ASSEMBLY INSTRUCTIONS
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE
PARTS LIST
PART
MATERIAL CODE
NO.
1
KUS862B-CS04-6
2
KUS862B-CS02-1
3
KUS862B-CS01-2
4
KUS862B-CS01-3
5
17C33A07A5001Y4
6
17C33A0706001Y4
7
17C02A0755131Y4
Attention:
Make sure that each bolt needed for all steps matches
the corresponding figure to ensure proper assembly.
Step 1:
Place the back assembly (#1) onto a non-abrasive
surface, such as a carpet. Insert the seat assembly (#2)
into the back assembly (#1). See Figure 1.
!
Use the correct bolts as indicated. Do not tighten any of the bolts until the chair is completely
assembled.
Do not discard of any of the packaging until you have checked that you have all of the parts and
!
fittings required.
Keep children away during assembly. This item contains small parts that can be swallowed by
!
children. Children should always be under direct adult supervision while using this product.
!
Retain these assembly instructions for future reference.
!
Quote the following FQC NO.when contacting the service center.
INTENDED FOR RESIDENTIAL USE ONLY.
KUS862B
PART
BACK ASSEMBLY
SEAT ASSEMBLY
LEFT ARM
RIGHT ARM
BOLT M6*64
BOLT M6*16
BOLT M6*14
SERVICE CENTER TOLL FREE NO.
TEL: 1-877-539-7436
FAX: 1-877-539-7439
DON'T RETURN TO STORE!
STOP
PAGE 1 OF 3
8
Q'TY
17C33A0712001Y4
1
9
17FA05040301-Y4
1
10
18000337004
1
11
18000337006
1
12
17KAA0101----Y4
2
13
17KAA0201----Y4
2
14
61K862BX00001BA
2
15
61K862BY00001BA
FIGURE 1
BOLT M6*35
WASHER d6.5*D13*1.0
BOLT CAP
BOLT CAP M6
HEX.KEY WRENCH 4MM
HEX.KEY WRENCH 6MM
BACK CUSHION
SEAT CUSHION
2
1
COURTYARD CREATIONS INC.
2
6
6
2
1
1
1
1
2
1
