What This Document Contains
RocketPort® Serial Hub ia (RPSH-ia) Hardware Installation
RocketPort
Hardware Installation
The RocketPort Serial Hub ia is a DIN-rail mountable (24V) serial
communications device that easily connects to a 10/100 Base-T Ethernet hub,
switch, or network interface card (NIC).
The RocketPort Serial Hub ia uses a RISC processor to process asynchronous
serial communications, thereby maximizing performance and eliminating
throughput bottlenecks.
RocketPort Serial Hub ia features include:
•
Two DB9 software selectable RS-232, RS-422, or RS-485 asynchronous serial
ports.
•
Configurable network protocol, allowing the RocketPort Serial Hub ia to use
IP or MAC (media access control) addressing.
Note: See the
Software Installation
information.
•
An optional 24VDC power supply that supports input voltages between 100-
240VAC and 50 or 60 Hz operation.
•
Auto polarity selection for network connection.
•
Diagnostic LEDs.
Some drivers feature:
•
Multi-server port assignment, permitting the sharing of this device with
multiple servers. Each individual server can be configured for MAC or IP
addressing.
•
Port sharing among servers. The same port can be used for multiple servers.
Use this document to:
•
Install
the RocketPort Serial Hub ia.
•
Verify
that the RocketPort Serial Hub ia passes the hardware diagnostics
during the power up phase.
•
Add
additional units to an existing RocketPort Serial Hub ia environment.
•
Build cables or loopback
-
An ethernet crossover cable, if you are connecting the RocketPort Serial
Hub ia directly to a NIC card (not included).
-
Null-modem cable for the peripheral devices that you are connecting to the
RocketPort Serial Hub ia (not included).
-
RS-232/422 loopback plug (one included).
•
Troubleshoot
installation or configuration problems.
•
Review the RocketPort Serial Hub ia
•
Contact
Comtrol™ or download updated software or documentation.
See the appropriate
Software Installation
information.
®
Serial Hub ia (RPSH-ia)
documentation for MAC or IP addressing
plugs, including:
specifications
documentation for software installation
and
agency
notices.
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Comtrol RocketPort Serial Hub ia
Summary of Contents for Comtrol RocketPort Serial Hub ia
- Page 1 The RocketPort Serial Hub ia is a DIN-rail mountable (24V) serial communications device that easily connects to a 10/100 Base-T Ethernet hub, switch, or network interface card (NIC). The RocketPort Serial Hub ia uses a RISC processor to process asynchronous serial communications, thereby maximizing performance and eliminating throughput bottlenecks.
-
Page 2: Connecting To The Network
4.75” above the unit and a minimum of 2.0” below. 2.0” 3. Attach the RocketPort Serial Hub ia to a standard DIN rail or the DIN rail section mounted in Step 2. 0.5” 0.5”... - Page 3 4. Connect an Ethernet cable from the port labeled Network on the RocketPort Serial Hub ia to your server NIC card (10/100Base-T) or Ethernet hub. Note: If connecting the RocketPort Serial Hub ia directly to a NIC, an Ethernet crossover cable is required.
-
Page 4: Verifying The Hardware Installation
Adding a Unit to an Existing Installation Use this procedure to add another RocketPort Serial Hub ia to an existing configuration. 1. Install the RocketPort Serial Hub ia to an Ethernet hub or NIC card using the Connecting to the Network discussion. -
Page 5: Replacing Hardware
Use this procedure to replace a RocketPort Serial Hub ia with another RocketPort Serial Hub ia in an existing configuration. 1. Disconnect the power from the RocketPort Serial Hub ia that is to be removed from service. 2. Remove the old unit and attach a new or spare RocketPort Serial Hub ia. -
Page 6: Connecting Devices
1. Install or reconfigure the driver using the Software Installation documentation or the driver readme file. 2. Connect your devices to Ports 1 or 2 for each RocketPort Serial Hub ia using the appropriate cable. You can build your own cables using the Building Null-... -
Page 7: Db9 Connector Pinouts
DB9 Connector Pinouts DB9 Connector Pinouts Use the following pinout information for the DB9 serial port Pin 1 Pin 5 connectors on the RocketPort Serial Hub ia. Pin RS-232 RS-422 RS-485 Pin 9 Pin 6 Not used Not used DB9 Male... - Page 8 Terminal (WCOM32) program. Linux users can use MiniCom. See the driver documentation for your driver for information about using these applications. The RocketPort Serial Hub ia is shipped with a a single loopback plug (RS-232/ 422). This information can help you build additional plugs or replace a missing loopback.
-
Page 9: Hardware Specifications
Building an RS-485 Test Cable Building an RS-485 Test Cable You can use a straight-through cable as illustrated previously, or build your own cable. RS-485 Loopback Cable for WCOM or MiniCom Signal Pins Pins Signal TxD or TRX- TxD or TRX- RTS or TRX+ RTS or TRX+ Note: The RS-485 loopback cable only requires... - Page 10 Notices The following table illustrates hardware specifications. Hardware Topic Specifications Current consumption 180 mA (24VDC) Input voltage 20 - 28VDC Power consumption 2.8 W Optional power supply: Line frequency 50 - 60 Hz Line voltage 100 - 240VAC 10/100Base-T (10/100 Ethernet host interface Mbps - RJ45) OS dependent, see the...
-
Page 11: Technical Support
All Rights Reserved. Comtrol Corporation makes no representations or warranties with regard to the contents of this document or to the suitability of the Comtrol product for any particular purpose. Specifications subject to change without notice. Some software or features may not be available at the time of publication. Contact your reseller for current product information.
