Changing the
Camera Screw Fixing
1. Remove the knob
retaining screw.
2. Remove knob by
turning anti-clockwise.
3. Remove the camera
fixing screw from the
slot.
4. Change the camera
fixing bolt for the
alternative size.
5. Replace the knob
by turning clockwise,
then replace the
retaining screw and
retighten.
autocue.com
Specifications
Models
Medium
760
Folded Height
(mm)
1575
Max. Operating
Height (mm)
720
Minimum Height
(mm)
4.2
Net Weight (Kg)
6
Max. Load
Capacity (Kg)
-85/90
Tilt Range
(degrees)
360
Pan Range
(degrees)
60
Ball Base (mm)
Quick attachment & release
Camera Fixing
slide system, 3/8" and 1/4"
camera screw
Aluminium
Material
Heavy
Tripod
Heavy
910
1750
810
9.3
18
-85/85
360
70
Aluminium
Guide
