Edimax EA-OD19 Specifications

High Gain Directional Antenna 19dBi for 11b/g System
High Gain Directional Antenna 19dBi for 11b/g System
EA - OD19
EA - OD19
19dBi Directional Antenna for 2.4GHz 802.11b/g
Taiwan / Headquarters
Edimax Technology Co., LTD.
TEL:886-2-7739-6888
FAX:886-2-7739-6887
sales@edimax.com.tw
China
Beijing Edimax Science &
Technology Co., LTD.
TEL:8610-6213-9288
FAX:8610-6213-9231
sales@edimax.com.cn
U.S.A.
Edimax Computer Company
TEL:1-408-496-1105
FAX:1-408-980-1530
sales@edimax.com
Latin America
TEL:1-786-845-8099
FAX:1-786-331-8490
sales_latinamerica@edimax.com
Europe
Edimax Technology Europe B.V.
TEL:31-499-377344
FAX:31-499-372647
sales@edimax.nl
U.K.
Edimax Technology (UK) Ltd.
TEL:44-870-7740226
FAX:44-870-7740227
info@edimax.co.uk
Features
• High gain technology
• Excellent VSWR preference
• Low profile with light weight construction
• Easy installation in outdoor solution
Specifications
Electrical
Specifications
Frequency Range 2.40 to 2.50 GHz
Gain 19dBi
Polarization Linear,
Vertical/ Horizontal
VSWR 1.5 Max : 1
Connector N Jack
Power handling 30 Watts
Pattern (H & V Plane)
HPBW (H Plane)
HPBW (V Plane)
Horizontal (H Plane)
Notes: Specifications are subjected to change at any time without notice.
Mechanical
Specifications
Dimension
Weight
Radome Material
Radome Color
Temperature Storage
Survival wind speed
18 degree
18 degree
Vertical (V Plane)
391 x 391 x 28mm
1.1 kg
ABS Plastic
UV Stabilized
Gray
-45 o C to +50 o C
201 km/hr
