SGS SAT105 Owner's Manual

Ratchet wrench

Advertisement

Quick Links

SAT105
RATCHET WRENCH
OWNER'S MANUAL
FOR YOUR SAFETY
PLEASE READ THESE INSTRUCTIONS CAREFULLY
AND RETAIN THEM FOR FUTURE USE.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SAT105 and is the answer not in the manual?

Questions and answers

Summary of Contents for SGS SAT105

  • Page 1 SAT105 RATCHET WRENCH OWNER’S MANUAL FOR YOUR SAFETY PLEASE READ THESE INSTRUCTIONS CAREFULLY AND RETAIN THEM FOR FUTURE USE.
  • Page 2: Specification

    SPECIFICATION TOOL MODEL SAT105 CAPACITY 1/2 IN. FREE SPEED 160 RPM MAX TORQUE 50 FT-LB / 69 Nm AVERAGE AIR CONSUMPTION 4 SCFM WORKING PRESSURE 90 PSI / 6.3 BAR AIR INLET 1/4 IN. AIR HOSE 3/8 IN. LENGTH x HEIGHT...
  • Page 3: Safety Instructions

    SAFETY INSTRUCTIONS DANGER RISK OF FIRE OR EXPLOSION WHAT COULD HAPPEN HOW TO PREVENT IT Abrasive tools such as sanders and grinders, Never operate tools near flammable sub- rotating tools such as drills and impact tools stances such as petrol, naphtha, cleaning such as nailers, staplers, wrenches, hammers solvents etc.
  • Page 4 RISK OF CUT OR BURNS WHAT COULD HAPPEN HOW TO PREVENT IT Tools that cut, shear, drill, staple, punch & Keep the working part of the tool away chisel are capable of causing serious injury. from hands and body. WWW.SGS-ENGINEERING.COM PAGE 4...
  • Page 5: Risk Of Injury

    Air tools can inadvertently propel fasteners Use only parts, fasteners and accessories or other materials in work area. recommended by SGS Engineering. Keep work area clean and free of clutter. Keep children and others away from tool while it is in operation.
  • Page 6: Risk Of Entanglement

    If damaged, have the tool serviced and repaired before use. Use only accessories identified by SGS Use of an accessory not intended for a Engineering as suitable for use with specific specific tool increases the risk of injury to tools.
  • Page 7 SAFETY GUIDELINES Make sure that the air compressor being used for the air tool operation sup- plies the correct output (CFM). Have the tool in the “off” position when connecting the tool to the air supply. Use normal 90 PSI (or ranging from 6.0 to 8.0kg) air pressure while running the tool.
  • Page 8: Care And Maintenance

    The tool should be lubricated daily (or before each use) with air tool oil (not in- cluded). Air tool oil is available from SGS Engineering. Do not use detergent oil. During continuous operation, the tool should be oiled every 1 to 2 hours. This may be done using an in-line oiler or manually.
  • Page 9 Figure 2 Figure 3 Figure 1 Figure 4 Figure 5 PAGE 9...
  • Page 10: Troubleshooting

    Oil tool and run until no water is evident. Oil tool again and run 1-2 seconds. Abnormal vibration Improper lubrication. Follow proper lubrication procedures and/or excessive in this manual. heat develops in the tool. WWW.SGS-ENGINEERING.COM PAGE 10...
  • Page 11: Parts Diagram

    PARTS DIAGRAM PAGE 11...
  • Page 12: Parts List

    PARTS LIST PART DESCRIPTION PART DESCRIPTION Screw nut Bolt O-ring Gear bracket Spring Lubricating sleeve O-ring Bias axle Bolt Bearing Air inlet Guiding sleeve Trigger bolt Ratchet holder Trigger F/R stem Main housing Spring Bearing Top sleeve Rear plate Spacer Bolt Ratchet bracket Rotor...
  • Page 13: Type Of Equipment

    SGS Engineering (UK) Ltd West Side Park Raynesway Derby, DE21 7AZ EC Declaration of Conformity This is an important document and should be retained SGS Engineering (UK) Ltd MANUFACTURER’S NAME: Ratchet Wrench TYPE OF EQUIPMENT: SAT105K PART NUMBER: APPLICATION OF EC COUNCIL DIRECTIVES / STANDARD:...
