- Page 1 COMET SYSTEM www.cometsystem.com Web Sensor T5540 Web Sensor T5541 Web Sensor T5545 Web Sensor T6540 Web Sensor T6541 Web Sensor T6545 USER GUIDE...
- Page 2 Is prohibited to copy and make any changes in this manual, without explicit agreement of company COMET System, s.r.o. All rights reserved. COMET System, s.r.o. makes constant development and improvement of all its products. Manufacturer reserves the right to make technical changes without previous notice. Misprints reserved.
-
Page 3: Table Of Contents
IE-SNC-T5(6)5xx-08 Table of contents Introduction ................................ 4 General safety rules ............................. 5 Device description and important notices ....................5 Getting started ..............................7 What is needed for operation ........................7 Mounting the device ............................ 7 Device settings ............................. 8 Checking functions ............................10 Device setup ..............................11 Setup using web interface .........................11 Setup using TSensor software .........................22... -
Page 4: Introduction
Temperature units are °C or °F. Communication interface of Web Sensors is Ethernet. Device types: Type Temperature Relative humidity concentration Computed quantity T5540 T5541 T5545 T6540 T6541 ... -
Page 5: General Safety Rules
IE-SNC-T5(6)5xx-08 General safety rules The following summary is used to reduce the risk of injury or damage the device. To prevent injury, please follow instructions. The device can be services only by a qualified person. The device contains no serviceable parts inside. Don’t use the device, if it doesn’t work correctly. - Page 6 IE-SNC-T5(6)5xx-08 The device can also be used to check measured values and if the limit is exceeded, device sends warning messages. Possible ways to sending warning messages: Sending e-mails up to 3 e-mail addresses Sending SNMP traps up to 3 configurable IP addresses ...
-
Page 7: Getting Started
IE-SNC-T5(6)5xx-08 Chapter Getting started Here you can find information necessary to put newly purchased equipment to operation. This procedure is only informative. What is needed for operation To install the unit you need to the following equipment. Before installation check if it’s available. -
Page 8: Device Settings
IE-SNC-T5(6)5xx-08 192.168.1.213. This address must be changed according to information from the previous step. When you installing several new devices, connect them to the network one after another. connect the Ethernet connector connect the power adapter 9 - 30V (e.g. 12V/200mA) ... - Page 9 IE-SNC-T5(6)5xx-08 the window shows all available devices on your network click to Change IP to set new address according to network administrator instructions. If your device is not listed, then click Help! My device wasn’t found! Then follow the instructions. MAC address is on product label. The device is factory set to IP 192.168.1.213.
-
Page 10: Checking Functions
IE-SNC-T5(6)5xx-08 Checking functions The last step is to check measured values on the device website. In the address bar of the web browser, enter the device IP address. If the default IP address was not changed, then insert http://192.168.1.213. Displayed web page lists actual measured values. If the web pages are disabled, you can see text Access denied. -
Page 11: Device Setup
IE-SNC-T5(6)5xx-08 Chapter Device setup This chapter describes basic device configuration. There is a description of settings using web interface. Setup using web interface Device can be setup using web interface or TSensor software. Web interface can be managed by the web browser. Main page will be shown when you insert device address into address bar of your web browser. - Page 12 IE-SNC-T5(6)5xx-08 General Device name can be changed using item Device name. Measured values are stored into memory according History storage interval field. After changing of this interval all history values will be cleared. Changes must be confirmed by Apply settings button.
- Page 13 IE-SNC-T5(6)5xx-08 Network Network parameters can be obtain automatically from DHCP server using option Obtain an IP address automatically. Static IP address is configurable via field IP address. It is not necessary setup Default gateway while you use device inside one subnet only. DNS server IP is required to set for proper function of DNS.
- Page 14 IE-SNC-T5(6)5xx-08 Alarm limits For each measurement channel is possible to set upper and lower limits, time-delay for alarm activation and hysteresis for alarm clearing. Example of setting the limit to the upper alarm limit: In Point 1 the temperature exceeded the limit. From this time, the time-delay is counting. Because at point 2 the temperature dropped below the limit value before the time delay expired, alarm was not set.
- Page 15 IE-SNC-T5(6)5xx-08 The alarm lasted up to Point 5, when the temperature dropped below the set hysteresis (temperature limit – hysteresis). At this moment was active alarm cleared and e-mail sent. When alarm occurs, alarm messages will be sent. In case of power failure or device reset (e.g. changing the configuration) will new alarm state evaluated and new alarm messages will be sent.
- Page 16 IE-SNC-T5(6)5xx-08 SOAP protocol SOAP protocol can be enabled by option SOAP protocol enabled. Destination SOAP server can be set via SOAP server address. For setup of server port can be used option SOAP server port. Device sends SOAP message according selected Sending interval. Option Send SOAP message when alarm occurs sends message when an alarm on channel occurs or alarm is cleared.
- Page 17 IE-SNC-T5(6)5xx-08 Email Email sending enabled option allows email features. It is necessary set address of the SMTP server into SMTP server address field. Domain name for SMTP server can be used. Default port of the SMTP server can be changed using item SMTP server port. SMTP authentication can be enabled using SMTP authentication option.
- Page 18 IE-SNC-T5(6)5xx-08 Modbus a Syslog protocols ModbusTCP and Syslog protocol settings are configurable via menu Protocols. Modbus server is enabled by default. Deactivation is possible via Modbus server enabled option. Modbus port can be changed via Modbus port field. Syslog protocol can be enabled using item Syslog enabled.
- Page 19 IE-SNC-T5(6)5xx-08 SNMP For reading values via SNMP it is necessary to know password - SNMP read community. SNMP Trap can be delivered up to three IP address - IP address of the Trap recipient. SNMP Traps are sent at alarm or error state on the channel. Trap feature can be enabled by option Trap enabled.
- Page 20 IE-SNC-T5(6)5xx-08 Time Time synchronization with SNTP server can be enabled by Time synchronization enabled option. IP address of the SNTP is necessary to set into SNTP server IP address item. List of free NTP servers is available at www.pool.ntp.org/en. SNTP time is synchronized at UTC format, and due to be necessary set corresponding time offset - GSM offset [min].
- Page 21 IE-SNC-T5(6)5xx-08 WWW and security Security features can be enabled by the Security enabled option. When security is enabled it is necessary to set administrator password. This password will be required for device settings. When secured access is required even to actual values reading it is possible to enable User account only for viewing enabled.
-
Page 22: Setup Using Tsensor Software
IE-SNC-T5(6)5xx-08 Setup using TSensor software TSensor software is an alternative to web configuration. Some less important parameters are configurable only by the TSensor software. TSesnor software allows user adjustment of measured values. Parameter MTU size can reduce size of the Ethernet frame. Lowering of this size can solve some communication problems mainly with Cisco network infrastructure. -
Page 23: Factory Defaults
IE-SNC-T5(6)5xx-08 Factory defaults Factory defaults field set the device into factory configuration. Network parameters (IP address, Subnet mask, Gateway, DNS) are left without changes. Settings relating to measurement are not restored by factory defaults. Network parameters are changed while you close jumper and push button inside device during connecting power supply. - Page 24 IE-SNC-T5(6)5xx-08 Parameter Default value Website refresh interval [sec] Website enabled Website port Security Administrator password cleared User password cleared Modbus port Modbus server enabled History storage interval [sec] SOAP server port SOAP server address cleared SOAP sending interval [sec] SOAP message when alarm occurs SOAP protocol enabled Syslog server IP address 0.0.0.0...
-
Page 25: Communication Protocols
IE-SNC-T5(6)5xx-08 Chapter Communication protocols Short introduction to communication protocols of the device. To use some communication protocols is necessary software, which can use the protocol. This software is not included. For detailed description of protocols and application notes please contact your distributor. Website The device supports displaying of measured values, history graphs and configuration using web browser. -
Page 26: Snmp
IE-SNC-T5(6)5xx-08 SNMP Using SNMP protocol you can read actual measured values, alarm status and alarm parameters. Via SNMP protocol is also possible to get last 1000 measured values from history table. Writing via SNMP protocol is not supported. It is supported SNMPv1 protocol version only. - Page 27 IE-SNC-T5(6)5xx-08 Description Type .1.3.6.1.4.1.22626.1.2.4.10.0 Temperature hysteresis Int*10 .1.3.6.1.4.1.22626.1.2.4.11.0 Relative humidity hysteresis Int*10 .1.3.6.1.4.1.22626.1.2.4.12.0 Computed quantity hysteresis Int*10 .1.3.6.1.4.1.22626.1.2.4.13.0 concentration low limit Integer .1.3.6.1.4.1.22626.1.2.4.14.0 concentration high limit Integer .1.3.6.1.4.1.22626.1.2.4.15.0 concentration time-delay Integer .1.3.6.1.4.1.22626.1.2.4.16.0 concentration hysteresis Integer .1.3.6.1.4.1.22626.1.5.5.1.0 SNMP Trap String .1.3.6.1.4.1.22626.1.5.6.1.1.1.nr Temperature history values Int*10 .1.3.6.1.4.1.22626.1.5.6.1.1.2.nr...
-
Page 28: Modbus Tcp
IE-SNC-T5(6)5xx-08 Modbus TCP Device supports Modbus protocol for communication with SCADA systems. Device use Modbus TCP protocol. TCP port is set to 502 by default. Port can be changed using TSensor software or web interface. Only two Modbus clients can be connected to device at one moment. -
Page 29: Soap
IE-SNC-T5(6)5xx-08 Address [DEC] Address [HEX] Value Type 20506 0x501A Max. computed value memory Int*10 20507 0x501B Min. CO concentration memory Int*X 20508 0x501C Max. CO concentration memory Int*X Type: register is in range 0 – 4500 (16bit) register is in BCD format (16bit) number in HEX format (16bit) String two characters in one 16bit register:... - Page 30 T5540 4155 T6540 4158 T5541 4161 T6541 4164 T5545 4191 T6545 4194 <temp> Contains the value of temperature (a decimal part of number is separated by a dot). Error on channel is signaled by 9999 or -9999. <relHum> Contains the value of relative humidity. Error value: 9999 or -9999.
-
Page 31: Syslog
IE-SNC-T5(6)5xx-08 Syslog The device allows sending text message to selected Syslog server. Events are send using UDP protocol on port 514. Syslog protocol implantation is according to RFC5424 and RFC5426. Events when Syslog messages are send: Text Event Sensor - fw 1-5-7.x Reset of the device NTP synchronization error NTP synchronization error... -
Page 32: Troubleshooting
Chapter Troubleshooting The chapter describes the common problems with devices Web Sensor Tx5xx and methods how to fix these problems. Please read this chapter before you will call technical support. I forgot the device IP address IP address is factory set to 192.168.1.213. If you had changed it and forgot new IP address, run the TSensor software and press Find device... -
Page 33: I Forgot The Password For Setup
I forgot the password for setup Please reset device to factory defaults. Procedure is described at following point. Factory defaults This procedure restore device to factory settings including network parameters (IP address, Subnet mask, etc.). Settings relating to measurement are not restored by factory defaults. For factory-defaults follow these steps: ... -
Page 34: Device Error States
Device error states Device still make self-tests. If error occurred, LCD shows error codes: Error LCD display Description Error 0 Err0 Internal memory CRC error. In this state device doesn't work. This is a critical error, contact the distributor. Error 1 Err1 Measured value or computed quantity (expect CO concentration) is over the... -
Page 35: Technical Specifications
Chapter Technical specifications Information about technical specifications of the device. Dimensions Web Sensor T5540: Web Sensor T5541:... - Page 36 Web Sensor T5545: Web Sensor T6541:...
-
Page 37: General Parameters
Web Sensor T6540: Web Sensor T6545: General parameters Supply voltage: DC voltage from 9V to 30V, coaxial connector, 5x2.1mm diameter, center positive pin Consumption: ~ 1W continuously, max. 4W for 50ms with 15s period Measuring interval of temperature and relative humidity: 2sec Measuring interval of CO concentration:... - Page 38 T6540 ~160g T5541/1m probe ~240g, T5541/2m probe ~270g, T5541/4m probe ~330g T6541/1m probe ~320g, T6541/2m probe ~390g, T6541/4m probe ~530g T5545 ~ 280g T6545 ~ 290g Mounting the device: With two holes at the bottom of the unit Communication port:...
-
Page 39: Measured Values
1000 values for each channel inside non-backup RAM memory EMC: EN 61326-1, EN 55011 Measured values Type Temperature Relative humidity concentration Computed quantity T5540 T5541 T5545 T6540 T6541 T6545 ... -
Page 40: Co 2 Concentration Measurement
Type Range Accuracy Resolution T5540 T6540 ±50ppm + 2% of measuring value 0 to 2000ppm T5545 at 25°C (77°F) and 1013hPa 1ppm T6545 T5541 ±100ppm + 5% of measuring value 0 to 10000ppm at 25°C (77°F) and 1013hPa T6541 Temperature dependence: typ. - Page 41 Specific humidity This value depends on atmospheric pressure. Pressure for quantities calculation is stored in device memory. Default value is 1013hPa and can be changed by software. Range: 0 to 550g/kg Accuracy: ±2.1g/kg at ambient temperature T < 35°C (95°F) Mixing ratio This value depends on atmospheric pressure.
-
Page 42: Operating Terms
T5541 -30°C to +80°C -40°C to +60°C T6541 -30°C to +105°C (-22°F to +176°F) (-40°F to +140°F) (-22°F to +221°F) T5545 -30°C to +60°C -30°C to +60°C (-22°F to +140°F) (-22°F to +140°F) T6545 -30°C to +60°C -30°C to +60°C (-22°F to +140°F) - Page 43 When mounting in RACK 19" with universal holder MP046 (optional accessories) then sensor cover can be placed horizontally. Working position T5545, T6545: arbitrary - the holes in the stem must be routed in the direction of the air flow...
-
Page 44: End Of Operation
Recommended calibration interval: Type Calibration interval T5540 5 years T5541 5 years T5545 5 years T6540 1 year (temperature 2 years, relative humidity 1 year, CO concentration 5 years) T6541 1 year (temperature 2 years, relative humidity 1 year, CO... -
Page 45: Optional Accessories
Chapter Optional accessories This chapter contains list of optional accessories, which can be ordered by extra cost. Manufacturer recommends using only original accessories. All available optional accessories are on manufacturer webpages. Power supply Adapter A1515 Power supply adapter with CEE 7 plug, 100-240V 50-60Hz/12V DC, 0.5A for Web Sensor devices. - Page 46 www.cometsystem.com...
