Battery : Li-ion 18650 (Micro USB)
Charging the flashlight:
1. Unscrew the tail cap (A).
2. Plug the Micro USB end into the base of the flashlight. Plug the USB end into a power source such as
a computer, power bank charger, USB wall socket adapter or USB car charger.
3. LED battery indicator light :
4. Disconnect the USB cable when fully charged and screw on tail cap (A) to the base of the flashlight.
Operation :
Full pressing (B)
Half press (B)
When light is on, press (C) to adjust brightness
Press (C) when flashlight Off
Press (C) when light is On
Focus lock :
Turn the Head (D) clockwise
Turn the Head (D) anti clockwise
Main switch (B )
Mode switch (C)
PR52
Charging port
Green LED
Red LED
Dual switch
Focusable
Focus lock /
unlock
Tail cap (A)
Charging Completed
Charging in progress
Light on (100%) ---> Light off
Momentary on
Light on (100%) ---> Light on (50%) ---> Light on (5%)
(the cycle repeats)
Instant strobe. If pressed more than 5 seconds, strobe
remains on. Press again to turn strobe off.
Press Mode switch for more than 3 seconds to activate
Strobe. Strobe remains on until mode switch is pressed
again. The flashlight resets to high output level.
Locks the focus
Unlocks the focus
Head (D)
USER MANUAL
Unscrew tail cap
anti-clockwise
Advertisement
Table of Contents
Related Manuals for GP Design PR52
Summary of Contents for GP Design PR52
- Page 1 PR52 USER MANUAL Tail cap (A) Battery : Li-ion 18650 (Micro USB) Charging port Unscrew tail cap anti-clockwise Charging the flashlight: 1. Unscrew the tail cap (A). 2. Plug the Micro USB end into the base of the flashlight. Plug the USB end into a power source such as a computer, power bank charger, USB wall socket adapter or USB car charger.
- Page 2 Features : - Light modes : 3 – High / medium / low + strobe and momentary-on - Focus / lock : Easy one handed instant focusing with focus lock - Dual Switch for ease of use and operation - Body durable aircraft grade aluminum with hard wearing anodized protective coating - Polarity protection and PWM regulation for accurate light output - Tail-stand and anti-roll - Charge directly using micro USB...
- Page 3 Safety Instructions and Warnings Intended Use of Product Please read the full instructions before operating the product due to the possibility of risk as a result of the high luminosity. This product is to be used as a flashlight as directed by the instructions. Safety Instructions Keep product in safe location away from children.
