Front Panel Illustration

Rev. 00

Front and Rear Panel Illustrations

AUDIO key
SET key
Adjustment keys
SpO sensor input connector
2
AUDIO key-Press for two
minute silence. Press and
hold to permanently mute
audible alert. Press again to
cancel two minute silence or
audible alert mute.
SET key-Use to
between alert limits, pulse
beep volume and
volume.
ADJUSTMENT keys-Use to
adjust selected
value.
SpO sensor input connector-
2
For connection of Novametrix
SuperBright series sensors.
select
alert
option's
Alert Icon (visible only during alert)
SpO High Alert Limit displa
2
SpO Low Alert Limit display
2
Power indicator LED
SpO High Limit display-Upper limit value
2
displayed during normal
Displays " " , "VOL", "BEEP" or "AUTO"
depending upon the function selected by
the key.
SpO Low Limit display-Lower limit value
2
during normal monitoring. Displa
volume setting value, pulse beep value, or
"LMTS" depending upon the function
selected by the key.
Power indicator LED-Lights green when
the Model 509 is powered.
Alert Icon- Flashes red when an alert
condition is detected. This icon is visible
only when indicating an alert.
Model 509 Service Manual
monitoring.
