- Page 1 IRELESS ES310 User Manual V1.2 2015 2 2 - 3 0 3 , 3 2 8 X I N G H U T R E E T U Z H O U H I N A...
- Page 2 Information to User This device complies with part 15 of the FCC Rules. Operation is subject to the condition that this device does not cause harmful interference. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
- Page 3 warning The device has been evaluated to meet general RF exposure requirement. This device should be installed in where that has no emission source and no metallic object obscures. RF Exposure Compliance The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or Transmitter.
-
Page 4: Table Of Contents
3.2 Step 2: Install ES310 ......................9 3.2.1 Connect Lines to ES310 ..................10 3.2.2 Connect ES310 to the Vehicle ................11 3.3 Step 3: Power On ....................... 11 3.4 Step 4: Set APN, Report Server IP (SMS) ................12 3.5 Step 5: Query Current Location (SMS) ................ -
Page 5: Version History
Version history Version Data Note Author V1.0 2013-10-1 First version Apple V1.1 2013-10-8 Jane V1.2 2013-10-11 Add chapter 3.6.4 Apple Default Account for User... -
Page 6: Structure Introduction
1. Structure Introduction ① ES310 works with power line and I/O line ○ 1 ○ 2 ② USB port ③ Supply power port and I/O port ④ Dimension: 83mm*43.2mm*17.7mm I/O port Supply power port ○ 3 ○ 4... -
Page 7: Preparation
2. Preparation Make sure the equipments below are all available. Equipment Lists: Equipment Name Number Note ES310 Necessary WCDMA SIM Card Necessary power Line Necessary I/O Line Necessary Power supply (12V- 36V) Necessary (Cigarette Lighter/ OBD) Data line Not Necessary (For AT command) -
Page 8: Quick Using Steps
3. Quick Using Steps S: Success Step 1 F: Fail Insert SIM Card Step 2 Install ES310 Step 3 Power on F check, re-do AT or SMS Step 4 (SMS) Step 7 (AT) Set APN&IP Set APN,IP F check, re-do... -
Page 9: Step 1: Insert Sim Card
Open the terminal cover, and put the metal side of SIM card face down and then fasten the card slot cover. Note: SIM Hot-Plug is forbidden for this device. 1. Metal side faces 2. Fasten card slot 3.2 Step 2: Install ES310 The terminal is GPS positioning product, it is recommended that you follow the instructions to install. -
Page 10: Connect Lines To Es310
I/O line Power supply line ④ 3.2.1 Connect Lines to ES310 First, connect power supply line to ES310. Plug the part ② of power supply line into ES310 power supply port (chapter 1 ③) Second, connect I/O line to ES310... -
Page 11: Connect Es310 To The Vehicle
When finishing installation, as long as power supply line is connected with cigarette lighter or OBD, ES310 is powered on and starts work. Note: If ES310 is connected with cigarette lighter, then only the car is ignition on, cigarette lighter will has voltage. That means, ES310 can be powered on. -
Page 12: Step 4: Set Apn, Report Server Ip (Sms)
When ES310 is powered on, the two LEDs –Yellow and green LEDs will light for 10 seconds; then, only green LED will blink four times; after blinking, yellow and green LEDs will blink together. Wait for a while, yellow LED will light without blink. - Page 13 Note: It’s also no problem if the user name and the pass word are not set. For example (the content of SMS): gprs,cmnet, www.eskylocate.com:1750 # Report server URL The possible responses: ①GPRS=Success! That means everything goes well. GO TO Step 5. ②GPRS=Fail! Make sure no parameters are missed.
-
Page 14: Step 5: Query Current Location (Sms)
Make sure GPS signal coverage is good. 3.5 Step 5: Query Current Location (SMS) If Step1 ~ Step 4 have passed, Then you can refer to <ES310 Protocol> to go on test other functions. The Query Current Location command is “Where, [PASSWORD] #”. -
Page 15: Login Page
Figure 1: Loading Page If you don’t see this page, please do: ①Check your Internet Connection. ②Check your operation system(No IOS). ③You don’t have install plug-in (sliverlight), Microsoft will give you the link of installation. If not, you have to install it by yourself: http://www.microsoft.com/getsilverlight/Get-Started/Install/Default.aspx 3.6.2 Login Page After finish loading, go into Log-In page. -
Page 16: Register An Account
①Make sure IMEI is the exactly number you can see on the product label. Totally 15 numbers. And also it’s unique, so don’t register with using same IMEI. ②Table “Version”, please choose ES310. ③Make sure your E-mail address is correct. You can re-get your password via E-mail if you forgot... -
Page 17: Default Account For User
After register successfully, return to Log-In page and enter the User Name and Password you just set. 3.6.4 Default Account for User eSky Wireless Inc. has an default account for user to experience the Car Online Platform. The default account: User name: esky Password: esky1233456 You are welcome to use the above user name and password to register on our platform. -
Page 18: Start Tracking
Figure 5: Main tracking Page 3.6.6 Modes Switch Page If you have two or more ES310 devices, you can add the others in one account (Same UserID). Click the middle of 3*3 squared. As shown in Figure 6. Figure 6: Modes Switch Page Then click “Add”... - Page 19 Figure 7: Add Device Pop-up...
-
Page 20: Step 7: Set Apn, Report Server Ip (At)
If commands are set by AT command, please refer to <serial Readme> to install ES310 device driver and set hyper terminal You can contact our technical support to ask for device driver and <serial Readme>. If everything is ready, then follow me to enjoy the AT command trip. -
Page 21: Step 8: Normal Function Test (At)
It means APN, server IP have changed successfully. ② OK GPRS=Fail! Try again Please don’t set any command within 1 ~ 2 min after ES310 is powered on. Mark sure GPRS command spells correctly. ③ ERROR Make sure that AT command mark spells correctly. - Page 22 AT command should be: at*cmd=”interval,000000,120#” Possible Response: ① OK INTE RVA L =Success! ② OK INTERVAL=Fail! ③ ERROR ④No Response.
-
Page 23: Install And Operation
4. Install and Operation 4.1 Installation Method Note: 1) The following installation order, please do not inverted. 2) During the installation process, please do not supply the terminal. The terminal installation is divided into hidden installation and open installation When the terminal is using special vehicles, hidden installation is recommended. Otherwise, open installation is chosen. -
Page 24: Installation Notes
4.3 Installation Notes ① Avoid put together with the emission source, for example, reversing radar, anti-theft devices and other on-board communications equipment. ② As for fixing the terminal, you can bound with ties or stick with wide sponge strength double-faced adhesive. ③... -
Page 25: Supplement
But if PDP cannot be activated, it shows off. 5.2 I/O Harness ES310 has 3 INPUTs, 2 OUTPUTs. Count from right to left: INPUT: orange wire is INPUT 0, yellow is INPUT 1, brown is INPUT 2,...
