IOtech DaqBoard/3000 Series User Manual

Pci 16-bit, 1 mhz multifunction boards
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
DaqBoard/3000 Series
A Hardware Reference Manual for:
DaqBoard/3000
DaqBoard/3001
DaqBoard/3005
DaqBoard/3006
© 2005, 2006 by IOtech, Inc.
IOtech, Inc.
25971 Cannon Road
Cleveland, OH 44146-1833
Phone: (440) 439-4091
Fax: (440) 439-4093
E-mail (Product Information): sales@iotech.com
E-mail (Technical Support): productsupport@iotech.com
Internet: www.iotech.com
DaqBoard/3000 Series
User's Manual
PCI 16-Bit, 1 MHz
Multifunction Boards
1128-0901
p/n
957593
PCI 16-Bit, 1 MHz Multifunction Boards
1.2
Rev.
Printed in the United States of America
User's Manual
Requires one of the following
Operating Systems:
Windows 2000
Windows XP

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DaqBoard/3000 Series and is the answer not in the manual?

Questions and answers

Related Manuals for IOtech DaqBoard/3000 Series

Summary of Contents for IOtech DaqBoard/3000 Series

  • Page 1 Phone: (440) 439-4091 Fax: (440) 439-4093 E-mail (Product Information): sales@iotech.com E-mail (Technical Support): productsupport@iotech.com Internet: www.iotech.com DaqBoard/3000 Series User’s Manual PCI 16-Bit, 1 MHz Multifunction Boards 1128-0901 Rev. © 2005, 2006 by IOtech, Inc. Printed in the United States of America 957593...
  • Page 3 IOtech, Inc. cannot be held liable for any damages resulting from the use or misuse of this product. Copyright, Trademark, and Licensing Notice All IOtech documentation, software, and hardware are copyright with all rights reserved. No part of this product may be copied, reproduced or transmitted by any mechanical, photographic, electronic, or other method without IOtech’s prior written consent.
  • Page 4 PDF documents. Note that hardcopy versions of the manuals can be ordered from the factory. DaqBoard 3000 Series Contains the DaqBoard/3000 Series hardware-related and software-related chapters. This pdf file, plus the following constitute a complete set of documentation for the DaqBoards discussed.
  • Page 5 DBK Options.pdf The DBK Option Cards and Modules Manual discusses each of the DBK products available at the time of print. The DBK Options document, for the most part, does not apply to DaqBoard/3000 Series boards. 457-0905 Programmers Manual.pdf The programmer’s manual pertains to developing custom programs using Applications Program Interface (API) commands.
  • Page 6 DaqBoard/3000 Series User’s Manual...

  • Page 7: Table Of Contents

    Theory of Operation…… 1-3 Daq Software …… 1-13 2 – Connections and Pinouts Overview …… 2-1 Pinout for DaqBoard/3000 Series Boards …… 2-2 TB-100 Terminal Connector Option …… 2-3 PDQ30 Analog Expansion and DBK215 Connector Options …… 2-4 3 – CE-Compliance Overview ……...
  • Page 8 Detection on an Analog Input, Timer Output Updates …… 6-8 Using the Hysteresis Function …… 6-8 Using Multiple Inputs to Control One DAC Output …… 6-10 7 – Specifications - DaqBoard/3000 Series PDQ30 Appendix A: DBK215 16-Connector BNC Connection Module...
  • Page 9 Cleveland, OH 44146-1833 Phone: (440) 439-4091 Fax: (440) 439-4093 E-mail (Product Information): sales@iotech.com E-mail (Technical Support): productsupport@iotech.com Internet: www.iotech.com DaqBoard Installation Guide For PCI-bus Data Acquisition Boards 1033-0940 Rev. 1033-0940, © 1999 through 2005 by IOtech, Inc. rev. IG-1 918494...
  • Page 10 After the install you can navigate to the DBK manual and other relevant electronic documents from your desktop as follows: Start ⇒ Programs ⇒ IOtech DaqX Software ⇒ DaqBoard 2000 Series Users Note: DaqBoard/1000 Series and DaqBoard/3000 Series boards do not support DBK options.
  • Page 11 Minimum System Requirements Reference Note: Adobe PDF versions of user ® manuals will automatically install onto your Pentium P3 Processor, 500 MHz Windows Operating System hard drive as a part of product support. The RAM: 128 Mbytes default location is in the Programs group, which can be accessed from the Windows Desktop.
  • Page 12 – Install Boards in available PCI Bus-slots Step 2 IMPORTANT: Software must be installed before installing hardware. CAUTION Turn off power to, and UNPLUG the host PC and externally connected equipment prior to removing the PC’s cover and installing the DaqBoard. Electric shock or damage to equipment can result even under low-voltage conditions.
  • Page 13 7. Refer to the figure at the right. Align the groove in the DaqBoard’s PCI edge-connector with the ridge of the desired PCI slot, and with the PC’s corresponding rear- panel slot. 8. Push the board firmly into the PCI slot. The board will snap into position.
  • Page 14 1. Run the Daq Configuration control panel applet. Navigation from the desktop to the applet is as follows: Start ⇒ Settings ⇒ Control Panel ⇒ Daq*Configuration (double-click) 2. Double-click on the Device Inventory’s DaqBoard1K0, 2K0, or 3K0 icon, as applicable. The DaqBoard’s Properties tab will appear.
  • Page 15 At this point we are ready to connect signals. • For DaqBoard/1000 Series and DaqBoard/3000 Series boards, connection is typically made via a terminal board, such as the optional TB-100, a DBK215 module via a 68-pin SCSI connector and/or or a PDQ30 via a HDMI connector. However, note that the DaqBoard/3006 has no HDMI connector and cannot be connected to a PDQ30.
  • Page 16 DaqBoard Installation Guide 1033-0940, rev 8.0 IG-8 918494...

  • Page 17: Device Overviews

    For board details refer to Chapter 6, Specifications. Block Diagrams Block Diagram for DaqBoard/3000 and /3001 Note: DaqBoard/3000 has two 16-Bit Digital-to-Analog Converters. DaqBoard/3001 has four 16-Bit Digital-to-Analog Converters. DaqBoard/3000 Series User’s Manual Daq Systems and Device Overviews 1-1 988093...

  • Page 18: Connections

    The HDMI connector can be used to connect a PDQ30 analog expansion module to a DaqBoard/3000 Series board. Details are provided in Chapter 2 of this manual. Cable CA-266-3 (3 ft.) [or CA-266-6 (6 ft.)] is used to connect the PDQ30 to the 3000 Series board.

  • Page 19: Product Features

    Timing mode: can measure the time between two counter inputs to 20.83 nsec resolution o Self-calibration The DaqBoard/3000 series offers up to 12-MHz scanning of all digital input lines. Digital inputs and counter inputs can be synchronously scanned [along with analog inputs] but do not affect the overall A/D rate because they use no time slot in the scanning sequencer.
  • Page 20 Note: The HDMI connector is not present on the DaqBoard/3006. Analog Input The DaqBoard/3000 series has a 16-bit, 1-MHz A/D coupled with 16 single-ended, or 8 differential analog inputs. Seven software programmable ranges provide inputs from ±10V to ±100 mV full scale [with exception of DaqBoard/3006 which has a fixed single-ended range of ±10V.] Each channel can be...
  • Page 21 Notice that some of the analog channels in the scan group are from a PDQ30 expansion module. All analog channels are sampled at the same rate of 1us. Analog channels on the PDQ30 can also have any of the gain ranges applied. DaqBoard/3000 Series User’s Manual Daq Systems and Device Overviews 1-5 988093...
  • Page 22 Auto zero channels read a shorted analog input that is internal to the PDQ30. Auto zeroing reduces drift due to fluctuating ambient temperatures or ambient temperatures outside the DC specifications. Daq Systems and Device Overviews DaqBoard/3000 Series User’s Manual 988093...
  • Page 23 166,666 Hz then the data bandwidth streaming into the PC is 2.167 MSamples per second. Some slower PCs may have a problem with data bandwidths greater than 6 MSamples per second. DaqBoard/3000 Series User’s Manual Daq Systems and Device Overviews 1-7...
  • Page 24 MSamples per second. Analog Input & Channel Expansion The DaqBoard/3000 series has a 16-bit, 1-MHz A/D coupled with 16 single-ended, or 8 differential analog inputs. Seven software programmable ranges provide inputs from ±10V to ±100 mV full scale. Each channel can be software-configured for a different range, as well as for single-ended or differential bipolar input.
  • Page 25 Bus Mastering DMA to efficiently conduct I/O from the PC to the DaqBoard. Triggering Triggering can be the most critical aspect of a data acquisition application. The DaqBoard/3000 series supports a full complement of trigger modes to accommodate any measurement situation.
  • Page 26 Driver support only. Calibration Every range of a DaqBoard/3000 Series device is calibrated at the factory using a digital NIST traceable calibration method. This method works by storing a correction factor for each range on the unit at the time of calibration.
  • Page 27 Digital outputs can be updated asynchronously at anytime before, during or after an acquisition. Two of the 8-bit ports can also be used to generate a 16-bit digital pattern at up to 12 MHz. The DaqBoard/3000 Series boards support digital pattern generation via Bus Mastering DMA. In the same manner as analog output, the digital pattern can be read from PC RAM or a file on the hard disk.
  • Page 28 That clock can be either internally generated or externally applied. Counter Inputs Four 32-bit counters are built into the DaqBoard/3000 Series boards. Each of the four counters accepts frequency inputs up to 20 MHz. The high-speed counter channels can be configured on a per-channel basis.

  • Page 29: Software

    Multiple DaqBoards per PC The features described for DaqBoard/3000 Series boards can be replicated up to four times, as up to four boards can be installed in a single host PC. The serial number on each board differentiates one from another, and a user-selected name can be assigned to each board for easy recognition within the program.
  • Page 30 CD. The Reader provides a means of reading and printing the PDF documents. Note that hardcopy versions of the manuals can be ordered from the factory. 1-14 Daq Systems and Device Overviews DaqBoard/3000 Series User’s Manual 988093...

  • Page 31: Connections And Pinouts

    DBK215 includes 16 BNC connectors in addition to screw-terminals. Pinouts for both the TB-100 and the DaqBoard/3000 Series boards follow. In addition, use of the optional PDQ30 analog expansion module is discussed, as is the DBK215 should refer to Appendix A.

  • Page 32: Pinout For Daqboard/3000 Series Boards

    Pinout for DaqBoard/3000 Series Boards Pin numbers refer to the 68-pin SCSI female connector, located on the DaqBoard/3000. Function Function Analog input Channel 8 Analog input Channel 0 Analog input Channel 1 Analog Common Analog Common Analog input Channel 9...

  • Page 33: Tb-100 Terminal Connector Option

    TB-100 Terminal Connector Option The TB-100 Terminal Connector option can be used to connect all signal I/O lines that are associated with a DaqBoard/3000 Series device. TB-100 connects to the DaqBoard’s 68-pin SCSI connector via a 68-conductor cable: p/n CA-G55, CA-G56, or CA-G56-6.

  • Page 34: Pdq30 Analog Expansion And Dbk215 Connector Options

    PDQ30 Analog Expansion and DBK215 Connector Options PDQ30 Analog Expansion Module DBK215 16 BNC Connector Module DaqBoard/3000 Series boards can connect to optional devices through either or both of the board’s orb connectors. DaqBoard/3000 Series Connector Layout* Note: DaqBoard/3006 has no HDMI Connector and cannot be connected to a PDQ30.
  • Page 35 DBK215 If you are not using a TB-100 terminal board connection option with your DaqBoard/3000 Series board you can, instead, make use of a DBK215 module. The DBK215 includes: BNC Access to 16 inputs or outputs (on front panel) on-board screw-terminal blocks*...
  • Page 36 System Example A DaqBoard/3000 Series system example which includes both a PDQ30 and a DBK215 is illustrated on page 2-4. For convenience, it has been repeated below. In regard to the PDQ30 aspect: 1) Connection from PDQ30 to DaqBoard/3000 is made via a CA-266-3 (or CA-266-6) HDMI cable.
  • Page 37 PDQ30 Terminal Block Pinouts (TB1 through TB6) PDQ30 can measure 48 channels of voltage or 24 channels of temperature. The temperature measurement requires the use of Differential Mode. Reference Notes: For PDQ30 specifications, refer to chapter 6. DaqBoard/3000 Series User’s Manual Connections & Pinouts 918494...
  • Page 38 Connections & Pinouts DaqBoard/3000 Series User’s Manual 918494...

  • Page 39: Ce-Compliance

    • transient overvoltage according to installation categories (overvoltage categories) I, II and III For mains supply, the minimum and normal category is II • pollution degree I or II in accordance with IEC 664 DaqBoard/3000 Series User’s Manual CE-Compliance 957894...

  • Page 40: Safety Conditions

    The host computer must be properly grounded. • In low-level analog applications, some inaccuracy is to be expected when I/O leads are exposed to RF fields or transients over 3 or 10 V/m as noted on the Declaration of Conformity. CE-Compliance DaqBoard/3000 Series User’s Manual 957894...

  • Page 41: Calibration

    Calibration DaqBoard/3000 Series boards are factory-calibrated. However, if adjustments are needed they should be completed in the following order: Analog Measurement Path, Offset and Gain Voltage Reference DAC0 Offset and Gain * DAC1 Offset and Gain * DAC2 Offset and Gain *...
  • Page 42 Calibration DaqBoard/3000 Series User’s Manual 918494...
  • Page 43 DaqCal User Calibration Utility Contents Overview …… i Equipment …… ii NIST Traceability …… iii Installing DaqCal …… iii Setup …… iii What to Expect when using DaqCal …… v Calibrating Analog Outputs …… vii Calibrating DBK Expansion Options …… viii CAUTION Turn off power to all devices connected to the system before connecting cables or setting configuration jumpers and switches.
  • Page 44 Equipment Refer to the appropriate block below, depending on whether you will be calibrating through a 37-pin, 68-pin, or 100-pin connector. 37-PIN If calibration signals will be passing through a 37-pin P1 connector you will need: Required: 6.5-digit, digital multi-meter adjustable voltage calibrator ambient temperature meter In addition, the following are recommended:...

  • Page 45: Nist Traceability

    DaqCal is installed automatically from your data acquisition CD during software installation of DaqView. The default location of DaqCal.exe is the IOtech DaqX Software Program Group. The DaqX program group can be accessed through the “All Programs” feature in the Miccrosoft Windows Desktop.
  • Page 46 (37-pin) For DB37 P1 applications you can attach a DBK11A to the device via a CA-37 cable. Connecting a DBK11A (100-pin) For 100-pin P4 connector applications you can use a DBK200 (or DBK201), DBK11A, and a CA-195 cable; or you could use a DBK213 and a CA-195 cable. Illustrations of these two scenarios follow.

  • Page 47: What To Expect When Using Daqcal

    After you have completed the setup according to the type of device and appropriate connectivity option, launch DaqCal and follow the on-screen instructions. What to Expect when using DaqCal When DaqCal opens you will be prompted to select your device from a list. After doing so the application will guide you through the calibration process using simple on-screen instructions.
  • Page 48 From the screen’s Calibration List (right-hand figure), select the desired types of calibration. In the example shown we have selected: Channel Offset A/D (Single-Ended) Channel Gain A/D (Single-Ended) After making the selections, click the <Calibrate> button (see preceding figure). Selecting the Desired Calibrations Steps specific to your device will now display.

  • Page 49: Calibrating Analog Outputs

    Calibrating Analog Outputs After launching DaqCal, select the device to be calibrated from the device inventory list. After selecting your device, click the <OK> button. An instruction screen with a Calibration List will display. From the screen’s Calibration List select the desired types of calibration.

  • Page 50: Calibrating Dbk Expansion Options

    Calibrating DBK Expansion Options If the primary data acquisition device (DaqBook, or DaqBoard) is out of its calibration period, calibrate that device prior to calibrating the DBK expansion option. An alternative to using DaqCal is to contact the factory or your service representative to schedule a factory calibration. After launching DaqCal, select the device to be calibrated from the device inventory list.

  • Page 51: Counter Input Modes

    There are 16 different debounce times. In either debounce mode, the debounce time selected determines how fast the signal can change and still be recognized. The two debounce modes are “trigger after stable” and “trigger before stable.” A discussion of the two modes follows. Debounce Model DaqBoard/3000 Series User’s Manual Counter Input Modes 918494...

  • Page 52: Debounce Module

    T1 it is accepted and the Output (of the debounce module) goes high. Note that a period of stability must precede the edge in order for the edge to be accepted. 5-2 Counter Input Modes DaqBoard/3000 Series User’s Manual 918494...
  • Page 53 To see the effects of different debounce time settings, simply view the analog waveform along with the counter output. This can be done by connecting the source to an analog input. DaqBoard/3000 Series User’s Manual Counter Input Modes 918494...
  • Page 54 The debounce time should be set short enough to accept the desired input pulse but longer than the period of the undesired disturbance as shown in the diagram below. 5-4 Counter Input Modes DaqBoard/3000 Series User’s Manual 918494...

  • Page 55: Terms Applicable To Counter Modes

    OPT2: Determines whether the pulsewidth is to be measured with a 16-bit counter (Counter Low); or a 32-bit counter (Counter High). OPT4: Allows the mapped channel to gate the counter. OPT6: Allows the mapped channel to be measured for pulsewidth. DaqBoard/3000 Series User’s Manual Counter Input Modes 918494...

  • Page 56: Counter/Totalize Mode

    The software can read the counter’s high 16-bits at a later time, after reading the lower 16-bits. The full 32-bit result reflects the timing of the first asynchronous read strobe. Counter/Totalize Mode *There is one asynchronous read strobe for each of the four counter channels. 5-6 Counter Input Modes DaqBoard/3000 Series User’s Manual 918494...
  • Page 57 Counter and Encoder modes. However, it is possible for the user to use that read strobe as a mapped channel elsewhere, if desired. For example, the read strobe could be used to increment or decrement the counter. DaqBoard/3000 Series User’s Manual Counter Input Modes 918494...

  • Page 58: Period Mode

    208.3 ns, 2083 ns, and 20833 ns. These are often referred to as tick-sizes. The /3000 Series board uses a 48 MHz, 30 ppm oscillator as a timing source. The tick sizes are derived from 1 period, 10 periods, 100 periods, or 1000 periods of the 48 MHz clock. 5-8 Counter Input Modes DaqBoard/3000 Series User’s Manual 918494...
  • Page 59 (16 bit or 32 bit values.) The frequency ranges are designed to fit a wide array of possible applications. Within each range, the sampling error decreases dramatically as the input period increases. The ranges will get smaller as required accuracy increases. DaqBoard/3000 Series User’s Manual Counter Input Modes 918494...
  • Page 60 15– 50kHz, 1ppm range. The values returned will have sampling error that is greater than 1ppm but they can be averaged by the PC software to further reduce the sampling error. 5-10 Counter Input Modes DaqBoard/3000 Series User’s Manual 918494...

  • Page 61: Pulsewidth Mode

    208.33 ns, 2.083 µs, and 20.83 µs. These are often referred to as tick-sizes. The 3000 Series board uses a 48 MHz, 30 ppm oscillator as a timing source. If the input signal has a poor slew rate the pulsewidth mode will provide variant results. DaqBoard/3000 Series User’s Manual Counter Input Modes 5-11...
  • Page 62 20m – 800 208.333 200m – 800 208.333 2m – 80 20.833 20m – 80 20.833 High Accuracy Pulsewidth and Time Ranges for a 32-bit Value that has little sampling error (<10ppm, <1ppm) 5-12 Counter Input Modes DaqBoard/3000 Series User’s Manual 918494...

  • Page 63: Timing Mode

    Timing Mode *There is one asynchronous read strobe for each of the four counter channels. Note 1: Tick-sizes are: 20.83ns, 208.3ns, 2083ns, and 20833ns, derived from the 48 MHz system clock. DaqBoard/3000 Series User’s Manual Counter Input Modes 5-13 918494...
  • Page 64 32-bit (Counter High) counter. Since time measurements always have the “stop at the top” option enabled, this option dictates whether the measurement has a range of 0 to 65535 ticks or 0 to 4,294,967,295 ticks. 5-14 Counter Input Modes DaqBoard/3000 Series User’s Manual 918494...

  • Page 65: Encoder Mode

    The A and B signals will pulse 512 times (or 1024, 4096, etc.) per complete rotation of the encoder. The concentric pattern for the Z signal has only one transparent window and therefore pulses only once per complete rotation. Representative signals are shown in the following figure. DaqBoard/3000 Series User’s Manual Counter Input Modes 5-15 918494...
  • Page 66 These 3 different modes are known as 1X, 2X, and 4X. The 3000 Series board implements all of these modes and functions, as described in the following options. Encoder Mode *There is one asynchronous read strobe for each of the four counter channels. 5-16 Counter Input Modes DaqBoard/3000 Series User’s Manual 918494...
  • Page 67 Choose a pullup resistor value based on the encoder’s output drive capability and the input impedance of the 3000 Series board. Lower values of pullup resistors will cause less distortion but also cause the encoder’s output driver to pull down with more current. DaqBoard/3000 Series User’s Manual Counter Input Modes 5-17...
  • Page 68 Note that the number of Z-reference crossings can be tabulated. If the encoder was turning in only one direction, then the Z-reference crossings will equal the number of complete revolutions. This means that the data streaming to the PC will be relative position, period = 1/velocity, and revolutions. 5-18 Counter Input Modes DaqBoard/3000 Series User’s Manual 918494...
  • Page 69 A typical acquisition might take 6 readings off of the 3000 Series board module as illustrated below. The user determines the scan rate and the number of scans to take. DaqBoard/3000 Series board Acquisition of Six Readings per Scan Note: Digital channels do not take up analog channel scan time.
  • Page 70 With the encoders connected in this manner there is no relative positioning information available on encoder #1 or #2 since there is no Z signal connection for either. Therefore only distance traveled and velocity can be measured for each encoder. 5-20 Counter Input Modes DaqBoard/3000 Series User’s Manual 918494...

  • Page 71: Setpoint Configuration For Output Control

    “high.” There is no change to the detect signal while within the window. Value A defines the upper limit of the Window and Value B defines the low limit. Using Setpoints to Control Outputs DaqBoard/3000 Series User’s Manual Setpoint Configuration for Output Control 908794...
  • Page 72 Detection setpoints act on 16-bit data only. Since the DaqBoard/3000 Series boards have 32-bit counters, data is returned 16-bits at a time. The lower word, the higher word or both lower and higher words can be part of the scan group.

  • Page 73: Detecting Input Values

    TIP: It is recommended that the “Equal to Limit A” mode only be used with counter or digital input channels as the channel source. If similar functionality is desired for analog channels, then the “Inside Window” mode should be used. DaqBoard/3000 Series User’s Manual Setpoint Configuration for Output Control 907994...

  • Page 74: Controlling Analog, Digital, And Timer Outputs

    PC may not. This is true no matter what mode the counter channel is in. 6-4 Setpoint Configuration for Output Control DaqBoard/3000 Series User’s Manual 908794...
  • Page 75 P2C is to be updated by set point criterion, then you must do an asynchronous write to P2C before the acquisition is started. The initial value will only be output if the asynchronous write to P2C has been performed. DaqBoard/3000 Series User’s Manual Setpoint Configuration for Output Control 908794...

  • Page 76: P2C, Dac, Or Timer Update Latency

    DAC pacer clock. For these reasons, avoid streaming outputs on any DAC or pattern digital output when using setpoints to control DACs. 6-6 Setpoint Configuration for Output Control DaqBoard/3000 Series User’s Manual 908794...

  • Page 77: More Examples Of Control Outputs

    (for Channel 5) DAC1 Detection (for Channel 5) Limit A (for Channel 4) Limit B (for Channel 4) Detection Signal (for Channel 4) Analog Inputs with Setpoints Update on True and False DaqBoard/3000 Series User’s Manual Setpoint Configuration for Output Control 908794...

  • Page 78: Detection On An Analog Input, Timer Output Updates

    (condition False) timer0 will be updated with a second output value. Limit A (for Channel 23) Limit B (for Channel 23) Detection Signal Timer0 Updating a Timer Output Update on True and False 6-8 Setpoint Configuration for Output Control DaqBoard/3000 Series User’s Manual 908794...

  • Page 79: Using The Hysteresis Function

    Hysteresis mode can also be done with P2C digital output port, or a timer output, instead of a DAC. Ch 3 Analog Input Voltage Limit A Limit B Detection DAC0 Channel 3 in Hysterisis Mode DaqBoard/3000 Series User’s Manual Setpoint Configuration for Output Control 908794...

  • Page 80: Using Multiple Inputs To Control One Dac Output

    When both criteria are True at the same time, the DAC2 voltage will be associated with the criteria that has been most recently met. 6-10 Setpoint Configuration for Output Control DaqBoard/3000 Series User’s Manual 908794...

  • Page 81: The Setpoint Status Register

    The Setpoint Status Register Regardless of which software application you are using with a DaqBoard/3000 Series device, a setpoint status register can be used to check the current state of the 16 possible setpoints. In the register, Setpoint 0 is the least significant bit and Setpoint 15 is the most significant bit. Each setpoint is assigned a value of 0 or 1.
  • Page 82 6-12 Setpoint Configuration for Output Control DaqBoard/3000 Series User’s Manual 908794...

  • Page 83: And Pdq30

    Specifications – DaqBoard/3000 Series PDQ30 DaqBoard/3000 Series Specifications I/O Comparison Matrix Product or System Analog Input Input Analog Digital I/O Counter Timer Channels Ranges Output Channels Inputs Outputs Channels DaqBoard/3000 16SE / 8DE DaqBoard/3001 16SE / 8DE DaqBoard/3005 16SE / 8DE...
  • Page 84 Maximum Usable Input Voltage + Common Mode Voltage Ranges Maximum (CMV + V 0.5, 1, 2, 5, 10V 10.5V 0.1, 0.2V 2.1V A/D Specifications Type: Successive approximation Resolution: 16 bit Maximum Sample Rate: 1 MHz Nonlinearity (Integral): ±2 LSB maximum Nonlinearity (Differential): ±1 LSB maximum Input Sequencer Analog, digital and counter inputs can be scanned synchronously based on either an internal programmable...
  • Page 85 External Acquisition Scan Clock Input Maximum rate: 1.0 MHz Clock Signal Range: Logical zero 0V to 0.8V; Logical one 2.4V to 5.0V; protected to ±15V Minimum pulse width: 50 ns high, 50 ns low Triggering Trigger Sources: 6, individually selectable for starting and stopping an acquisition. Stop acquisition can occur on a different channel than start acquisition;...
  • Page 86 Analog Outputs Applicable to DaqBoard/3000 and /3001 only Analog output channels are updated synchronously relative to scanned inputs, and clocked from either an internal onboard clock, or an external clock source. Analog outputs can also be updated asynchronously, independent of any other scanning in the system. Bus mastering DMA provides CPU and system-independent data transfers, ensuring accurate outputs that are irrespective of other system activities.
  • Page 87 Pattern Generation Output Two of the 8-bit ports can be configured for 16-bit pattern generation. The pattern can be updated synchronously with an acquisition at up to 12 MHz. Counters One Counter Channel, Typical Each of the four high-speed, 32-bit counter channels can be configured for counter, period, pulse width, time between edges, or multi-axis quadrature encoder modes.
  • Page 88 Frequency/Pulse Generators One Timer Channel, Typical Channels: 2 x 16-bit Output Waveform: Square wave Output Rate: 1 MHz base rate divided by 1 to 65535 (programmable) High Level Output Voltage: 2.0V minimum @ -1.0 mA, 2.9V minimum @ -400 µA Low Level Output Voltage: 0.4V maximum @ 400 µA Software DaqViewXL/Plus...
  • Page 89 PDQ30 Specifications General Operating Temperature: -30˚ to +70˚C Storage Temperature: -40˚ to +80˚C Power Consumption: 400 mW (max) Warm up: 30 minutes to rated specifications Relative Humidity: 0 to 95%, non-condensing Vibration: MIL STD 810E, category 1 and 10 Communications Connector: 25 pin DSUB Signal I/O Connector: Six removable screw terminal blocks (12 connections each) Dimensions: 269mm W x 92mm D x 45 mm H: (10.6”...
  • Page 90 DaqBoard’s 68-pin connector via a CA-G55, CA-56, or CA-56-6 cable. PDQ30 Analog Input Expansion Module: Adds 48 SE [or 24 DE] channels to a DaqBoard/3000 Series board. Characteristics of the expansion channels are identical to those of the onboard channels. PDQ30 connects to the 3000 Series board via HDMI cable CA-266-3, or CA-266-6.
  • Page 91 RC filter network section of the board. DBK215’s SCSI connector (P5) connects to a second 68-pin SCSI connector on a DaqBoard/500 Series, DaqBoard/1000 Series, or DaqBoard/3000 Series board. Connection is made via a CA-G55, CA-G56, or CA-G56-6 cable. Cable descriptions are provided on page A-2.
  • Page 92 DBK215 Block Diagram * Accessory Kit p/n 1139-0800 includes jumper wires and a screw driver. Note that the 68-pin SCSI (P5) connector typically connects to a SCSI connector via a CA-G55, CA-G56, or CA-G56-6 cable. CA-G55 is a 3-foot long cable. CA-G56 is a 3-foot long shielded cable.
  • Page 93 Connection Tips CAUTION Turn off power to the host PC and externally connected equipment prior to connecting cables or signal lines to DBKs. Electric shock or damage to equipment can result even under low-voltage conditions. Take ESD precautions (packaging, proper handling, grounded wrist strap, etc.) Use care to avoid touching board surfaces and onboard components.
  • Page 94 System Example DBK215 and PDQ30 Connection to a DaqBoard/3000 Series Board Notes regarding the above system example: Any of three 68-conductor SCSI ribbon cables can be used to connect the DBK215 to the board’s SCSI.. CA-G55 is a 3-foot long cable.
  • Page 95 Using the Screw-Terminal Blocks You must remove the DBK215 module’s cover plate to access the screw terminal blocks. This is described in steps 1 and 2 below. 1. Remove the top inward screws from each of the 4 mounting brackets. See following figure. To remove the cover plate you must first remove the top inward screw from each of the...
  • Page 96 In general, the following terminal block-to-signal relationships apply: DBK215 Used for . . . Alternative Terminal Blocks ANALOG INPUT BNC 0 thru 7 TB10 TB11 ANALOG INPUT TB12 DIGITAL I/O TB13** ANALOG INPUT TB9,TB10 TB14** BNC Channels 0 thru 7** TB15 USER (See Note 1)
  • Page 97 Analog I/O Correlation to 68-pin SCSI Also see “Correlation to BNC Terminations (TB13 and TB14) on page DBK215-10.” Pin Number and Description DIFF CH 0 IN (Single-Ended Mode) / CH 0 HI IN (Differential Mode) CH 8 IN (Single-Ended Mode) / CH 0 LO IN (Differential Mode) CH 1 IN (Single-Ended Mode) / CH 1 HI IN (Differential Mode) CH 9 IN (Single-Ended Mode) / CH 1 LO IN (Differential Mode) CH 2 IN (Single-Ended Mode) / CH 2 HI IN (Differential Mode)
  • Page 98 Digital I/O Correlation to 68-pin SCSI Pin Number and Description DGND Digital Ground, Common DGND Digital Ground, Common Digital I/O: Port A, Bit 7 Digital I/O: Port A, Bit 6 Digital I/O: Port A, Bit 5 Digital I/O: Port A, Bit 4 Digital I/O: Port A, Bit 3 Digital I/O: Port A, Bit 2 Digital I/O: Port A, Bit 1...
  • Page 99 Pulse/Frequency Correlation to 68-pin SCSI Pin Number and Description P3 Digital Port Bit 0 P3 Digital Port Bit 1 P3 Digital Port Bit 2 TB1 is NOT USED P3 Digital Port Bit 3 P3 Digital Port Bit 4 P3 Digital Port Bit 5 P3 Digital Port Bit 6 P3 Digital Port Bit 7 DGND...
  • Page 100 Correlation to Analog Input BNC Terminations – BNC 0 through BNC 7 “Virtual” Terminal Blocks TB13 and TB14 for ANALOG INPUT connect to TB9 and TB10 through the printed circuit board. TB13 (“Virtual” Terminal Block) 68-Pin SCSI Connector, Pin Number and Description TB13 does not physically exist on BNC CH DIFF...
  • Page 101 Adding Resistor/Capacitor Filter Networks WARNING Disconnect the DBK215 from power and signal sources prior to installing capacitors or resistors. CAUTION Ensure wire strands do not short power supply connections to any terminal potential. Failure to do so could result in damage to equipment. Do not exceed maximum allowable inputs (as listed in product specifications).
  • Page 102 • Do not use RC filters in conjunction with additional DBK expansion accessories. • Prior to installing a resistor to the filter network you must drill a 1/16” hole through the center pinhole [beneath the board’s silkscreen resistor symbol] as indicated in the preceding figure.
  • Page 103 Specifications for DBK215 Operating Environment: Temperature: -30°C to 70°C Relative Humidity: 95% RH, non-condensing Connectors: P5: 68-Pin SCSI Screw Terminals: 14 banks of 10-connector blocks Wire Size: 12 TO 28 AWG Dimensions: 285 mm W x 220 mm D x 45 mm H (11” x 8.5” x 2.7”) Weight: 1.36 kg (3 lbs) Cables and Accessories:...
  • Page 104 DBK215, pg. A-14 Appendix A 948894...
  • Page 105 Appendix B Hardware Analog Level Trigger An Important Note Regarding Hardware Analog Level Trigger and Comparator Change State Issue: When the starting out analog input voltage is near the trigger level, and you are performing a rising [or falling] hardware analog level trigger, it is possible that the analog level comparator will have already tripped, i.e., to have tripped before the sweep was enabled.
  • Page 106 Hardware Analog Level Trigger Appendix B 90794...
  • Page 107 Glossary Acquisition A collection of scans acquired at a specified rate as controlled by the sequencer. Analog A signal of varying voltage or current that communicates data. Analog-to-Digital A circuit or device that converts analog values into digital values, such as binary bits, for use in digital Converter (ADC) computer processing.
  • Page 108 Differential mode Differential mode voltage refers to a voltage difference between two signals that are referenced to a common voltage point. Example: Signal 1 is +5 VDC referenced to common. Signal 2 is +6 VDC referenced to common. If the +5 VDC signal is used as the reference, the differential mode voltage is +1 VDC (+ 6 VDC - +5 VDC = +1 VDC).
