Arenaluci VEGA 12 LED User Manual

This unit should only be used for purpose for
which it has been intended and should be
installed using the instructions which are
provided. Arena Luci cannot be held liable for
damages to person, animals or objects as a
result of improper, unreasonable and wrong
usage.
This instruction manual contains important
information about the installation and use of the
projector. Please read and follow these
instructions carefully.
The security of this device is guaranteed only
with the proper use of the following instructions,
therefore they must be kept carefully.
Never install the device in locations easily
accessible by people who ignore the existence of
this user's manual and safety instructions.
For the wiring please refer to enclosed wiring
diagrams. If in the diagrams indicated there
should not be that of your application, contact the
technical office.
Disconnect the unit from any power supply before
attempting any operation in contact or inside the
unit, and when not in use.
It is essential that each device is correctly
earthed and that electrical installation conforms
to all relevant standards. Never supply the unit
without the earth link.
Prior to connect the unit to the power supply,
check the output voltage fits the technical
requirements on the label.
Never let the power cord come into contact with
other cables.
Please note that as part of Arena Luci's ongoing commitment to continuous product development,
specifications are subject to change in the course of product improvement without notice. Arena Luci is not
responsible for damages resulting from improper or different use than expected.
VEGA 12 LED
User's manual
Recessed carriageable LED inground 230V AC
WARNINGS
Never touch the electrical contacts, either directly
with your fingers, or indirectly by means of sharp
or metal objects.
Make sure that cables cannot cause trip hazard.
Do not attempt to dismantle and modify the unit.
Due to the high technological level of this unit,
any service maintenance should be performed by
specialised operators. Please contact your Arena
Luci dealer for any operation.
When assembling make sure that the cable
glands are tightened for a watertight seal.
Avoid installing the unit close to heat sources.
Never lean the power cord on hot unit surfaces.
Allowed to be mounted directly on inflammable
surfaces.
LED module is not replaceable.
Do not use any solvent based cleaning agents.
Use only a soft, dry anti­static cloth.
The installation of LED modules (including power
supplies) should be done according to current
technical rules and regulations. The installation
should be performed only by a qualified operator.
This luminaire is an outdoor IP67 device, but not
IP68 (underwater). Therefore the proper and
extended functioning will be related to the proper
installation.
To avoid infiltrations inside the inground box do
not open or install this luminaire during rainy
days or in high humidity conditions.
Avoid contact with either corrosive agents or
humidity and moisture on delicate elements:
damages from corrosion are not refunded as
component defects.
12 out
ING0012­WW
ING0012­W
