 Panneau Droit de Tiroir 23101509...
  • Page 13 ÉTAPE 1 N x 1 Q x 1 R x 1 BB x 4 S x 1 BB x 4 AB20405_G4 ÉTAPE 2 M x 1 DD x 8 O x 1 AA x 8 AA x 8 CC x 12 DD x 8 CC x 12 AB20405_G5...
  • Page 14 ÉTAPE 3 P x 1 BB x 6 BB x 6 AB20405_G6 ÉTAPE 4 T x 1 U x 1 EE x 36 EE x 36 AB20405_G7...
  • Page 15 ÉTAPE 5 A x 1 G x 1 V x 1 FF x 4 AB20405_G8 ÉTAPE 6 J x 1 K x 1 L x 1 FF x 5 AB20405_G9...
  • Page 16 ÉTAPE 7 GG x 2 HH x 1 AB20405_G10 ÉTAPE 8 x 5 Remarque: Les étapes 8 à 10 seront répétées pendant l'assemblage B x 1 des façades de tiroirs C, D, E et F. H x 1 I x 1 FF x 4 AB20405_G11...
  • Page 17 ÉTAPE 9 x 5 J x 1 K x 1 L x 1 FF x 5 AB20405_G12 ÉTAPE 10 x 5 GG x 2 HH x 1 AB20405_G13...
  • Page 18 ÉTAPE 11 Ces diapositives les sections montées sur l’armoire doivent être entièrement étendu pour l’installation Cette section Slide monté sur tiroir Les tiroirs peuvent avoir besoin être poussé dedans et dehors définir correctement les diapositives AB20405_G14 RETRAIT DU TIROIR AB20405_G15...
  • Page 19 WARNING AVERTISSEMENT Des blessures graves ou mortelles peuvent se produire lorsqu’un meuble se renverse. Pour éviter les renversements : • Installer retenue de renversement fourni. • Placez les articles les plus lourds dans les tiroirs du bas. • Ne placez pas de téléviseurs ou d’autres objets lourds sur le dessus de ce produit. •...
