Edimax EA-IO5D Specifications

Indoor Omni
Indoor Omni
5dBi Omni Desktop Antenna
5dBi Omni Desktop Antenna
Detachable Designed for 802.11a/b/g WLAN
Detachable Designed for 802.11a/b/g WLAN
Taiwan / Headquarters
Edimax Technology Co., LTD.
TEL:886-2-7739-6888
FAX:886-2-7739-6887
sales@edimax.com.tw
China
Beijing Edimax Science &
Technology Co., LTD.
TEL:8610-6213-9288
FAX:8610-6213-9231
sales@edimax.com.cn
U.S.A.
Edimax Computer Company
TEL:1-408-496-1105
FAX:1-408-980-1530
sales@edimax.com
Latin America
TEL:1-786-845-8099
FAX:1-786-331-8490
sales_latinamerica@edimax.com
Europe
Edimax Technology Europe B.V.
TEL:31-499-377344
FAX:31-499-372647
sales@edimax.nl
U.K.
Edimax Technology (UK) Ltd.
TEL:44-870-7740226
FAX:44-870-7740227
info@edimax.co.uk
- Directional Antenna
- Directional Antenna
Features
• Increase wireless signal range 50% and more - up to 40 meter
• Complies with 802.11a/b/g wireless LAN for reduce "dead-spots"
• Direct contact to AP/Router without cable loss, pure gain performance
• Antenna base included 1 meter pigtail for connect to the PC or AP
• The antenna base for PC/AP re-location to pick up the best link quality
• Magnetic designed for office partition and hangable bottom for ceiling
Specification
Model NO.
Frequency Range
Gain
VSWR
Impedance
Power Handling
Dimension
Weight
Antenna base cable
Antenna Interface
Horizontal (H Plane)
Notes: Specifications are subjected to change at any time without notice.
ED-IO5D
2.4 GHz - 2.5GHz ; 4900MHz – 5875MHz
5 dBi at 11b/g ; 7dBi at 11a
2.0 : 1 Max
50 Ohms
2 W (cw)
219 x 23 x 14 mm (w/o antenna base)
30 g (w/o antenna base)
GDC-101B (Black); Length: 1M
RP SMA Plug
Vertical (V Plane)
EA-IO5D
Revision 2
