EARTH
GROUND
N
NEUTRAL
L
HOT/LIVE
AC Input
15A Branch Circuit
#14 or #12 AWG
Internal Cable
(pre-wired)
AX-CTL-(#) and AX-CTL-(#)V Mounting
Ground Wire
(pre-wired to backbox stud)
AX-CC(#)-16, CCM-01 and CCM-02 Mounting
Figure 1 – AX-ACB Mounting and Wiring
AX-ACB
www.advancedco.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Advanced Axis AX-ACB
Summary of Contents for Advanced Axis AX-ACB
- Page 1 AX-ACB Ground Wire (pre-wired to backbox stud) EARTH GROUND NEUTRAL HOT/LIVE AC Input 15A Branch Circuit #14 or #12 AWG Internal Cable (pre-wired) AX-CTL-(#) and AX-CTL-(#)V Mounting AX-CC(#)-16, CCM-01 and CCM-02 Mounting Figure 1 – AX-ACB Mounting and Wiring www.advancedco.com...
- Page 2 These instructions cover the installation and replacement of the AX-ACB AC Board. Refer to separate wiring diagrams and manuals for additional system module installation wiring, operation and programming functions. AX-CTL-1: Wiring Diagram: 670-1342 Product Manual: 682-010 Program Manual: 682-002 AX-CTL-1L, AX-CTL-2 and AX-CTL-4: Wiring Diagram: 670-1233 Product Manual: 682-001 Program Manual: 682-002...
