3300 Ver3(09-04)
Introduction
Thank you for purchasing the EDGE DiskGO! USB Watch Drive. We hope you will enjoy the convenience
and flexibility of having your data stored in an everyday wristwatch! This guide explains how to use the
DiskGO! Watch and the Application Software bundled with your device.
Please read the safety precautions carefully before you begin using the DiskGO! Watch and the
application software. Ensure that you use the product correctly according to the procedures outlined in
this guide.
______________________________________________________________
Warning
______________________________________________________________
Do not attempt to disassemble or alter any part of the product that is not described in this guide.
Do not handle the product or plug and unplug the device if your hands are wet. Doing so runs the
risk of electrical shock.
Do not place the product near to or exposed to direct flame or heat.
Never place the product near equipment generating strong electromagnetic fields. Exposure to
strong magnetic fields may cause malfunctions or corruption of data.
Make sure the plug is dry before you connect the DiskGO! Watch to a computer. This may result in
a short circuit which might damage your DiskGO! Watch and/or computer.
Always hold the USB plug when disconnecting the DiskGO! Watch from your computer. Never
unplug it by only holding the watch or wire as this may damage the DiskGO! Watch.
It is recommended that you frequently clean accumulated residue inside the plug to prolong the
product's life.
Setting the Time
Pull out the crown when the second hand arrives at 12 o'clock position.
Turn the crown in either direction to set hour and minute.
Push the crown to the normal position to start
DiskGO!
This product is backed by a one year limited warranty.
For complete warranty information visit
SAFETY PRECAUTIONS
TM
USB Watch Drive
www.edgetechcorp.com/register.

Advertisement

loading
Need help?

Need help?

Do you have a question about the USB Watch and is the answer not in the manual?

Questions and answers

Related Manuals for Edge USB Watch

Summary of Contents for Edge USB Watch

  • Page 1 This product is backed by a one year limited warranty. Introduction Thank you for purchasing the EDGE DiskGO! USB Watch Drive. We hope you will enjoy the convenience and flexibility of having your data stored in an everyday wristwatch! This guide explains how to use the DiskGO! Watch and the Application Software bundled with your device.

  • Page 2: System Requirements

    Changing the Watch Battery Please follow the procedures outlined below: Unscrew the casing on the back of the watch Unscrew the Circuit Board Assembly (CBA) Lift the CBA as shown in the picture Remove the red insulator and replace the battery. Next, replace the red insulator, screw the CBA back down, and then secure the outer casing.

  • Page 3: Guide To Components

    application software. Mac or PC USB equipped equipped Macintosh computer. Operating System (OS) Windows 98 , Windows Millennium Edition (Windows ME), Windows 2000, Windows XP, Linux 2.4 or higher, Mac OS 8.6 or higher USB Interface 3 MB or more Free Hard Disk Space The software contained on the CD is for Windows based PC’s only.

  • Page 4: Basic Functions

    Plug and Play When you plug the device into the USB port of your computer, you will see a “Removable Disk” icon in the Explorer window. When using the DiskGO! Watch on a Macintosh using OS 9.0 or higher, once you plug the DiskGO! Watch into the USB port, you should see the disk icon on the Desktop.

  • Page 5: Partition Types

    Shortly after clicking stop, you will get a message indicating that you can unplug the device from the USB port of your computer. Warning: When you want to remove the DiskGO! Watch, make sure the LED isn’t flashing. If the LED is flashing, activity is still occurring between your computer and the DiskGO! Watch.
  • Page 6 3. Public Area Plus Security Area Public LUN 0 Area This figure shows the detail operation of single LUN. Security LUN 0 Area Public LUN 1 Area This figure shows the detail operation of multiple LUNs. Function Type 1. Public Area Only 2.
  • Page 7 If you are using Windows 98, you must install the driver before you install the application software. Installing the software: If you are installing the application software for use with Windows XP or 2000, you must first log on to the computer as “administrator”...
  • Page 8 If the “Digital Signature Not Found” message displays during installation, just click the [Yes] button to proceed. Using UMSD.exe Program the First Time: Warning The UMSD Program can only handle one DiskGO! Watch at a time. If you are not planning to use the functions of the UMSD Program, like “Resize”, “Change Password”, or “Log In”, etc., you can insert more than one DiskGO! Watch Drive.
  • Page 9 • By default, the device is not in “Security” mode, so the “Resize” function will be active when you run this software for first time. [UMSD] - Resize: Warning The “Resize” function will erase all the data or files stored in the DiskGO! Watch.
  • Page 10 If you select “Public Area Only”, then click the [OK] button. The “Confirmation” window will pop up. Please make sure you have already backed up any important files or data on the DiskGO! Watch. If you select “Security Area”, you will next see the “Security Area Resize” window pop up. You can drag the scroll bar in the middle of the window to set the size of the “Public Area”...
  • Page 11 password in the “Password Hint” window. This hint will be displayed when you click the “Hint” button in the “Unlock Protect” window. The maximum size of the hint is 32 characters. After you have finished, click the [OK] button. The “Confirmation” window will pop up. Please make sure you have already backed up any important files or data on the DiskGO! Watch.
  • Page 12 Warning When you use the login/logout function with the device, please make sure there are no applications running or documents open that are stored on the device. If so, it will cause data loss or damage. Enter you password in the “Password” area. You can create a password hint using the “Resize”...
  • Page 13 You will have three attempts to input the password. After three attempts you will receive a final error message if you have entered an incorrect password. To begin the process again, you will have to unplug plug the device then reinsert it in order to attempt again. When you login/logout, please make sure you close all the programs or documents stored or connected to the device.
  • Page 14 When you login/logout, ensure you close all the programs or documents stored or connected to the device. If there is an application program running or open document stored on the device, the following message will pop up. In Win2000 and XP, even if you have an “Explorer”...
  • Page 15 Make sure your Windows folder is located on the “C” drive. Only one USB Watch Drive is connected. Make sure the DiskGO! Watch is in “Public Area” mode if the “Security” function is enabled. If you want to make your device a bootable USB HDD, It cannot be set up in the “Security” mode.
  • Page 16 Select the type of the boot up method: USB ZIP or USB HDD. The USB HDD option is only available for Windows 98. If you select “USB HDD”, the computer will open a DOS the DiskGO! Watch. If you select “USB ZIP”, the computer will open a DOS the DiskGO! Watch.
  • Page 17 Windows XP: Make a bootable floppy first. You can insert a floppy into the floppy drive, then click on the icon of 3.5” floppy in the “My Computer” window using the right button of your mouse. Select “Format”. Select the option for a bootable floppy in the format options. Then click on the “Start” button. Make a directory called “XP_Bootable”...
  • Page 18 Error Messages: If this message shows up, one possible reason is your Windows OS installation is not complete. (Please make sure the path \WINDOWS\COMMAND\EBD in Windows 98, \WINDOWS\COMMAND\EBD in Windows ME, or \XP_Bootable in Windows XP exists) If this message shows up, please check to see if the capacity of the “Public Area” is large enough. Notes: Once you finish using the program, you will see different disk properties when you select different disk types.
  • Page 19 DiskGO! Watch as boot device for every computer. Award has changed its BIOS in March 2002. The boot up procedure has been changed. The boot up utility will not work with Award’s new BIOS if you are using the USB ZIP boot up option. If your DiskGO! Watch becomes damaged, you can use this utility to repair the functionality of the device.
  • Page 20 If you selected the “Scan Disk” option, that process will follow the “Low Level Format”. Once the job has finished, a completion message will be shown.
  • Page 21 WITH THE PRODUCT ARE FOR CONVENIENCE ONLY AND ARE NOT INTENDED TO BE ALL-INCLUSIVE. 327 East 14 Street / Ada OK 74820 / (800) 332-6581 / (580) 332-6581 / www.edgetechcorp.com EDGE and DiskGO! are trademarks of EDGE Tech Corp. Trademarked words or logos used herein are property of their respective owners.
