Integrated Circuit Diagrams - Infinity Modulus MSW-1 Service Manual

MSW-1
JFET, J111, J113,
Q5, Q9
1. D
2. S
3. G
TRANS, NPN, 150V, 0.6A 2N5551TR,
MPSA92TR,
Q2, Q6, Q6
1. G
2. D
3. S

INTEGRATED CIRCUIT DIAGRAMS

TRANS, PNP, 150V, 0.6A,
2N5401TR, 2N4401
Q1, Q5, Q3
MOSFET,
IRF9540, IRF530,
IRF540, IRF740,
Q1, Q4, Q5, Q3,
Q7, Q4, Q8
3
1 2
QUAD OP AMP, 14 PIN DIL
LM324N, TL074/084
U5, U6, U1, U2
U1 HYBRID IC
-15V, LM7915CT
REGULATOR
U3
1. GROUND
2. INPUT
3. OUTPUT
1 2 3
OPAMP, DUAL 8
PIN DIL, TLO82
U2
31
+15V, LM7815CT
REGULATOR
U2
1. INPUT
2. GROUND
3. OUTPUT
1 2 3
