READ BEFORE USE!
READ BEFORE USE!
WARNING
WARNING
USE PROPANE GAS ONLY!
USE PROPANE GAS ONLY!
-Do not store or use gasoline or other
-Do not store or use gasoline or other
flammable vapors in the vicinity of this or any
flammable vapors in the vicinity of this or any other
other appliance.
appliance.
- Service must be performed by a qualified installer,
- Service must be performed by a qualified installer, service
service agency or the gas supplier.
agency or the gas supplier.
WARNING
WARNING
For use with cylinders marked PROPANE only. DO
For use with cylinders marked PROPANE only. DO NOT
NOT connect to a remote gas supply.
connect to a remote gas supply.
If the firebowl is stored indoors, detach and leave
If the firebowl is stored indoors, detach and leave
propane cylinder outdoors.
propane cylinder outdoors.
5004909
Design certified under ANSI 21.97 CSA 2.41-(2014)
Design Complies with ANSI Z21.97-2014 • CSA 2.41-(2014)
Requirements for Outdoor Gas Fireplaces
Outdoor Decorative Gas Fireplaces.
OWNER'S MANUAL
OWNER'S MANUAL
Factory No.: HYFP50095-32
1
Item No.: WAR-986
WARNING
WARNING
For Outdoor Use Only! Use Propane Gas Only !
For Outdoor Use Only! Use Propane Gas Only !
Propane cylinders sold separately.
Propane cylinders sold separately.
WARNING
WARNING
Improper installation,
adjustment, alteration, service or maintenance can cause
Improper installation, ad ustment, alteration,
injury or property damage. Read the owner's manual
thoroughly before installing or servicing this equipment. If
service or maintenance can cause in ury or
the information in this manual is not followed exactly, a
property damage. R
fire or explosion may result causing property damage,
thoroughly efore installing or
personal injury or loss of life.
e uipment. I
WARNING
WARNING
The propane cylinder must be disconnected when
this firebowl is not use.
The propane cylinder must be disconnected
when this firebowl is not use.
DANGER
If you smell gas:
1. Shut off gas to the appliance.
If you smell gas:
2. Extinguish any open flame.
1. Shut off gas to the appliance.
3. If odor continues, keep away from the appliance and
2. Extinguish any open flame.
immediately call your gas supplier or fire department.
3. If odor continues, keep away from the appliance
and immediately call your gas supplier or fire
department.
WARNING
WARNING
This firebowl must be attended at all times!
This fire o l must e attended at all times!
WARNING
WARNING
An LP-cylinder not connected for use shall not be stored
in the vicinity of this or any other appliance.
An LP-cylinder not connected for use shall not e
stored in the vicinity of this or any other appliance.
1
Item No.: 67761
manual
DANGER

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WAR-986 and is the answer not in the manual?

Questions and answers

Related Manuals for Sunnydaze Decor WAR-986

Summary of Contents for Sunnydaze Decor WAR-986

  • Page 1 OWNER'S MANUAL OWNER'S MANUAL Factory No.: HYFP50095-32 Item No.: 67761 READ BEFORE USE! Item No.: WAR-986 READ BEFORE USE! WARNING WARNING For Outdoor Use Only! Use Propane Gas Only ! For Outdoor Use Only! Use Propane Gas Only ! Propane cylinders sold separately.
  • Page 2 DANGER Failure to follow the Dangers, Warnings and Cautions contained in this Owner’s Manual may result in serious bodily injury or death, or in a fire or an explosion causing damage to property. WARNING *Do not use this firebowl for cooking. *Remove the PVC Cover from the firebowl before opening the appliance.
  • Page 3 FOR PROPANE GAS UNITS *The gas pressure regulator provided with the propane fire bowl must be used. *Do not attempt to disconnect the gas regulator or any gas fitting while your firebowl is in operation. *A dented or rusty propane cylinder may be hazardous and should be checked by your gas supplier prior to use. *Do not use a propane cylinder with a damaged valve and any other worn out parts.
  • Page 4 Inspect the hose before each use of the appliance. If the hose shows signs of cracks, abrasions, cuts or damage of any kind, do not operate the appliance. Fix or replace the hose as required before using the appliance. For assistance with repair or replacement of the hose, call Bond Manufacturing at 1-866-771-2663.
  • Page 5 Tabulated here below are the description to all parts as shown in above Picture . Item Picture Description Guard Thermocouple Ground Wire Ignition Pin Burner Plate Main Frame of Fire Table Burner Ring Nozzle Corrugated Pipe Switching Valve Regulator Valve with Gas Hose Control Knob Ignitor...
  • Page 6 User's Guide Parts and Accessories of Fire Table / Column. Part G. Tabulated herebelow is the User's Guide to various Parts and Accessories to form your complete Fire Table /Column. Before you start to assemble this product, make sure all parts are present. Compare parts with package contents list.
  • Page 7 ASSEMBLY INSTRUCTIONS 1. Check that the Control Knob (13) for the gas supply system is turned to the “OFF” position before starting any assembly. 2. Attach panel with door (C) and panel with (D) together using 2pcs of Bolts(01) with Screwdriver(02). Pls do not fully tighten.
  • Page 8 5.Put Thank holder insert into the bottom holes . Tighten all Bolts 6.Put the metal base on the bottom of top, make sure the metal box contact with the window of the panel. And tighten the Bolts 7.Fixed the metal base with top using 4pcs of Bolts(01) with Screwdriver(02). And tighten the Bolts 8.Turn over the Gas Fire Pit...
  • Page 9 Part I. USER'S INSTRUCTIONS Tabulated herebelow are the basic steps to help you light and use your Fire Table / Column. STEP1 1. Check that the Control Knob (13) for the gas supply system is turned to the “OFF” position before starting any assembly.
  • Page 10 STEP 7 Subject to your preference, you may pour Lava Rocks / Pumice stones over the Burer Ring. The Guard MUST NOT BE BLOCKED. Refer to guidance below : Note : Do not place more than 1/4 inch depth of lava rocks above the burner holes. Doing so will suffocate the flame.
  • Page 11 See WARNING and Figures: See WARNING and Figures: WARNING WARNING This screen must be clear and free of This screen must be clear and free of obstructions at all times to insure proper obstructions at all times to insure proper operation.

  • Page 12: Routine Care

    TO EXTINGUISH Push the Control Knob and turn clockwise to the "OFF" position. Turn the cylinder valve on the gas tank clockwise to close the gas supply if not in use for a long time.(See figure below) ROUTINE CARE Keep your firebowl free and clear from combustible materials. Visually inspect burner from obstructions and keep fireplace free and clear from debris.

  • Page 13: Helpful Tips

    Helpful Tips If the burner will not light or stay lit, please perform the following checks. It is possible that the Excess Flow Safety Device has been tripped. Turn the control knob to off and close the LP Gas tank valve. Disconnect the regulator.

  • Page 14: Troubleshooting

    Troubleshooting Problem: Burner will not light using igniter Please review the Helpful Tips on page 15 for common fixes to this problem. Possible Cause 1: Electrode and burners are wet. -Wipe dry with cloth. Possible Cause 2: Igniter battery is dead or backwards. -Check that the AAA battery is inserted correctly in the igniter (see page 10) or replace the battery.
  • Page 15 Troubleshooting Problem: Sudden drop in gas flow, or a reduced flame height Possible Cause 1: Out of Gas. -Check for gas in the LP gas tank. Possible Cause 2: Excess flow safety device may have been activated. -Turn control knob to “OFF”, wait 30 seconds and light outdoor fire table. If flames are still too low, reset the excessive flow safety device by turning off...
