INSTALLATION, OPER., MAINT.
YCAQ10, YCAM12, YCAK14, YCAI16, YCAG18, YCAR11, YCAN13,
YCAM12, YCAK14, YCAI16, YCAG18, YCAN13, YCAL15, YCAJ17, YCAH19 with following EPROMS:*
BEFORE MAY 1, 1987
LCH130W
LCH130A
LCH150W
LCH150A
LCH175W
LCH175A
LCH200W
LCH200A
LCH230W
LCH230A
AIR COOLED – RECIPROCATING HERMETIC
Supersedes: 150.40-NM25 (389)
MODELS
YCAL15, YCAJ17 & YCAH19
STYLE D
YCAQ10 & YCAR11with following EPROMS:*
Standard Unit – GEII.4 Rev. 2
Brine Unit – GEII.4 BR Rev. 1
Metric Unit – GEII.4 M Rev. 1
Standard Unit – GEII.5 Rev. 2
Brine Unit – GEII.5 BR Rev. 1
Metric Unit – GEII.5 M Rev. 1
*Must be used with 031-00805 Rev. C Micrologic Board.
CROSS-REFERENCE CHART – NOMENCLATURE
EFFECTIVE MAY 1, 1987
YCWK11, YCWL12
YCRK00, YCRL00
YCWM13, YCWN14
YCRM00, YCRN00
YCWU19, YCWV20
YCRU00, YCRV00
YCWQ15, YCWR16
YCRQ00, YCRR00
YCWS17, YCWT18
YCRS00, YCRT00
PACKAGED LIQUID CHILLERS
Form 150.40-NM25 (597)
00013TG
EFFECTIVE JAN., 1990
YCWJ45PR0, YCWJ56PR0
YCRJ45PO0, YCRJ56PO0
YCWJ56RS0, YCWJ67RS0
YCRJ56RO0, YCRJ67RO0
YCWJ67TT0, YCWJ78TT0
YCRJ67TO0, YCRJ78TO0
YCWJ77VU0, YCWJ88VU0
YCRJ77VO0, YCRJ88VO0
YCWJ88XV0, YCWJ99XV0
YCRJ88XO0, YCRJ99XO0
