Southland SM2119 Operator's Manual

Walk-behind lawn mower

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Look Inside for:

Specifications

Safety Definitions

Important Safety Information

Parts & Features

Assembly

Operation

Maintenance

Storage

Troubleshooting

Technical Service

Warranty

Repair Parts

IMPORTANT:

This manual provides complete instructions for safely operating and maintaining your mower. Read and save these

instructions. Refer to this manual each time before using your mower.

Record the following for future reference:

Model No: ___________________

Mfg. Date Code: ______________________

Date of Purchase: Attach a copy of your sales receipt.

Consumer Toll Free Number: 1-800-737-2112

Refer to the website for electronic manual and parts book.

If you have a question or problem...

CALL TOLL FREE: 1-800-737-2112

KEEP THIS MANUAL FOR FUTURE REFERENCE

04/05/2013

Operator's Manual

WALK-BEHIND

LAWN MOWER

Page

4-5

8-9

10-12

13-15

17-19

20-22

www.southlandpowerequipment.com

Printed in the USA

MODEL NO

SM2119

A202217

Table of Contents

Need help?

Do you have a question about the SM2119 and is the answer not in the manual?

Questions and answers

Summary of Contents for Southland SM2119

Page 1 Operator’s Manual WALK-BEHIND LAWN MOWER MODEL NO SM2119 Look Inside for: Page Specifications Safety Definitions Important Safety Information Parts & Features Assembly Operation 10-12 Maintenance 13-15 Storage Troubleshooting Technical Service Warranty 17-19 Repair Parts 20-22 IMPORTANT: This manual provides complete instructions for safely operating and maintaining your mower. Read and save these instructions.
Page 2: Specifications
Specifications MODEL SM2119 Cutting Width 21 in (533 mm) 1˝ to 3-3/4˝ (25.4-95.3 mm) Cutting Depths 3-position height adjust 25-30 ft/lbs Blade Bolt Torque Unit Weight 60 lb (27.2 kg) Gasoline Type Regular Unleaded, >=87 Octane Fuel containing Ethanol > 10% is not recommended.•...
Page 3: Safety Definitions
Safety Definitions • Save all instructions Become familiar with and understand the meaning of the warning symbols found on your mower. Safety Warning Symbols Do not mow when children or others are Indicates WARNING, DANGER, or CAUTION. Use common sense. Watch what you are doing. around.
Page 4: Important Safety Information
Important Safety Information • Save all instructions DANGER Carbon Monoxide. Using an engine indoors can kill you in minutes. Engine exhaust contains high levels of car- bon monoxide (CO), a poisonous gas you cannot see or smell. You may be breathing CO even if you do not smell engine exhaust.
Page 5: Safe Handling Of Gasoline
Important Safety Information (Continued) • Save all instructions • Never attempt to make wheel height adjustments while III. CHILDREN the engine is running. Tragic accidents can occur if the operator is not alert to the • Grass catcher components are subject to wear, damage, presence of children.
Page 7: Parts And Features
Parts & Features • Save all instructions Read, understand, and follow all instructions on the machine and in the manual(s) before starting. To be able to operate your mower safely and get the best performance, become familiar with the controls and the proper use of the machine before starting.
Page 8 Assembly If you need assistance or find any parts missing, CALL • Save all instructions TOLL FREE: 1-800-737-2112. NOTE: All references to right or left side of the mower are from the operator’s position behind the unit. IMPORTANT: The assembly instructions were written for persons with some mechanical ability and experience. All steps are not included in these instructions.
Page 9 Assembly (Continued) If you need assistance or find any parts missing, CALL • Save all instructions TOLL FREE: 1-800-737-2112. HANDLE ASSEMBLY (FIG. 2-4) NOTE: The handle screws (M) in the bottom holes of the IMPORTANT: Unfold handles being careful not to pinch or handle brackets were left loose for shipping purposes.
Page 10: Operation
Operation • Save all instructions Read, understand, and follow all instructions on the ma- Fig. 5 chine and in the manual(s) supplied before starting. Be thoroughly familiar with the controls and the proper use of the machine before starting. The operation of any mower can result in for- eign objects being thrown into the eyes, which can result in severe eye damage.
Page 11: Add Gasoline
Operation (Continued) • Save all instructions ADD OIL WARNING Refer to the separate Engine Owner’s manual for addi- To avoid personal injury or property damage, use tional engine information. extreme care when handling gasoline. Gasoline is ex- tremely flammable and the vapors are explosive. Do not CAUTION smoke or allow smoking near fuel or the mower.
Page 12: Mowing Tips
Operation (Continued) • Save all instructions TO START THE ENGINE (FIG. 7) MOWING TIPS NOTE: Due to protective coatings on the engine, a small Thoroughly inspect the area where the mower is to be used amount of smoke may be present during the initial use of and remove all foreign objects such as rocks, wire, toys, etc.
Page 13: Maintenance
Maintenance • Save all instructions CLEANING WARNING IMPORTANT: For best performance, keep mower hous- In order to prevent accidental starting when setting up, ing free of grass build-up and trash. Clean the underside of transporting, adjusting or making repairs, always discon- your mower after each use.
Page 14: Blade Care
Maintenance (Continued) • Save all instructions ENGINE TO REMOVE BLADE (FIG. 8) A list of key engine maintenance items required for good 1. Disconnect spark plug wire from spark plug and place performance is listed here. Consult the separate Engine wire where it can not come in contact with plug.
Page 15: To Sharpen Blade
Maintenance (Continued) • Save all instructions • The blade can be sharpened with a file or on a grinding IMPORTANT: Blade bolt is heat treated. If bolt needs re- placing, replace only with approved bolt shown in the wheel. Do not attempt to sharpen while on the mower. Repair Parts section of this manual.
Page 16: Troubleshooting
Troubleshooting PROBLEM POSSIBLE CAUSE(S) SOLUTION(S) Engine will not start (see the 1. Fuel tank is empty 1. Add fresh fuel. separate Engine Owner’s Manual 2. Blade control lever is not depressed 2. Grasp and hold blade control lever firmly against for further engine troubleshooting) handle while pulling starter rope handle.
Page 17: Technical Service
• Date of Purchase (include copy of receipt for written requests) • Your Address • Your Phone Number Warranty Southland MOWER Limited Warranty ® Always specify model number when contacting the factory. We reserve the right to amend these specifications at any time without notice. The only warranty applicable is our standard written war- ranty.
Page 18 Warranty (Continued) Manufacturer’s Warranty Coverage The emissions control system is warranted for two years. If any emissions-related part on your engine is defective, the part will be re- paired or replaced by METL. Owner’s Warranty Responsibility As the power equipment engine owner, you are responsible for the performance of the required maintenance listed in your owner’s manual.
Page 19 Warranty (Continued) Exclusions Failures other than those resulting from defects in material or workmanship are not covered by this Emission Control System Warranty. This Emission Control System Warranty does not extend to emission control systems or parts which are affected or damaged by owner abuse, neglect, improper maintenance, misuse, mis-fueling, improper storage, accident and/or collision, the incorporation of, or any use of, any unapproved, add-on, modified, “graymarket”...
Page 21 Repair Parts SM2119 LAWN MOWER REPAIR PARTS Item Component No. Description Deck 21˝ A202183 A202185 Bracket 4 Hole Rt Front Wheel A202184 Bracket 4 Hole Lt Front Wheel A202187 Bracket 4 Hole Rt Rear Wheel A202186 Bracket 4 Hole Lt Rear Wheel...
Page 22 Repair Parts Decal Group Item Part No. Description Label, Decorative (SOUTHLAND/HONDA) A202207 A202250 Label, Decorative (Cyclonic Force) A202275 Label, Decorative (Made in USA) A202268 Label, Decorative (139CC Magna Force) A202448 Label, Cut Finger Questions? Call Toll Free at 1-800-737-2112 ENG - 22...
