IP Camera
Document Version
Pages
User Manual
V1.1.1
30
IP Camera User Manual
This user manual applies to the following types of products:
Series number
Product types
F-SC621
Mini Dome Camera
F-SC431
Speed Dome Camera
F-SC332
Pro
Cellular Bullet Camera
4G Intelligent Vehicle HD Network
F-SC921
Bullet Camera
F-SC241
4G&5G IoT RTU
Bullet Camera
Add：11th Floor, A-06 Area, No.370, Chengyi Street, Jimei District, Xiamen City, Fujian Province, China.
Tel：+86 592-5907276 Fax: +86 592-5912735
Web: en.four-faith.com
Advertisement
Table of Contents
Related Manuals for Four-Faith F-SC621
Summary of Contents for Four-Faith F-SC621
- Page 1 Pages User Manual V1.1.1 IP Camera User Manual This user manual applies to the following types of products: Series number Product types F-SC621 Mini Dome Camera F-SC431 Speed Dome Camera F-SC332 Cellular Bullet Camera 4G Intelligent Vehicle HD Network F-SC921...
- Page 2 IP Camera User Manual Files Revised Record Date Version Remark Author 2019-05-01 V1.0.0 Initial Version Wayne 2020-12-01 V1.1.0 Add latest products and new Jonas features instruction 2021-6-22 V1.1.1 Update Product Line Graph Jonas Address: 11th Floor, A-06 Area, No.370, Chengyi Street, Jimei District, Xiamen City, Fujian Province, China.
- Page 3 All contents in the files are protected by copyright law, and all copyrights are reserved by Xiamen Four-Faith Communication Technology Co., Ltd. Without written permission, all commercial use of the files from Four-Faith are forbidden, such as copy, distribute, reproduce the files, etc., but non-commercial purpose, downloaded or printed by individual (all files shall be not revised, and the copyright and other proprietorship notice shall be reserved) are welcome.
- Page 4 IP Camera User Manual Note: There may be differences between models of accessories and interfaces, actual products shall prevail. Address: 11th Floor, A-06 Area, No.370, Chengyi Street, Jimei District, Xiamen City, Fujian Province, China. Website: www.fourfaith.com Tel: +86-592-5907276 Fax: +86-592-5912735...
-
Page 5: Table Of Contents
IP Camera User Manual CONTENTS CHAPTER 1 INTRODUCTION ..............1 General........................1 Product Line ......................2 Word Definition ......................2 CHAPTER 2 SYSTEM ................... 3 Structure & Diagram ....................3 2.1.1 IPC Working Principle Diagram ................. 3 2.1.2 IPC Cloud Management Structure ..............3 Features ........................ - Page 6 IP Camera User Manual 4.1.2 SD/TF Card ...................... 13 4.1.3 RS485 ......................13 4.1.4 Audio Interface ....................13 4.1.5 External I/O ...................... 13 4.1.6 External RELAY Interface ................14 4.1.7 ADC In ......................14 Local Web Management Portal ................14 4.2.1 Login ........................
-
Page 7: Chapter 1 Introduction
Chapter 1 Brief Introduction of Product 1.1 General Four-Faith IP Camera series provides a comprehensive range of security and surveillance solution to meet users’ requirement. The cameras can be set up in a network and controlled or managed locally and remotely. Users can use it as an independent monitoring camera or connect to an NVR to build a surveillance system. -
Page 8: Product Line
IP Camera User Manual 1.2 Product Line IP Camera F-SC621 F-SC431 F-SC241 F-SC921 F-SC332 1.3 Word Definition Word Explanation IP Camera Advanced Video Coding (MPEG-4 AVC) is a block-oriented H.264 motion-compensation-based video compression standard. High Efficiency Video Coding(HEVC), also known as H.265 and MPEG-H Part 2, is a video compression... -
Page 9: Chapter 2 System
IP Camera User Manual Chapter 2 System 2.1 Structure & Diagram 2.1.1 IPC Working Principle Diagram Front-end Access Audio Master-Slave Frame Service Management & Video C/S Structure Service Audio & Video Production Production Video Image Diagram 2.1.1 IPC System Structure 2.1.2 IPC Cloud Management Structure 4G/5G Camera Router... -
Page 10: Features
IP Camera User Manual 2.2 Features 2.2.1 Network ❖ Ethernet: 1*RJ45 10M/100M Ethernet Port ❖ Network Storage: NFS、CIFS/SMB ❖ Protocol: IPv4/IPv6, TCP, UDP, RTP, RTSP, RTCP, HTTP, HTTPS, DNS, DDNS, DHCP, FTP, NTP, SMTP 2.2.2 System ❖ Storage: Support Micro SD/SDHC/SDXC Card Local Storage, up to 128G ❖... -
Page 11: Other Web Funtions
IP Camera User Manual 2.2.5 Other Web Functions ❖ Local web server for device configuration, system maintenance, storage management, video monitoring, etc. ❖ Video Playback: Support video playback on web browser ❖ NTP: NTP with RTC, support timed reboot, scheduled power on or off ❖... -
Page 12: Chapter 3 Operating Environment
3.2 Connection 3.2.1 Equipment power supply Four-Faith IP camera supports PoE power supply and DC 9-60V wide voltage power supply. Users can choose one of the power supply modes to power the equipment. The power supply and network interface can be seen at the end of the camera after the screws around the cover plate are removed. -
Page 13: Network Connection
IP Camera User Manual 3.2.2 Network connection The camera can be connected to the computer for debugging and configuration in the following ways: 1. Direct computer connection 2. Connect through a switch or router 3.2.3 Access to devices Factory default configuration page address of IPC is http://192.168.1.100. - Page 14 IP Camera User Manual 2. Modify IPv4. Page 8 of 30 IP Camera www.fourfaith.com...
-
Page 15: Device Search And Ip Setting
IP Camera User Manual 3. Set the COMPUTER IP to any address in 192.168.1.x network segment. 4. Try to access the IP camera configuration web page http://192.168.1.100 from Internet Explorer. 3.2.4 Device search and IP setting When customer using a switch or router to connect, the device may not be able to access because the camera is in a different network segment from the computer and router. - Page 16 IP Camera User Manual Please confirm whether the IP address of the IP camera is in the same network segment as the computer. Otherwise, the configuration of the camera cannot be accessed. The following processes can use for obtain the network segment where the computer is located: Press Win+R on a Windows computer to open the CMD: Enter ipconfig in the command bar and press Enter:...
-
Page 17: Device Login
IP Camera User Manual For information about the Incisive Tools, please refer to the user manual of the Incisive Tools. 3.2.5 Device login 1. Open IE browser (IE 8.0 or above) and enter the IP address of IPC. 2. Enter ID and password to login. Notice: 1. - Page 18 IP Camera User Manual 3. The user needs to install the video plug-in when the user login to IE for the first time. Click and download the video player plug-in. 4. After finish downloading, install the video plug-in. 5. After finish installing the video plug-in, refresh the IE. Users can check real-time video monitoring on IE and user can operate different functions of IPC on this web interface.
-
Page 19: Chapter 4 Main Function
IP Camera User Manual Chapter 4 Main Function 4.1 Embedded System 4.1.1 Ethernet 1 x 10/100M auto-adaptive Ethernet port 4.1.2 SD/TF Card SD card auto mount directory: /mnt/mmc/, for video recording and image capture. The related web page will show the usage information, user can also check the files inside the SD card. -
Page 20: External Relay Interface
IP Camera User Manual 4.1.6 External RELAY Interface Support external RELAY OUT, can output signal to trigger other action. 4.1.7 ADC In Support external ADC collection, can be used for real-time analog data collection in some specific environment. For example, to check the temperature of a fishpond, the IPC can be connected to an external temperature sensor to collect the voltage analog data. -
Page 21: Configuration
IP Camera User Manual 4.2.2 Configuration Click the ‘Configuration’ tab on the top menu, user can manage the IPC from the following page. The side menu has list out all the items that user can configure. User can do detail configuration on the right side of the side menu after clicking the related item. -
Page 22: Video Setting
IP Camera User Manual 4.2.4 Video Setting Support video configuration, including Stream Type, Video Format, Resolution, Quality, Time, Bit Rate, CBR/VBR Type, etc. 4.2.5 Real-time Video Real-time video is supported in IPC web interface and user can control the IPC remotely at the same time. - Page 23 IP Camera User Manual 2. Click preview option on the top of the menu. At the lower right corner, user can remote control IPC such as play/stop live video, snapshots, video recording. Some cameras can support lens zoom, focus and other features. 3.
- Page 24 IP Camera User Manual 4. User can setting the record video storage path on the IPC web interface. Page 18 of 30 IP Camera www.fourfaith.com...
- Page 25 IP Camera User Manual Buttons of image setting: Button Description Primary stream Secondary stream Window size Real size Full scream size Protocol setting Play Stop Snapshot Brightness Contrast Sharpness Noise reduction level Default Video recording Saturation Page 19 of 30 IP Camera www.fourfaith.com...
- Page 26 IP Camera User Manual Buttons of IPC remote control: Button Description configuration Zoom in Zoom out Focus increase Focus reduce Iris increase Iris reduce Focus speed Lens initialization Auxiliary focus Auto iris Page 20 of 30 IP Camera www.fourfaith.com...
-
Page 27: Video Playback
IP Camera User Manual 4.2.6 Video Playback The IPC web interface supports video playback function. User can use the IPC web interface to play the recorded video from the IPC storage directly. You may require to install plug-ins before you use this function. Processes: 1. -
Page 28: Video Record Schedule
IP Camera User Manual 4.2.7 Video Record Schedule User can set the recording schedule so that the IP camera can record automatically at regular intervals. Processes: 1. Click the configuration on the top of menu. 2. Select the storage option on the left side. 3. -
Page 29: Alarm
IP Camera User Manual 4.2.8 Alarm The product supports various event alarm functions, by setting up some trigger conditions and the related actions to inform user to check and take action. 4.2.9 Storage Configuration The product support storage management, storage configuration, file search, scheduled recording, scheduled image capture, etc. -
Page 30: Network Configuration
IP Camera User Manual 4.2.10 Network Configuration Page 24 of 30 IP Camera www.fourfaith.com... -
Page 31: 5G Configuration
IP Camera User Manual 4.2.11 4G/5G Configuration 1. Insert the SIM card to the IPC. Click the ‘Network’ option on the left side of the IPC Web interface and choose 4G/5G on the top of the menu. Enable the 4G/5G Notice: 1. -
Page 32: Cloud Platform Configuration
IP Camera User Manual 4.2.12 Cloud Platform Configuration 1. Click the ‘Cloud’ on the top of the menu, enable it and save. Check the status and copy the device registration ID. (The cloud server address and server port may change by the customer’s local server and local port) Notice: 1, Make sure the server address and port are correct, customer could check with the technician. - Page 33 IP Camera User Manual 2. Enter the cloud server address on the IE and login to the Four-Faith Could Platform. 3. Click the device and choose add option for adding the IPC device to the Four-Faith Cloud Platform. Page 27 of 30 IP Camera www.fourfaith.com...
- Page 34 IP Camera User Manual 4. Paste the device registration ID that copy on the IPC Web interface. Select the organization, device type and total channel. Fill up the IPC information and click confirm. 5. Click the organization that select at the previous procedure on the left side and check the status.
-
Page 35: Smtp
IP Camera User Manual 6. Click the ‘live view’ on the top of the menu. Choose organization on the right side and select the IPC to watch the live stream video on the Four-Faith Cloud Management Platform. 4.2.13 SMTP Page 29 of 30 IP Camera www.fourfaith.com... -
Page 36: Device Upgrade
IP Camera User Manual 4.2.14 Device Upgrade 1. Remote Upgrade: Upload the new firmware through the cloud server API, click the upgrade button on the related web page. The cloud server will automatically send the firmware to the IPC to finish the upgrade. After the upgrade, it will return the result to the web server.
