- Page 1 ® powered by GP-FLEX-30 Solar Flex Owner’s Manual...
- Page 2 GP-FLEX-30 Table of Contents 1.0 General Information 1.1 How Does a Go Power! Solar Charging Kit Work? 1.2 Warnings 1.3 Required Tools 1.4 Parts Checklist 1.5 Module Specifications 2.0 Wiring the Solar Module and Power Cable 2.1 Installling your 30 watt Solar Flex Kit (GP-FLEX-30) 3.0 Routing Power Cable through the Fridge Vent 3.1 Method 1 –...
- Page 3 GP-FLEX-30 1.1 How Does a Go Power! Solar Charging Kit Work? The solar module converts the sun’s energy into DC electricity and this electricity charges the battery. The battery stores the electricity, similar to a water tank storing water. The battery power may be used at any time to operate devices connected to the battery. To stop the battery from being overcharged by the solar module, a solar controller is connected in between the solar module and the battery.
- Page 4 GP-FLEX-30 1.4 Parts Checklist GP-FLEX-30 PART 01. Ring Terminal Battery Connector 02. 50’ MC4 Cable with Male and Female MC4 Connectors 03. Tie Wrap 04. #10 x 1” Wood Screws 05. #10 x 1.5” Machine Screws 06. #10 Well Nuts 07.
- Page 5 Warning: Using an adhesive can create a permanent mounting situation. It is strongly advised that placement is well thought out and that panel function has been tested before mounting. Go Power! and Carmanah Technologies is not responsible for damage caused the by removal of Solar Flex Modules.
- Page 6 GP-FLEX-30 battery terminal. See Figure 2: “12 Volt Battery Connected to Solar Controller with Inline Fuse”. 4. Wire the controller according to the terminal identification on the back of controller, starting with the battery connections. Tighten the positive and negative battery connections and then set the battery type (see controller manual for instruction).
- Page 7 GP-FLEX-30 7.3 Additional Information Unless approved by Go Power! management, all product shipped collect to Go Power! will be refused. Test items or items that are not under warranty, or units that are not defective, will be charged a minimum bench charge of ($50.00 US) plus taxes and shipping. A 15% restocking charge will be applied on goods returned and accepted as “new”...
- Page 8 GP-FLEX-30 ® powered by © 2013 Go Power! By Carmanah Technologies GP_MAN_Solar Flex_GP-30 electric.com...
