- Page 1 Synology DiskStation DS114 Quick Installation Guide Synology_QIG_DS114_20130716...
-
Page 2: Table Of Contents
Table of Contents Chapter 1: Before You Start Package Contents ................................3 Synology DiskStation at a Glance ............................ 4 Safety Instructions ................................5 Chapter 2: Hardware Setup Tools and Parts for Hard Disk Installation ........................6 Install Hard Disks ................................6 Start up your DiskStation .............................. -
Page 3: Package Contents
Please also read the safety instructions carefully before use to prevent your DiskStation from any damages. Package Contents Main unit x 1 AC power cord x 1 AC power adapter x 1 Screws for hard drives x 6 Screws for securing the Synology case x 3 RJ-45 LAN cable x 1... -
Page 4: Synology Diskstation At A Glance
To turn off Synology DiskStation, press the power button and hold it until you hear a beep sound and the Power LED starts blinking. The fan is built to exhaust waste heat out of Synology DiskStation. If the fan is Back Panel malfunctioning, the system will beep every few seconds. -
Page 5: Safety Instructions
Before cleaning, unplug the power cord first. Wipe Synology product with damp paper towels. Do not use chemical or aerosol cleaners to clean it. Do not place the Synology product on a cart, table, or desk, which is not stable to avoid the product from falling over. -
Page 6: Chapter 2: Hardware Setup
A screwdriver A 3.5" or 2.5" SATA hard disk (Please visit www.synology.com for compatible hard disk models.) Warning: If you install a hard disk that contains data, the system will format the hard disk and erase all data. If you need the data in the future, please back it up before installation. -
Page 7: Start Up Your Diskstation
b Slide the 2.5" Disk Holder into the hard drive bay, and push it all the way until the hard disk is connected to the SATA connector. Secure the Disk Holder with the provided screws. 3 Replace the upper case, and tighten the screws on the back panel. Start up your DiskStation 1 Connect the AC adapter to the power port of DiskStation. -
Page 8: Chapter 3: Install Dsm On Diskstation
Synology DiskStations – to start working. We highly recommend using Synology’s online Web Assistant for installing DSM from the web browser. Synology Web Assistant automatically downloads the latest available software updates from the Internet and guides you through the installation. -
Page 9: Learn More
Congratulations! Your DiskStation is set up now. Refer to the User’s Guide in the installation disc for advanced settings and management. For more information or online resources about your DiskStation, please visit www.synology.com. 9 Chapter 3: Install DSM on DiskStation... -
Page 10: Appendix A: Specifications
Environment Requirements ‧Storage Temperature: 15 to 155˚F (-10 to 70˚C) ‧Relative Humidity: 5% to 95% RH ‧Maximum Operating Altitude: 2,000 m (6,500 ft) Note: Model specifications are subject to change without notice. Please refer to www.synology.com for the latest information. -
Page 11: Appendix B: Led Indication Table
Disk is being accessed DISK No internal disk or disk idle Static Power ready Blue Booting up Power Blinking Shutting down Power off Note: Model specifications are subject to change without notice. Please refer to www.synology.com for the latest information. - Page 12 IMPORTANT–READ CAREFULLY: THIS END USER LICENSE AGREEMENT ("EULA") IS A LEGAL AGREEMENT BETWEEN YOU (EITHER AN INDIVIDUAL OR A SINGLE ENTITY) AND SYNOLOGY, INC. AND ITS AFFILIATES, INCLUDING SYNOLOGY AMERICAN CORP AND SYNOLOGY UK LTD., (COLLECTIVELY, "SYNOLOGY") FOR ANY SYNOLOGY SOFTWARE, TOGETHER WITH ANY OTHER ASSOCIATED FIRMWARE, MEDIA, PRINTED MATERIALS AND "ONLINE"...
- Page 13 Section 16. Termination. Without prejudice to any other threatened breach of any provision of this EULA relating to rights, Synology may terminate this EULA if you do not abide Synology's intellectual property rights. by the terms and conditions contained herein. In such event, you must cease use of the Software and destroy all copies of Section 20.
- Page 14 THIS LIMITED WARRANTY ("WARRANTY") APPLIES TO THE PRODUCTS (AS DEFINED BELOW) OF SYNOLOGY, INC. AND ITS AFFILIATES, INCLUDING SYNOLOGY AMERICA CORP AND SYNOLOGY UK LTD., (COLLECTIVELY, "SYNOLOGY"). YOU ACCEPT AND AGREE TO BE BOUND BY THE TERMS OF THIS WARRANTY BY OPENING THE PACKAGE CONTAINING AND/OR USING THE PRODUCT.
- Page 15 DAMAGES. the Product specifications; (b) has been repaired, modified or altered by anyone other than Synology or its agent or Limitation of Liability. SYNOLOGY'S AND ITS designee; (c) has been in any way misused, abused, or SUPPLIERS' LIABILITY ARISING OUT OF OR RELATING damaged;...
- Page 16 Customers residing within the and the arbitration proceedings shall be conducted in United States and Synology will be resolved exclusively and English or, if both parties so agree, in Mandarin Chinese. finally by arbitration under the current commercial rules of...
