- Page 1 USER MANUAL Lighted Mirror PRO FESSI O NAL INS TALL AT I O N R ECOMMENDED WARRANTY REGISTRATION REGISTER FOR EXTRA BENEFITS Activate within 30 days of purchase: seura.com/activate 1-800 -957-3872 1230 O N TAR I O ROAD, GR EEN BAY, WI 54311...
- Page 2 Thank you for selecting a Séura Lighted Mirror. Please read this guide before beginning installation. Carefully remove and inspect the unit for possible damage that NOTE: All Séura drawing packages indicate generalized nominal occurred during shipping. If there is damage, please call Séura at residential wood framing construction and are not indicative of 1-800-957-3872.
- Page 3 DATE: the fixture disconnect using the color code listed in the next section. NOTE: PLEASE SIGN AND DATE THIS PAGE BEFORE RETURNING TO SEURA, SIGNIFYING YOU AGREE TO ALL TOLERANCES PROPRIETARY AND CONFIDENTIAL 7/8" KNOCKOUT SPECIFICATIONS SHOWN ON ALL DRAWING SHEETS. THE BUILD PROCESS WILL NOT BEGIN WITHOUT AN...
- Page 4 Dimmable Touch Button upgrade, verify that your wall switch supports dimming functionality. The dimmable switch must be 0-10V or Triac. Step 2: Map out the installation area and mount the lighted mirror Mirror Width housing to the wall.
- Page 5 Step 3: Make wiring connections. Wiring Fixture Disconnect • Séura lighted mirrors are equipped with an easy-to-install Wiring connections made by wiring fixture disconnect that can be found on the mirror the manufacturer housing that is now connected to the wall. Refer to your Field wire connector included drawing package to identify the location of the Connections to be made by...
- Page 6 Installation: Hard-Wired Configuration (continued) Step 4: Hang the mirror See pages 10-12 for instructions to connect optional upgrades (such as touch buttons, mirror defoggers and more) from the housing to the mirror. • If the mirror has a decorative frame, do not hold the mirror by the frame.
- Page 7 Installation: Plug-In Configuration Step 1: Prepare proper wall switch. Wiring Fixture Disconnect • Ensure a Ground Fault Circuit Interrupter (GFCI) outlet is located near the mirror so the plug cord can reach the outlet. We Tab to open recommending the outlet be located within the middle open area wiring fixture of the housing for a clean look without a visible cord.
- Page 8 Installation: Plug-In Configuration (continued) Step 2: Map out the installation area and mount the lighted mirror Mirror Width housing to the wall. X” • Locate the keyhole slots on the lighted mirror housing. The number of keyhole slots depends on the mirror size. You may...
- Page 9 Optional Upgrade: Touch Control Dimming Included with Full Length Lighted Mirrors Curate the desired atmosphere with one touch. Use Séura’s Touch Control Dimming to conveniently change the intensity level anywhere from dreamy low-light to reviving brightness. Séura’s Touch Control Dimming button comes attached to the mirror housing with a wire lead. The button icon is etched into the mirror glass and surrounded by the touch button mounting plate.
- Page 10 Optional Upgrade: Touch Control Color Temperature Touch Control Color Temperature must be paired with Touch Control Dimming. See page 10 for Touch Control Dimming installation and operating instructions. Whether you’re energizing your morning routine with cool, clean white, or winding down for a good night’s sleep with a warm and inviting glow, tune your light color with the in-mirror touch sensor.
- Page 11 For standard hard-wired defogger, no touch control: After mounting the lighted mirror housing and making field wiring connections to the fixture, then it’s time to hard wire the defogger. There are two wires on the back of the mirror that are on the defogger. Using a wire stripper, strip approximately 1/2"...
- Page 12 Optional Upgrade: Night Light Just a warm glow of sleep-inducing low light is all you need, so you can drift back to dreamland easily. This small night light is hidden below the bottom edge of the mirror so it casts light downward and matches your sleek, functional style. The night light can be wired to your control preference.
- Page 13 Optional Upgrade: Touch Control Clock and Dimming Your day begins with reflecting timeliness, and an LED clock conveniently integrated with your mirror keeps you focused so you’re out the door on time. With in-mirror controls, it’s easy to set the time and tune the light to complement your mood or activity. Séura’s Touch Control Clock and Dimming button comes attached to the mirror housing with a wire lead.
- Page 14 Stay on time with an elegant, in-mirror digital clock. Conveniently set and adjust the time with an easy-to-use IR remote. After mounting the lighted mirror housing and making field wiring connections to the fixture, then it’s time to hard wire the digital clock.
-
Page 15: Care And Maintenance
Optional Upgrade: Security Latch Intended for public commercial properties and hotels, Séura’s security latch prevents unwanted tampering and damage to the mirror. After mounting the housing to the wall and before hanging the mirror, move the security latch to the locked position. Then hang the mirror onto the housing. -
Page 16: Limited Product Warranty
LIMITED PRODUCT WARRANTY For information regarding Séura’s warranty policy, please visit our website: www.seura.com/warranty. If the current Séura warranty policy is after your product purchase date, please contact Séura Customer Support to request warranty documentation from the date of your purchase.
