- Page 1 DSI-5A-D9M ADAPTER TECHNICAL REFERENCE MANUAL DSI-5A-D9M V20-1 1 ...
-
Page 2: Table Of Contents
8.2. General Safety Instructions 13 8.2.1. Environmental Considerations 13 8.2.2. Product End-of-Life Handling 13 8.2.3. System and Components Recycling 13 8.2.4. General safety and hazard warnings for all Dewesoft systems 14 9. Documentation Version 17 DSI-5A-D9M V20-1... -
Page 3: About This Document
It gives you important information about the subject. Please read carefully! Hint It gives you a hint or provides additional information about a subject. Example Gives you an example of a specific subject. DSI-5A-D9M V20-1 3/17 ... -
Page 4: Technical Data
Resistor dielectric withstanding voltage 1000Vac Input connector type MSTB 2,5/ 3-STF-5,08 Phoenix Contact, mates with MSTB 2,5/ 3-GF-5,08 Connector info 2.5mm 2 Nominal cross section TEDS DSI Compatible Do not exceed the absolute maximum rating! DSI-5A-D9M V20-1 4/17 ... -
Page 5: Connectors
Current Input - 2 + I, Power Current Input + 3 G I, Signal Analog Ground Illustration 1: 3 pin plug Illustration 2: The illustration shows a 10-position version of the plug DSI-5A-D9M V20-1 5/17 ... -
Page 6: Output Connector Pinout
OE- I, Power Output enable - 9 TEDS I/O, Signal TEDS 5. Safety instructions Your safety is our primary concern! Please be safe! Warning Use DSI-5A-D9M adapter only with SIRIUSi - Isolated version. DSI-5A-D9M V20-1 6/17 ... -
Page 7: Operation
Since there is an built-in TEDS device in the adapter itself and if DSI adapters/TEDS sensors under Settings are selected, adapters will be recognised and parameters will be set automatically. Please check if Dewesoft enables scanning for DSI adapters. DSI-5A-D9M V20-1... -
Page 8: Dsi Adapters / Teds Sensor Support
DSI-5A-D9M TECHNICAL REFERENCE MANUAL Illustration 6: Setting – Hardware setup Illustration 7: DSI adapters/TEDS sensors checkbox DSI-5A-D9M V20-1 8/17 ... -
Page 9: Manual Operation
DSI-5A-D9M TECHNICAL REFERENCE MANUAL Illustration 8: DSI-5A-D9M adapter is recognized and set automatically 6.1.1. Manual operation If DSI adapters/TEDS sensors are left unchecked under Hardware setup then sensor supply and range has to be set manually. ... - Page 10 Under Channel setup for channel N, set Excitation voltage to 15V. Signal Output Enable indicator LED will be turned on to indicate that measured signal is present on the signal outputs. Illustration 10: Excitation voltage setting DSI-5A-D9M V20-1 10/17 ...
-
Page 11: Warranty Information
7.2. Support Dewesoft has a team of people ready to assist you if you have any questions or any technical difficulties regarding the system. For any support please contact your local distributor first or Dewesoft directly. ... -
Page 12: Copyright
When used in text representing the company, product or technology name, the ® sign is not used. The Dewesoft triangle logo is a registered trademark but the ® sign is not used in the visual representation of the triangle logo. ... -
Page 13: Safety Instructions
Failure to comply with these precautions or with specific warnings elsewhere in this manual violates safety standards of design, manufacture, and intended use of the product. Dewesoft GmbH assumes no liability for the customer’s failure to comply with these requirements. ... -
Page 14: General Safety And Hazard Warnings For All Dewesoft Systems
REMOVE POWER and do not use the product until the safe operation can be verified by service-trained personnel. If necessary, return the product to Dewesoft sales and service office for service and repair to ensure that safety features are maintained. ... - Page 15 This product has left the factory in safety-related flawlessness and in proper condition. In order to ● maintain this condition and guarantee safety use, the user has to consider the security advice and warnings in this manual. DSI-5A-D9M V20-1 15/17 ...
- Page 16 Devices and systems according to IEC 61508 or IEC 61511 which are considered as “operationally well-tried”, are excluded from the scope of IEC 61326-3-1. Fire-alarm and safety-alarm systems, intended for the protection of buildings, are excluded from the scope of IEC 61326-3-1. DSI-5A-D9M V20-1 16/17 ...
-
Page 17: Documentation Version
TECHNICAL REFERENCE MANUAL 9. Documentation Version Doc-Version Date Notes [dd.mm.yyyy] 0.9 09.05.2014 Pre-release version 1.0 21.05.2014 Initial version, amended electrical specs., new safety instructions, new schematic. V20-1 04.09.2020 New template. Change MSI-5A to DSI-5A-D9M DSI-5A-D9M V20-1 17/17 ...
