- Page 1 Operating Instructions DEB1200D ElEctronic Ballast DlH1200D DayligHt FixturE...
-
Page 2: Table Of Contents
InStructIonS DEB1200D anD DLH1200D Contents 1. Important information 2. General description of the system 3. Safety precautions Caution: mains voltage! Distance to flammable materials Outdoor operation UV risk Cooling Repair and maintenance Additional precautions 4. Power factor correction (PFC) 5. -
Page 3: Important Information
Keep the operating instructions with the equipment at all times. The manufacturer is not responsible for damage caused by improper use or mishandling. The DEB1200D electronic ballast and the DLH1200D light head are built in accordance with CE and EMV-regulations EN 55015, EN 61547, EN61000-3-2 and -3, safety standards EN 60598-1, EN 60598-2-17, EN 60922, EN60350. -
Page 4: Safety Precautions
3) SAFETY PRECAUTIONS The DLH1200D daylight light head cannot be operated without the DEB1200D elec- tronic ballast. The connecting cable (DPOW1200D) must be used between the elec- tronic ballast and the light fixture. Maximum tilt angle is +/- 90°. -
Page 5: B) Distance To Flammable Materials
Caution: Do not put light into transport case while still hot !! C) OUTDOOR OPERATION The DEB1200D electronic ballast and DLH1200D light head are built according to Safety Class IP23 (wet location). The light head cable and connectors are in accordance with IP67 and can be laid on wet ground provided correct seating of the connector lock rings is assured. -
Page 6: E) Cooling
The electronic ballast must not be operated on humid or wet surfaces. Avoid direct sunlight on the DEB1200D. DLH1200D DAyLIGHT FIxTURE: To prevent the possibility of fire, the DLH1200D light head must be mounted on a light hanger suitable for the load or on a lighting stand of suitable dimension to pre- vent the light head from falling or tipping over. -
Page 7: G) Additional Precautions
C) Use only the following lamps: Use of original Dedolight lamps is recommended: type HMI800HR-SE. This lamp matches perfectly the intricate design of the Dedolight optics. Using the original Dedolight HMI800HR-SE lamp from Osram offers optimal results throughout the entire focusing range. -
Page 8: Stand Fitting
InStructIonS DEB1200D anD DLH1200D D) When installing a new lamp, do not touch the glass envelope of the lamp with bare fingers. Oil and grease residue burn into the quartz housing and lower the life expectancy. Remove the foam or plastic safety cover of the lamp only after placing it in the socket or touch lamp only with a lint-free cloth. -
Page 9: Starting Operation Of The System
InStructIonS DEB1200D anD DLH1200D 7) STARTING OPERATION OF THE SYSTEM A) Local mode Check to make sure that red mains switch is in off position “O“. - Connect light head (with lamp installed) to ballast with 7m connecting cable. - Page 10 InStructIonS DEB1200D anD DLH1200D C) DMX mode - Check to make sure that red mains switch is in off position „O“ - Connect light head (with lamp installed) to ballast with 7m connecting cable. - Connectors are to be secured by the locking rings - Connect external DMx controller to „DMx IN“...
-
Page 11: Operational Elements
InStructIonS DEB1200D anD DLH1200D 8. OPERATIONAL ELEMENTS - DEB1200D Dimming Mode selector 1: - Dimming (450 - 1200 W) - Normal (800 W) - Boost (1200 W) Mode selector 2: Lamp current frequency 50 Hz / 60Hz / 75Hz flickerfree... - Page 12 InStructIonS DEB1200D anD DLH1200D 8. OPERATIONAL ELEMENTS - DLH1200D Meniscuslens Mirror Front Lens Lamp socket Carriage Open door for Lamp replacement Accessory holder Latch for accessory holder Ignitor housing Light head cable Tilt lock lever Stirrup (bale) Ø 1/8“ (28 mm) stand fitting...
- Page 13 InStructIonS DEB1200D anD DLH1200D 8. OPERATIONAL ELEMENTS - DLH1200D Second lock latch for door Lock latch for door Push button light head on Focusing knob Push button light head off Folding handle see page 8 Edition I / May 2012...
-
Page 14: Adjusting Light Intensity
- drive in dim position (400-1200 W) Boost Position (135%) The DEB1200D electronic ballast may be set to the boost position ” ” by the yellow three position switch mode selector 1. This pushes the lamp from 800 W to 1200 W. -
Page 15: Transport
InStructIonS DEB1200D anD DLH1200D 11) TRANSPORT The metal halogen lamps are delivered in a foam protector within a cardboard carton. This material was chosen in order to minimize damage from strong vibration. The lamp should not be removed from the light head before transport. -
Page 16: Connection Diagram: Ballast And The Light Head Cable
InStructIonS DEB1200D anD DLH1200D 12) CONNECTION DIAGRAM: BALLAST AND THE LIGHT HEAD CABLE Schaltbau brown 1,5 mm (18 AWG) blue 1,5 mm white 0,5 mm (20 AWG) grey 0,5 mm red 0,5 mm yellow/green 2,5 mm 13) CONNECTION MAINS CABLE... -
Page 17: Technical Data - Specifications
Weights and Measures: Dimensions: DEB1200D: L = 329 mm (12.45“), W = 228 mm (9.0”), H = 230 mm (9.07“) DLH1200D: L = 292 mm (11.5“), W = 328 mm (12.9”), H = 271 mm (10.7“) DPOW1200D: L = 7 m (23’) -
Page 18: Trouble Shooting
InStructIonS DEB1200D anD DLH1200D 15) TROUBLE SHOOTING A. If the red indicator in the mains switch doesn’t illuminate, the mains outlet or mains cable may be defective. B. If the mains switch can’t be switched on: - mains voltage above 264 V - mains voltage has voltage spikes - short circuit in the ballast. -
Page 19: Warranty
InStructIonS DEB1200D anD DLH1200D 16) WARRANTY Dedotec GmbH warrants to the original purchaser, that this product is free from defects in material and workmanship and agrees to repair or replace, at its option, products which under normal installation and use discloses such defect, provided the... - Page 20 InStructIonS DEB1200D anD DLH1200D Copyright Dedotec GmbH, 2012. All rights reserved. DEDOTEC USA, INC. DEDOTEC optical and 48 Sheffield Business Park mechanical systems GmbH Ashley Falls, MA 01222 Karl-Weinmair-Str. 10 Telephone: (413) 229-2550 80807 Munich / Germany Fax: (413) 229-2556 Phone: 089 / 356 16 01 E-mail: info@dedolight.com...
