Edimax EW-7108PCg Specifications

802.11g Wireless LAN PC Card
802.11g Wireless LAN PC Card
802.11g Wireless LAN PC Card
802.11g Wireless LAN PC Card
IEEE 802.11g/b, WPA Compliant
Taiwan / Headquarters
Edimax Technology Co., Ltd.
TEL : 886-2-2299-5648
FAX : 886-2-2299-5647
sales@edimax.com.tw
China
Beijing Edimax Science &
Technology Co., Ltd.
TEL : 8610-6213-9288
FAX : 8610-6213-9231
sales@edimax.com.cn
U.S.A.
Edimax Computer Company
TEL : 1-408-496-1105
FAX : 1-408-980-1530
sales@edimax.com
Latin America
TEL :1-786-845-8099
FAX :1-786-331-8490
sales_latinamerica@edimax.com
Europe
TEL : 31-499-377344
FAX : 31-499-372647
sales@edimax.nl
U.K.
Edimax Technology (UK) Ltd.
TEL: 44-0-1908-255901
FAX: 44-0-1908-255700
info@edimax.co.uk
：
Features
• Works with both IEEE 802.11b and IEEE 802.11g products.
• High-speed transfer data rate - up to 54Mbps.
• High throughput supports multi-media data bandwidth requirement.
• Supports 64/128-bit WEP, WPA (TKIP with IEEE 802.1x) and AES functions
for high level of security.
• Automatic fallback increases data security and reliability.
• Supports the most popular operating system: Windows 98SE/Me/2000/XP.
• Supports 32-bit Cardbus interface.
Specification：
Product
Standard
Bus Type
Frequency Band
Modulation
Data Rate
Security
Antenna
Drivers
LEDs
Power Consumption
Transmit Power
Receive Sensitivity
Dimension
Temperature
Humidity
Certification
EW-7108PCg
IEEE 802.11g/b
32-bit Cardbus
2.4000~2.4835GHz (Industrial Scientific Medical Band)
OFDM with BPSK, QPSK, 16QAM, 64QAM (11g)
BPSK, QPSK, CCK (11b)
54/48/36/24/18/12/11/9/6/5.5/2/1Mbps auto fallback
64/128-bit WEP Data Encryption, WPA (TKIP with IEEE
802.1x) and AES
Printed Antenna with Diversity System
Windows 98SE/Me/2000/XP
TX/RX, Link
Tx: 350mA, Rx: 250mA
16dBm ~ 18dBm
54Mbps OFDM, 10% PER, -70dBm
11Mbps CCK, 8% PER, -86dBm
1Mbps BPSK, 8% PER, -92dBm
8(H) x 118(W) x 54(D) mm
32~131°F (0 ~55°C)
Max. 95% (NonCondensing)
FCC , CE
EW-7108PCg
