IP Camera
User Manual
IP Camera User Manual
This user manual applies to the following types of products:
Add：11th Floor, A-06 Area, No.370, Chengyi Street, Jimei District, Xiamen City, Fujian Province, China.
Document Version
Series number
F-SC621
F-SC431
F-SC341
F-SC332
F-SC331
F-SC311
F-SC241
4G&5G IoT RTU
Tel：+86 592-5907276 Fax: +86 592-5912735
Web: en.four-faith.com
V1.1.0
Product types
Mini Dome Camera
Speed Dome Camera
SPro
Cellular Bullet Camera
Pro
Cellular Bullet Camera
Pro
Cellular Bullet Camera
Mini
Bullet Camera
Bullet Camera
Pages
30
Advertisement
Table of Contents
Related Manuals for Four-Faith F-SC341
Summary of Contents for Four-Faith F-SC341
- Page 1 IP Camera User Manual This user manual applies to the following types of products: Series number Product types F-SC621 Mini Dome Camera F-SC431 Speed Dome Camera F-SC341 SPro Cellular Bullet Camera F-SC332 Cellular Bullet Camera F-SC331 Cellular Bullet Camera F-SC311...
- Page 2 Date Version Remark Author 2019-05-01 V1.0.0 Initial Version Wayne 2020-12-01 V1.1.0 Add latest products and new Jonas features instruction Address: 11th Floor, A-06 Area, No.370, Chengyi Street, Jimei District, Xiamen City, Fujian Province, China. Website: en.four-faith.com Tel: +86-592-5907276 Fax: +86-592-5912735...
- Page 3 All contents in the files are protected by copyright law, and all copyrights are reserved by Xiamen Four-Faith Communication Technology Co., Ltd. Without written permission, all commercial use of the files from Four-Faith are forbidden, such as copy, distribute, reproduce the files, etc., but non-commercial purpose, downloaded or printed by individual (all files shall be not revised, and the copyright and other proprietorship notice shall be reserved) are welcome.
- Page 4 IP Camera User Manual Note: There may be differences between models of accessories and interfaces, actual products shall prevail. Address: 11th Floor, A-06 Area, No.370, Chengyi Street, Jimei District, Xiamen City, Fujian Province, China. Website: en.four-faith.com Tel: +86-592-5907276 Fax: +86-592-5912735...
-
Page 5: Table Of Contents
3.2.2 Network connection ................... 7 3.2.3 Access to devices ....................7 3.2.4 Device search and IP setting ................9 3.2.5 Device login ..................... 11 CHAPTER 4 MAIN FUNCTION ..............13 Interface ........................13 4.1.1 Ethernet ......................13 IP Camera en.four-faith.com... - Page 6 4.2.8 Alarm ........................ 23 4.2.9 Storage Configuration ..................23 4.2.10 Network Configuration ..................24 4.2.11 4G/5G Configuration ..................25 4.2.12 Cloud Platform Configuration................26 4.2.13 SMTP ....................... 29 4.2.14 Device Upgrade ....................30 Video Coding ......................30 IP Camera en.four-faith.com...
-
Page 7: Chapter 1 Brief Introduction Of Product
Chapter 1 Brief Introduction of Product 1.1 General Four-Faith IP Camera series provides a comprehensive range of security and surveillance solution to meet users’ requirement. The cameras can be set up in a network and controlled or managed locally and remotely. Users can use it as an independent monitoring camera or connect to an NVR to build a surveillance system. -
Page 8: Product Line
The Real Time Streaming Protocol (RTSP) is a network RTSP control protocol designed for use in entertainment and communications systems to control streaming media servers. Page 2 of 30 IP Camera en.four-faith.com... -
Page 9: Chapter 2 System
Master-Slave Frame Service Management & Video C/S Structure Service Audio & Video Production Production Video Image Diagram 2.1.1 IPC System Structure 2.1.2 IPC Cloud Management Structure 4G/5G Camera Router Diagram2.1.2 Cloud Management Structure Page 3 of 30 IP Camera en.four-faith.com... -
Page 10: Features
❖ UART Port: TTL@115200bps Or Expansion for RS485* * = Optional 2.2.4 Cloud Platform ❖ Remote web server device management cloud platform for user to do remote status monitoring, configuration and update, etc. Page 4 of 30 IP Camera en.four-faith.com... -
Page 11: Other Web Funtions
(Primary, Secondary and Tertiary stream. 2 ways 1080P, 1 way D1 30fps, using H264/H265/MJPEG) 2.3.1 Video Storage Support 1 way SD card scheduled video recording & image capture, multi-way SD card alarm recording & capture. Page 5 of 30 IP Camera en.four-faith.com... -
Page 12: Chapter 3 Operating Environment
3.2 Connection 3.2.1 Equipment power supply Four-Faith IP camera supports PoE power supply and DC 9-60V wide voltage power supply. Users can choose one of the power supply modes to power the equipment. The power supply and network interface can be seen at the end of the camera after the screws around the cover plate are removed. -
Page 13: Network Connection
In the case of a direct computer connection, it is necessary to set a fixed IP address for the computer first. The specific operation is as follows: 1. Open the Network Connections page of the computer and right-click the Ethernet and choose properties. Page 7 of 30 IP Camera en.four-faith.com... - Page 14 IP Camera User Manual 2. Modify IPv4. Page 8 of 30 IP Camera en.four-faith.com...
-
Page 15: Device Search And Ip Setting
At this time, customer needs to use search tools to search IPC device for configuration. Open Incisive Tools and click the search button. The tool will search all camera devices under the same LAN and list them together. Page 9 of 30 IP Camera en.four-faith.com... - Page 16 192.168.0.x, the IP of the camera should be changed to 192.168.0.x, and so on. In the search tool, the IP of the device can be directly modified in batches. The specific processes are as follows: Page 10 of 30 IP Camera en.four-faith.com...
-
Page 17: Device Login
1. Open IE browser (IE 8.0 or above) and enter the IP address of IPC. 2. Enter ID and password to login. Notice: 1. Initial account of standard version: admin; Password: xmsx1234. 2. The version before V1.0.0.5, password is ff2018. Page 11 of 30 IP Camera en.four-faith.com... - Page 18 4. After finish downloading, install the video plug-in. 5. After finish installing the video plug-in, refresh the IE. Users can check real-time video monitoring on IE and user can operate different functions of IPC on this web interface. Page 12 of 30 IP Camera en.four-faith.com...
-
Page 19: Chapter 4 Main Function
IPC can output TTL signal to trigger other action after received the alarm signal, such as control relay to send out alarm, or activate fire alarm system. Page 13 of 30 IP Camera en.four-faith.com... -
Page 20: External Relay Interface
The default login credential is printed on a tag on your camera. The login IP address is 192.168.1.100, username is admin, and password is ff2018 unless you have changed them before. Type in the address and user info, click login to enter the management portal. Page 14 of 30 IP Camera en.four-faith.com... -
Page 21: Configuration
4.2.3 Display Setting Support web video image adjustment, including Basic Settings, Day & Night Switch, OSD, Private Mask, ROI, etc. Page 15 of 30 IP Camera en.four-faith.com... -
Page 22: Video Setting
Quality, Time, Bit Rate, CBR/VBR Type, etc. 4.2.5 Real-time Video Real-time video is supported in IPC web interface and user can control the IPC remotely at the same time. Processes: 1. Login the IPC web interface. Page 16 of 30 IP Camera en.four-faith.com... - Page 23 After finish record the video or snapshot, the system will automatically pop up the local disk window of the recording video/snapshot so that users can view it at the same time. Page 17 of 30 IP Camera en.four-faith.com...
- Page 24 IP Camera User Manual 4. User can setting the record video storage path on the IPC web interface. Page 18 of 30 IP Camera en.four-faith.com...
- Page 25 IP Camera User Manual Buttons of image setting: Button Description Primary stream Secondary stream Window size Real size Full scream size Protocol setting Play Stop Snapshot Brightness Contrast Sharpness Noise reduction level Default Video recording Saturation Page 19 of 30 IP Camera en.four-faith.com...
- Page 26 IP Camera User Manual Buttons of IPC remote control: Button Description configuration Zoom in Zoom out Focus increase Focus reduce Iris increase Iris reduce Focus speed Lens initialization Auxiliary focus Auto iris Page 20 of 30 IP Camera en.four-faith.com...
-
Page 27: Video Playback
Processes: 1. Click the playback on the top of menu. 2. Select the date and time on the right side. 3. Click the play button to playback the video. Page 21 of 30 IP Camera en.four-faith.com... -
Page 28: Video Record Schedule
2. Select the storage option on the left side. 3. Choose record schedule on the top. 4. Enable the record schedule. 5. Choose the disk. 6. Select the recording day & time period and save. Page 22 of 30 IP Camera en.four-faith.com... -
Page 29: Alarm
The product supports various event alarm functions, by setting up some trigger conditions and the related actions to inform user to check and take action. 4.2.9 Storage Configuration The product support storage management, storage configuration, file search, scheduled recording, scheduled image capture, etc. Page 23 of 30 IP Camera en.four-faith.com... -
Page 30: Network Configuration
IP Camera User Manual 4.2.10 Network Configuration Page 24 of 30 IP Camera en.four-faith.com... -
Page 31: 5G Configuration
IPC Web interface and choose 4G/5G on the top of the menu. Enable the 4G/5G Notice: 1. Make sure the network state is connected, has an IP address and the signal value is above 15. 2. The network state is at least 4G or LTE. Page 25 of 30 IP Camera en.four-faith.com... -
Page 32: Cloud Platform Configuration
1, Make sure the server address and port are correct, customer could check with the technician. 2, Make sure that the device registration ID is the same as the ID newly adde d on the platform and that the capital and small letter must be the same. Page 26 of 30 IP Camera en.four-faith.com... - Page 33 IP Camera User Manual 2. Enter the cloud server address on the IE and login to the Four-Faith Could Platform. 3. Click the device and choose add option for adding the IPC device to the Four-Faith Cloud Platform. Page 27 of 30 IP Camera en.four-faith.com...
- Page 34 4. Paste the device registration ID that copy on the IPC Web interface. Select the organization, device type and total channel. Fill up the IPC information and click confirm. 5. Click the organization that select at the previous procedure on the left side and check the status. Page 28 of 30 IP Camera en.four-faith.com...
-
Page 35: Smtp
IP Camera User Manual 6. Click the ‘live view’ on the top of the menu. Choose organization on the right side and select the IPC to watch the live stream video on the Four-Faith Cloud Management Platform. 4.2.13 SMTP Page 29 of 30 IP Camera en.four-faith.com... -
Page 36: Device Upgrade
RTSP address and port, verify the username and password, user will be able to watch the real-time video streaming on web page, VLC or network video players. It also supports video streaming through cloud server or from APP. Contact your sales for cloud server license. Page 30 of 30 IP Camera en.four-faith.com...
