- Page 1 Artisan Technology Group is your source for quality new and certified-used/pre-owned equipment SERVICE CENTER REPAIRS WE BUY USED EQUIPMENT • FAST SHIPPING AND DELIVERY Experienced engineers and technicians on staff Sell your excess, underutilized, and idle used equipment at our full-service, in-house repair center We also offer credit for buy-backs and trade-ins •...
- Page 2 Comtrol Cable User Guide Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
- Page 3 Copyright © 2005. Comtrol Corporation. All Rights Reserved. Comtrol Corporation makes no representations or warranties with regard to the contents of this document or to the suitability of the Comtrol product for any particular purpose. Specifications subject to change without notice.
-
Page 4: Table Of Contents
RS-232 Null-Modem Cable ....................... 11 RS-422 Null-Modem Cable ........................ 11 DB9 Straight-Through Cables ......................... 12 RS-232 Straight-Through Cable......................12 DB25 Serial Cables and Loopback Plugs ....................12 Requirements ............................12 DB25 Pinouts ............................12 DB25 Loopback Plugs..........................14 RS-232 Female Loopback Plug ......................14 RS-422 Female Loopback Plug ...................... - Page 5 RocketPort 4/8/16 Interface Cable Assembly Wire Detail ..............25 RocketPort 32 ISA, PCI 32, uPCI 16/32, and CPCI 16 Interface Cable Assembly Wire Detail ... 26 DB25 Interface to Controller Pinouts for RocketPort ISA/PCI 4, 8 and 16-ports ......27 Wire ................................27 Shield.................................
-
Page 6: Getting Started
RJ45 4000036 10” 0.25 a. This is a 3 foot cable. If necessary, you can connect a 10 foot DB25 to DB25 cable to extend the length of the cable. Getting Started [Documentation number: 2000430 Rev B] 5 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com... -
Page 7: Dte Versus Dce
DTE versus DCE Most devices, except modems, are Data Terminal Equipment (DTE) devices. Modems are Data Communication Equipment (DCE) devices. Comtrol ports are configured as DTE. How you build a cable depends on which device your are connecting to (DTE or DCE). -
Page 8: Data-Only Null-Modem Cables
If the Comtrol device falls within the limits for a Class A computing device established by the FCC, the serial cables used to connect the Comtrol device to the external devices must be shielded. The cable shield must connected to the chassis ground at both ends to reduce EMI. - Page 9 Shielded vs. Unshielded 8 [Documentation number: 2000430 Rev B] Getting Started Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
-
Page 10: Building Cables For Rocketport Products
This chapter describes the cables and pinouts for RocketPort products and covers the following topics: • DB9 Serial Cables and Loopback Plugs • DB25 Serial Cables and Loopback Plugs • RJ11 Serial Cables and Loopback Plugs • RJ45 Serial Cables and Loopback Plugs... - Page 11 DB9 Pinouts The following figures and tables illustrate the signals present on DB9 connectors. DB9 Female for SMPTE DB9 Male for Quad/Octa DB9 Female Pin 1 Pin 5 Pin 1 Pin 1 Pin 5 Pin 5 Pin 9 Pin 6 Pin 9 Pin 9 Pin 6...
-
Page 12: Db9 Loopback Plugs
COM2 on another computer. All RocketPort models support DB9 null-modem cables. RS-232 Null-Modem The following image displays the pinouts for an RS-232 null-modem cable. Cable Customer DTE DB25 Signal Pins Pins Pins Signal Note: You can also attach a null-modem adapter to one end of a straight-through cable to create a null-modem cable. -
Page 13: Db9 Straight-Through Cables
Refer to the manufacturer’s installation guide if you need help with connector pinouts or cables for the peripheral device. DB25 Pinouts This topic describes pinouts for the DB25 interface connectors. The following RocketPort models support DB25 connectors: • RocketPort PCI •... - Page 14 DB25 Pinouts This table shows connector information for DB25 connectors. Interface Modules Quad/Octacable RS-232 Signal RS-422 Signal RS-232 Signal Not used Not used Not used Not used Not used Not used Not used Not used Signal ground Signal ground Signal ground...
-
Page 15: Db25 Loopback Plugs
RocketPort Universal PCI • RocketPort Plus Universal PCI • RocketPort ISA Quadcable and Octacable use the RS-232 female loopback plug. To build a DB25 loopback plug for an Pin 1 Pin 13 Quadcable or Octacable, wire the following pins together: Pin 14 Pin 25 •... -
Page 16: Rj11 Serial Cables And Loopback Plugs
• Supported RS-modes are described in the electronic document shipped with your Comtrol device. RJ11 Pinouts This topic describes pinouts for the RJ11 interface connector for an RS-232 port. The following figures provide pinout information for the RJ11 jack plug and... -
Page 17: Rj45 Serial Cables And Loopback Plugs
Refer to the manufacturer’s installation guide if you need help with connector pinouts or cables for the peripheral device. • Supported RS-modes are described in the electronic document shipped with your Comtrol device. RJ45 Pinouts RJ45 Pinouts for The following RocketPort models support the octacable interface module (RS-232): Octacable Interface •... -
Page 18: Rj45 Null-Modem Cables
RocketPort PCI • RocketPort Universal PCI • RocketPort Plus Universal PCI The following image displays the pinouts for an RS-232 null-modem cable. Customer DTE RJ45 DB25 Signal Pins Pins Pins Signal Important: RJ45 pinouts are not standardized. Each peripheral manufacturer uses different pinouts. -
Page 19: Rj45 Loopback Plugs
RJ45 Loopback Plugs RJ45 Loopback A loopback plug is an RJ45 serial port plug with pins wired together. You can use Plugs it with application software (for example, Test Terminal) to test serial ports. The following RocketPort models support RJ45 loopback plugs: •... -
Page 20: Building Cables For Devicemaster Products
Building Cables for DeviceMaster Products Overview This chapter describes the cables and pinouts for DeviceMaster products and covers the following topics: • DB9 Serial Cables and Loopback Plugs • RJ45 Serial Cables and Loopback Plugs DB9 Serial Cables and Loopback Plugs This section describe how to build your own null-modem or straight-through DB9 serial cables and loopback plugs. -
Page 21: Db9 Pinouts
DB9 Pinouts DB9 Pinouts The following figure and table illustrates the DB9 connector signals. DB9 Male for RS-232, RS-422, and RS-485 Pin 1 Pin 5 Pin 6 Pin 9 Pinouts for Standard DB9 Connector RS-232 Mode RS-422 DCE Mode RS-485 Mode Not used Not used RxD-... -
Page 22: Db9 Null-Modem Cable
COM2 of one computer and the other end of the null-modem cable to COM2 of another computer. RS-232 Null-Modem The following image displays the pinouts for an RS-232 null-modem cable. You Cable need a null-modem cable to connect to DTE devices. DB25 RJ45 Signal Pins Pins Pins... -
Page 23: Rs-232 And Rs-485 Straight-Through Cable For Devicemaster Air, Pro, Rts Or Up
RS-232 and RS-485 Straight-Through Cable for DeviceMaster AIR, PRO, RTS or UP RS-232 and RS-485 The following image displays the pinouts for an RS-232 or RS-485 straight- Straight-Through through cable. Cable for RJ45 DB25 DeviceMaster AIR, Signal Pins Pins Pins Pins... -
Page 24: Rj45 Null-Modem Cable
COM2 on a computer and the other end of the null-modem cable to COM2 on another computer. RS-232 Null-Modem The following image displays the pinouts for an RS-232 null-modem cable. Cable RJ45 DB25 RJ45 Signal Pins Pins Pins... -
Page 25: Rj45 Loopback Plug
RJ45 Loopback Plug RJ45 Loopback Plug A loopback plug is an RJ45 serial port plug with pins wired together. You can use it with application software (for example, Test Terminal or MiniCom) to test serial ports. The RS-232/422 single loopback plug is shipped with the following DeviceMaster models: DeviceMaster RTS, DeviceMaster PRO and DeviceMaster UP. -
Page 26: Building Basic Cables
• RocketPort 32 ISA, PCI 32, uPCI 16/32, and CPCI 16 Interface Cable Assembly Wire Detail • DB25 Interface to Controller Pinouts for RocketPort ISA/PCI 4, 8 and 16-ports • 78-pin Connectors RocketPort 4/8/16 Interface Cable Assembly Wire Detail Destination DB25... -
Page 27: Rocketport 32 Isa, Pci 32, Upci 16/32, And Cpci 16 Interface Cable Assembly Wire Detail
RocketPort 32 ISA, PCI 32, uPCI 16/32, and CPCI 16 Interface Cable Assembly Wire Detail RocketPort 32 ISA, PCI 32, uPCI 16/32, and CPCI 16 Interface Cable Assembly Wire Detail Destination DB25 Source DB26 Male Base Color/Band Color Twisted Pair #... -
Page 28: Db25 Interface To Controller Pinouts For Rocketport Isa/Pci 4, 8 And 16-Ports
DB25 Interface to Controller Pinouts for RocketPort ISA/PCI 4, 8 and 16-ports DB25 Interface to Controller Pinouts for RocketPort ISA/PCI 4, 8 and 16-ports Function RXCLK+ RXCLK- RXDAT+ RXDAT- RXDAT1+ RXDAT1- RXCNVT+ RXCNVT- TXCLK+ TXCLK- TXDAT+ TXDAT- TXDAT1+ TXDAT1 TXCNVT+... -
Page 29: 78-Pin Connectors
78-pin Connectors 78-pin Connectors 78-pin Connector for The following table lists the pinouts for a 78-pin connector. The 78-pin connector is RS-232 Quadcable/ available on the following RocketPort models: Octacable • RocketPort PCI quadcable and octacable. Controllers • RocketPort Universal PCI quadcable and octacable. •... -
Page 30: 78-Pin Connector For Rs-422 Quadcable/Octacable Controllers
78-pin Connector for RS-422 Quadcable/Octacable Controllers 78-pin Connector for The following table lists the pinouts for a 78-pin connector. The 78-pin connector is RS-422 Quadcable/ available on the following RocketPort models: Octacable • RocketPort PCI 422 quadcable, octacable and SMPTE. Controllers •... - Page 31 78-pin Connector for RS-422 Quadcable/Octacable Controllers 30 [Documentation number: 2000430 Rev B] Building Basic Cables Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
-
Page 32: Cable Adapters
8J RJ11 to Standard DB9 (Null-modem Configuration) RJ45 to DB9 Connector Pinouts for DeviceMaster and RocketPort The following table displays the modem wiring connection from a Comtrol RJ45 connector to a standard DB9 connector. Note: If your DB9 wiring differs from the one shown below, adjust the DB9 pinouts accordingly. -
Page 33: Rj11 To Standard Db25 (Null-Modem Configuration)
8J RJ11 to Standard DB25 (Null-modem Configuration) The following table displays the modem wiring connection from a Comtrol 8J RJ11 to a standard DB25 connector. Note: If your DB25 wiring differs from the one shown below, adjust the DB25 pinouts accordingly. 8J RJ11 Connector Pinouts... -
Page 34: Technical Support
Technical Support Comtrol has a staff of support technicians available to help you. In the US, telephone support is available during standard weekday business hours (Central Standard Time, excluding holidays). If you need technical support, contact Comtrol by using one of the following methods:... - Page 35 34 [Documentation number: 2000430 Rev B] Technical Support Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
-
Page 36: Index
Index All DeviceMaster models Cable adapters All RocketPort models 8J RJ11 to standard DB25 RJ45 8J RJ11 to standard DB9 Loopback plug for Overview DeviceMaster PRO, RTS or UP Cables Null-modem cable for RS-232 DeviceMaster PRO, RTS or UP DB25... - Page 37 RocketPort ISA Phone RocketPort PCI RocketPort Plus Universal PCI RocketPort Universal PCI Requirements for DB9 for DB25 serial cables and loopback plugs All DeviceMaster models DB9 serial cables and loopback plugs DeviceMaster PRO, RTS or UP DeviceMaster RJ11 for RocketPort...
- Page 38 Null-modem cable for sal PCI DeviceMaster PRO, RTS or UP Straight-through cable RocketPort PCI, Universal PCI or Plus Univer- RS-422 sal PCI DB25 loopback plug Pinouts for the octacable interface module (RS- Female 232) for Male RocketPort PCI RocketPort Plus Universal PCI...
- Page 39 38 [Documentation number: 2000430 Rev B] Index Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
- Page 40 Artisan Technology Group is your source for quality new and certified-used/pre-owned equipment SERVICE CENTER REPAIRS WE BUY USED EQUIPMENT • FAST SHIPPING AND DELIVERY Experienced engineers and technicians on staff Sell your excess, underutilized, and idle used equipment at our full-service, in-house repair center We also offer credit for buy-backs and trade-ins •...
