PRODUCT ASSEMBLY

Position two part A side panels upside down with the ball entry hole closer to the floor. Attach
1
a part B end panel with four part 2 screws.
Flip part C soccer playfield upside down and slide it into the designated slots.
C
2
Attach another part B end panel and two part D bottom supports with eight part 2 screws.
x8
2
3
Flip the game table over. Attach two part E goal boxes with eight part 1 screws.
6 |
Please retain these instructions for future reference.
A
x2
2
x4
B
D
x2
B
x2
x8
E
1
