Summary of Contents for Comet System Web Sensor T5540
Page 1
COMET SYSTEM www.cometsystem.cz Web Sensor T5540 Web Sensor T5541 Web Sensor T6540 Web Sensor T6541 USER GUIDE...
Page 2
Is prohibited to copy and make any changes in this manual, without explicit agreement of company COMET System, s.r.o. All rights reserved. COMET System, s.r.o. makes constant development and improvement of all its products. Manufacturer reserves the right to make technical changes without previous notice.
IE-SNC-T5(6)5xx-04 Table of contents Introduction ................................ 4 General safety rules ............................. 5 Device description and important notices ....................5 Getting started ..............................7 What is needed for operation ........................7 Mounting the device ............................ 7 Device settings ............................. 8 Checking functions ............................10 Device setup ..............................11 Setup using web interface .........................11 Setup using TSensor software .........................18...
IE-SNC-T5(6)5xx-04 Chapter Introduction This chapter provides basic information about device. Before starting please read this manual carefully. The Web Sensor devices are designed for measurement of temperature, relative humidity and carbon dioxide concentration of air without aggressive substances. Measured quantities are according device type.
IE-SNC-T5(6)5xx-04 General safety rules The following summary is used to reduce the risk of injury or damage the device. To prevent injury, please follow instructions. The device can be services only by a qualified person. The device contains no serviceable parts inside. Don’t use the device, if it doesn’t work correctly.
Page 6
IE-SNC-T5(6)5xx-04 Sending e-mails up to 3 e-mail addresses Sending SNMP traps up to 3 configurable IP addresses Displaying the alarm status on web page Sending messages to Syslog server The device setup can be made by the TSensor software or web interface. TSensor software can be free downloaded from the manufacturer’s website.
IE-SNC-T5(6)5xx-04 Chapter Getting started Here you can find informations necessary to put newly purchased equipment to operation. This procedure is only informative. What is needed for operation To install the unit you need to the following equipment. Before installation check if it’s available.
IE-SNC-T5(6)5xx-04 192.168.1.213. This address must be changed according to informations from the previous point. When you installing several new devices, connect them to the network one after another. connect the Ethernet connector connect the power adapter 9 - 30V (e.g. 12V/200mA) LEDs on LAN connector should blink after connecting the power and LCD start showing measured values.
Page 9
IE-SNC-T5(6)5xx-04 the window shows all available devices on your network click to Change IP to set new address according to network administrator instructions. If your device is not listed, then click Help! My device wasn’t found! Then follow the instructions. MAC address is on product label. The device is factory set to IP 192.168.1.213.
IE-SNC-T5(6)5xx-04 Checking functions The last step is to check measured values on the device website. In the address bar of the web browser, enter the device IP address. If the default IP address was not changed, then insert http://192.168.1.213. Displayed web page lists actual measured values. If the web pages are disabled, you can see text Access denied.
IE-SNC-T5(6)5xx-04 Chapter Device setup This chapter describes basic device configuration. There is a description of settings using web interface. Setup using web interface Device can be setup using web interface or TSensor software. Web interface can be managed by the web browser. Main page will be shown when you insert device address into address bar of your web browser.
Page 12
IE-SNC-T5(6)5xx-04 General Device name can be changed using item Device name. Measured values are stored into memory according History storage interval field. After changing of this interval all history values will be cleared. Changes must be confirmed by Apply settings button. Network Network parameters can be obtain automatically from DHCP server using option Obtain an IP address automatically.
Page 13
IE-SNC-T5(6)5xx-04 Alarm limits For each measurement channel is possible to set upper and lower limits, time-delay for alarm activation and hysteresis for alarm clearing. Example of setting the limit to the upper alarm limit: In Point 1 the temperature exceeded the limit. From this time, the time-delay is counting. Because at point 2 the temperature dropped below the limit value before the time delay expired, alarm was not set.
Page 14
IE-SNC-T5(6)5xx-04 Measuring Page contains settings of the measuring part of the device. Settings can be saved only if jumper inside device is closed. Fields in this page are shown according device type. It is possible set visibility of measured values on device LCD. Display can be switched off. Units of measured and computed quantities are selectable by fields Temperature unit and Computed value.
Page 15
IE-SNC-T5(6)5xx-04 SOAP protocol SOAP protocol can be enabled by option SOAP protocol enabled. IP address of the destination http server is configurable via SOAP server IP address filed. For setup of destination server port can be used option SOAP server port. Target place of the http server can be set via SOAP server target place.
Page 16
IE-SNC-T5(6)5xx-04 Modbus a Syslog protocols ModbusTCP and Syslog protocol settings are configurable via menu Protocols. Modbus server is enabled by default. Deactivation is possible via Modbus server enabled option. Modbus port can be changed via Modbus port field. Syslog protocol can be enabled using item Syslog enabled.
Page 17
IE-SNC-T5(6)5xx-04 SNMP For reading values via SNMP it is necessary to know password - SNMP read community. SNMP Trap can be delivered up to three IP address - IP address of the Trap recipient. SNMP Traps are sent at alarm or error state on the channel. Trap feature can be enabled by option Trap enabled.
IE-SNC-T5(6)5xx-04 WWW and security Security features can be enabled by the Security enabled option. When security is enabled it is necessary to set administrator password. This password will be required for device settings. When secured access is required even to actual values reading it is possible to enable User account only for viewing enabled.
IE-SNC-T5(6)5xx-04 Factory defaults Factory defaults field set the device into factory configuration. Network parameters (IP address, Subnet mask, Gateway, DNS) are left without changes. Settings relating to measurement are not restored by factory defaults. Network parameters are changed while you close jumper and push button inside device during connecting power supply.
Page 20
IE-SNC-T5(6)5xx-04 SOAP sending interval [sec] SOAP message when alarm occurs SOAP protocol enabled Syslog server IP address 0.0.0.0 Syslog protocol enabled SNTP server IP address 217.31.205.226 GMT offset [min] NTP synchronization every hour SNTP synchronization enabled 1400 Periodic restart interval Demo mode Temperature High limit...
IE-SNC-T5(6)5xx-04 Chapter Communication protocols Short introduction to communication protocols of the device. To use some communication protocols is necessary software, which can use the protocol. This software is not included. For detailed description of protocols and application notes please contact your distributor. Website The device supports displaying of measured values, history graphs and configuration using web browser.
IE-SNC-T5(6)5xx-04 SNMP Using SNMP protocol you can read actual measured values, alarm status and alarm parameters. Via SNMP protocol is also possible to get last 1000 measured values from history table. Writing via SNMP protocol is not supported. It is supported SNMPv1 protocol version only.
IE-SNC-T5(6)5xx-04 .1.3.6.1.4.1.22626.1.5.6.1.1.2.nr Relative humidity history values Int*10 .1.3.6.1.4.1.22626.1.5.6.1.1.3.nr Computed quantity history values Int*10 .1.3.6.1.4.1.22626.1.5.6.1.1.4.nr concentration history values Integer When alarm occurred a warning messages (trap) can be sent to selected IP addresses. Addresses can be set using TSensor software or web interface. Traps are sent via UDP protocol on port 162.
IE-SNC-T5(6)5xx-04 FWrite($file_write, $data); FClose($file_write); $server = new SoapServer(null, array('uri' => "http://test-uri/")); $server->addFunction('InsertTx5xxCO2Sample'); $server->handle(); ?> Syslog The device allows sending text message to selected Syslog server. Events are send using UDP protocol on port 514. Syslog protocol implantation is according to RFC5424 and RFC5426.
IE-SNC-T5(6)5xx-04 Chapter Troubleshooting The chapter describes the common problems with devices Web Sensor Tx5xx and methods how to fix these problems. Please read this chapter before you will call technical support. I forgot the device IP address IP address is factory set to 192.168.1.213. If you had changed it and forgot new IP address, run the TSensor software and press Find device...
IE-SNC-T5(6)5xx-04 Follow the software instructions. An alternative is to reset device to factory defaults using factory-defaults button. I forgot the password for setup Please reset device to factory defaults. Procedure is described at following point. Factory defaults This procedure restore device to factory settings including network parameters (IP address, Subnet mask, etc.).
IE-SNC-T5(6)5xx-04 Device error states Device still make self-tests. If error occurred, LCD shows error codes: Error LCD display Description Error 0 Err0 Internal memory CRC error. In this state device doesn't work. This is a critical error, contact the distributor. Error 1 Err1 Measured value or computed quantity (expect CO...
IE-SNC-T5(6)5xx-04 Chapter Technical specifications Informations about technical specifications of the device. Dimensions Web Sensor T5540: Web Sensor T5541:...
IE-SNC-T5(6)5xx-04 Web Sensor T6540: Web Sensor T6541: General parameters Supply voltage: DC voltage from 9V to 30V, coaxial connector, 5x2.1mm diameter, positive pole in the middle Consumption: ~ 1W continuously, max. 4W for 50ms with 15s period Measuring interval of temperature and relative humidity: 2sec...
Page 32
IE-SNC-T5(6)5xx-04 Measuring interval of CO concentration: 15sec Display switching interval: 4sec (when more than two values are displayed) Not allowed manipulations: It is not allowed to operate the device under conditions other than specified in technical parameters. Devices are not designed for locations with chemically aggressive environment.
IE-SNC-T5(6)5xx-04 1000 values for each channel inside non-backup RAM memory EMC: EN 61326-1, EN 55011 Measured values Type Temperature Relative humidity concentration Computed quantity T5540 T5541 T6540 T6541 Temperature measurement Temperature and humidity measuring range is limited - see graph below.
IE-SNC-T5(6)5xx-04 Relative humidity and temperature restrictions: concentration measurement Type Range Accuracy Resolution T5540 ±50ppm + 2% of measuring value 0 to 2000ppm T6540 at 25°C (77°F) and 1013hPa 1ppm T5541 ±100ppm + 5% of measuring value 0 to 10000ppm at 25°C (77°F) and 1013hPa T6541 Temperature dependence: typ.
Page 35
IE-SNC-T5(6)5xx-04 Specific humidity This value depends on atmospheric pressure. Pressure for quantities calculation is stored in device memory. Default value is 1013hPa and can be changed by software. Range: 0 to 550g/kg Accuracy: ±2.1g/kg at ambient temperature T < 35°C (95°F) Mixing ratio This value depends on atmospheric pressure.
IE-SNC-T5(6)5xx-04 Accuracy: ±3g/m at ambient temperature T < 40°C (104°F), for more details see graph: Operating terms Temperature operating range: Type Case with electronic Measuring end of probe RH+T probe stem T5540 -30°C to +60°C T6540 (-22°F to +140°F) -30°C to +80°C (-22°F to +176°F) T5541 -30°C to +80°C...
IE-SNC-T5(6)5xx-04 Other environmental conditions (external influences) according to HD 60364-5-51: normal Storage conditions: temperature: -40°C to +60°C (-40°F to +140°F) relative humidity: 5 to 95%RH (without condensation) barometric pressure: 700 to 1100hPa Working position T5541, T6541: arbitrary Working position T5540: with connectors upwards Working position T6540: with sensor cover downwards.
IE-SNC-T5(6)5xx-04 Chapter Optional accessories This chapter contains list of optional accessories, which can be ordered by extra cost. Manufacturer recommends using only original accessories. Power supply Adapter A1515 Power supply adapter with CEE 7 plug, 100-240V 50-60Hz/12V DC, 0.5A for Web Sensor devices.
