OBID i-scan HF Installation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
INSTALLATION
ID ISC.ANT1800/700
Type A and B
Version: Reader ID ISC.LRM2500-B
customized (E)
–M00910-8e-ID-B.doc
2012-09-28

Advertisement

Table of Contents
loading

Related Manuals for OBID i-scan HF

Summary of Contents for OBID i-scan HF

  • Page 1 INSTALLATION ID ISC.ANT1800/700 Type A and B Version: Reader ID ISC.LRM2500-B customized (E) –M00910-8e-ID-B.doc 2012-09-28...
  • Page 2 FEIG ELECTRONIC GmbH does not convey any license under its patent rights nor the rights of others. ® ® OBID and OBID i-scan are registered trademarks of FEIG ELECTRONIC GmbH. ® my-d is a registered trademark of Infineon Technologies AG ®...
  • Page 3 ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B General information's regarding this document The sign "" indicates extensions or changes of this manual compared with the former issue. If bits within one byte are filled with "-", these bit spaces are reserved for future extensions or for internal testing- and manufacturing-functions.

  • Page 4: Table Of Contents

    ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B Contents Safety Instructions / Warning - Read before Start-Up ! Maintenance Instruction on transportation and shipping of the antennas Performance Features of the ID ISC.ANT1800/700 Antennas Performance Features of the People Counter ID ISC.ANT1800/700-GPC ..... 10 Available Antenna Types ..................
  • Page 5 ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B 6.4.1 Checking the Noise Level ..................38 6.4.2 Reading a Serial Number ..................40 6.4.3 Testing the performance ..................41 Setting the Alarm Kit ....................43 6.5.1 Reader Setting for Indicator..................44 6.5.2 Programming a Transponder with the AFI Byte ............46 Activating the Automatic Mode................
  • Page 6 ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B Safety Instructions / Warning - Read before Start-Up ! The device may only be used for the intended purpose designed by for the manufacturer. The operation manual should be conveniently kept available at all times for each user.
  • Page 7 ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B Maintenance The antenna ID ISC.ANT1800/700 is a design product with high quality surfaces, and should al- ways be handled with caution. The antenna was designed to work reliably and flawlessly for years without special maintenance.
  • Page 8 ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B Instruction on transportation and shipping of the antennas The packaging of the antennas has been designed to transport antennas vertically standing on a pallet to the site of installation. Attention! The antenna has be transported vertically on the base side on the pallet. A transporting or storing in the false orientation can cause damaging at the antenna.

  • Page 9: Performance Features Of The Id Isc.ant1800/700 Antennas

    ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B Performance Features of the ID ISC.ANT1800/700 Antennas The ID ISC.ANT1800/700-A antenna is a version with integrated Dynamic Antenna Tuning Board ID ISC.DAT , Long Range Reader ID ISC.LRM2500-B, 4-times Multiplexer Module ID ISC.ANT.MUX M4, signal light and buzzer.

  • Page 10: Performance Features Of The People Counter Id Isc.ant1800/700-Gpc

    ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B Performance Features of the People Counter ID ISC.ANT1800/700-GPC The product ID ISC.ANT1800/700-GPC, short form “Gate People Counter” or “GPC”, are made for mounting in the gate antennas ID ISC.ANT1800/700. A Gate People Counter consist of a People Counter board (PC) and one Radar Detector! The product ID ISC.ANT.GPC-E Extension Radar Detector is used to extend the People Counter to a...
  • Page 11 ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B Radar detection zone of a single gate Radar detection zone with two aisles Counter 1 | Counter 2 Cnt. 1 | Cnt. 2 Cnt. 3 | Cnt. 4 | Out | Out Radar detection zone with three aisles Radar detection zone with four aisles Fig.
  • Page 12 ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B The Connection between reader and people counter takes place through the RS485 Interface of the reader, inside the antenna. There is no need of a direct connection from the GPC to the Host. All commands from the Host to the People Counters are embedded in the Pickyback command of the reader.

  • Page 13: Available Antenna Types

    ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B Available Antenna Types The following products are currently available: Antenna Type Description ID ISC.ANT1800/700-A Antenna with Reader, Multiplexer , dynamic tuning board, signal light, buzzer and People Counter Board with one radar detector. Crystal Gate ID ISC.ANT1800/700-B...

  • Page 14: Installation And Wiring

    ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B Installation and Wiring Notes: Before installing the antennas please read 0 Project Notes . The spacing of the antennas in a gate depends on the antenna configuration. If multiple antennas or gates are connected to different readers, a minimum clearance of 8 m must be kept between the antennas or gates.

  • Page 15: Mounting Preparation

    ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B Mounting Preparation For the assembly of the antenna it has to be carefully unpacked and the antenna base to be opened. This is done as described in the following steps: 1. Place the packed antenna on the floor with the top side facing up. Carefully open the box and then remove the antenna.

  • Page 16: Installing The Antenna

    ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B Installing the antenna Dimensions of antenna The overall dimensions of the antenna are shown in Fig. 5 Fig. 5: Antenna outside dimensions All dimensions are in mm with general tolerance according to ISO 2768 m (mean).

  • Page 17: Drilling The Mounting Holes

    ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B Drilling the Mounting Holes If the position of the antennas has been marked or determined, the mounting holes and the holes for the cable entry, can be marked and drilled. The dimensions are shown in Fig. 6: Fig.
  • Page 18 ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B Alternatively the cables can be routed at the sides of the antenna bas like shown in Fig. 7 Fig. 7 Cable routing at the antenna sides FEIG ELECTRONIC GmbH Seite 18 von 71 M00910-8e-ID-B.doc...

  • Page 19: Installing The Antenna Base And Antenna Body

    ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B Installing the Antenna Base and Antenna Body The antenna will be mounted on the floor. Please note, the antenna conductors in the middle of the antenna body have to have the same direction (Fig.

  • Page 20: Typical Antenna Configuration (Gate Antenna With Two Antennas)

    ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B Typical Antenna Configuration (Gate Antenna with two Antennas) The standard configuration of a gate with three-dimensional tag orientation consists of one ID ISC.ANT1800/700-A with reader and multiplexer and one ID ISC.ANT1800/700-B. If a tag moves, at horizontal line, through the gate, it can be read at least once.
  • Page 21 ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B If multiple gates are arranged with short distances (1-8m) between each other, these will mutually interfere with each other. In this case, the readers for the individual gates have to be synchronized and run in one of the automatic modes.
  • Page 22 ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B The minimum distance between the antennas of a gate and antennas of RFID work station or terminals (transmitting frequency 13,56 MHz) should be: Transmitted Minimum Distance output power < 0.5 W 0.5 W-1.0 W 1.1 W –...

  • Page 23: Project Notes People Counter (Gpc)

    ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B Project Notes People Counter (GPC) The radar sensor of the People Counter detect moving objects within the detection area / beam (A1, A2, see Fig. 12) of the radar antenna. The size of the detection area, and hence the sensitivity...
  • Page 24 ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B Sensitivity Low: Medium: High: Very high: JP1+2 open JP1 closed JP2 closed JP1+2 closed 200 – 220 cm Distance A 180 cm 200 cm 240 - 260 cm 120 – 130 cm Distance B 60–70 cm...

  • Page 25: Gate Configuration And Setup Using Antennas

    ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B Gate Configuration and Setup using Antennas Required Components To set up the gate you need the following components: Qty. 1 ID ISC.ANT1800/700-A Crystal Gate (Base) (incl. Qty. 1 ID ISC.NET24V-B Power Supply Unit) Qty. 1 ID ISC. ANT1800/700-B Crystal Gate...

  • Page 26: Configuration Of A Gate Antenna With Multiplexer

    ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B Configuration of a Gate Antenna with Multiplexer Connect the components as shown in Fig. 13. Almost, all cable should be mounted already. Normally, the antenna cable from antenna Type B has to be connected to OUT2 at the multiplexer and the 24V DC power supply to X11 of the terminal board only.
  • Page 27 ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B Fig. 14: Terminal board An overview of the terminal board assignment is given in 0. Annex A Note: A reverse polarity could damage the device or the In-/Outputs. FEIG ELECTRONIC GmbH Seite 27 von 71...
  • Page 28 ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B Find here a possible wire connection between antenna Type A and B At a single gate with 2 antennas a connection between X12 LED 2 of the terminal board in Antenna Type A and X14 LED 3 of the terminal board in Antenna Type B must be installed. Grey wire (+ ) and green wire (-/GND).
  • Page 29 ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B The coax cables have fixed lengths and may not be shortened and therefore need to be tied into small loops (see Fig. 15). Tie all cables as far away from the antenna conductor as possible. The cables must never be allowed to contact the antenna conductor.

  • Page 30: Setting The Multiplexer

    ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B Setting the Multiplexer The jumpers JP11-JP14 should be set (factory setting) as shown. More on setting the ID ISC.ANT.MUX.M4 Multiplexer can be found in the corresponding installation manual (M90700-xde-ID-B). Fig. 17: Jumper positions FEIG ELECTRONIC GmbH Seite 30 von 71 M00910-8e-ID-B.doc...

  • Page 31: Setting The Antenna Tuner

    ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B Setting the Antenna Tuner For checking the settings of the antenna tuner the antenna base has to be opened. For this the two fastening screws (hexagon socket width AF 2,5) have to remove of the antenna base cover. By moving the cover upwards, carefully, remove the cover from the antenna base.

  • Page 32: Interface Connections

    ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B Interface Connections RS 232 The RS232 interface is connected on X3. The transmission parameters can be configured by means of software protocol. Figure 1: RS232 interface pin-outs on X3 Kurzzeichen Description RS232 – (Transmit) RS232 –...

  • Page 33: Lan / Tcp/Ip

    ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B LAN / TCP/IP The Reader has an integrated 10 / 100 Base-T network port for an RJ-45. Connection is made on X1 and has an automatic “Crossover Detection” according to the 1000 Base-T Standard.

  • Page 34: Reader Configuration With Multiplexer

    ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B Reader Configuration with Multiplexer To tune the antennas, open the ISOStart software and read out the current configuration of the Reader: Step Action Note Start ISOStart Software Select „Detect“ Select „Run without change “...
  • Page 35 ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B Step Action Note Select „Expert Mode“ and confirm with OK. Select “Logical View” FEIG ELECTRONIC GmbH Seite 35 von 71 M00910-8e-ID-B.doc...
  • Page 36 ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B Afterwards set the operating power, Transponder Parameters and ISO Host Mode: Step Action Note Select “Configuration” Air Interface: “Output -Power” = 8W „Multiplexer Enable“ „1 Input (Single Mode)“ „No of Output Channels „ (e.g. 2) „Antenna Active Time“...

  • Page 37: Tuning The Gate Antenna

    ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B Tuning the Gate Antenna Before tuning the gate antenna, you must quit the ISOStart software. Then the gate can be tuned as follows: Step Action Note Start “DATuningTool” software Select “Detect Reader...”. In the „Detect Reader“ window select the interface (COM-Port 1, BusAdr.

  • Page 38: Testing The Gate Antenna

    ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B Testing the Gate Antenna After tuning the gate antenna, you can check for proper function using a reader, the ISOStart service software and a Transponder. Here the Noise Level and performance of the gate are tested.
  • Page 39 ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B Step Action Note Activate antenna 2 with command: „Function Unit Commands - Multiplexer“ Parameter: „Channel Select“ „Cascade Level = 1“ „Output Channel of Input 1 = 2“ Confirm with “Send” Repeat Step 3 to 5 for...

  • Page 40: Reading A Serial Number

    ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B Reading a Serial Number Step Action Note Attach a tag to an antenna Use adhesive tape, for example Here to antenna at multip- lexer output 1 Activate antenna 1 with command: „Function Unit Commands - Multiplexer“...

  • Page 41: Testing The Performance

    ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B Testing the performance For testing the performance you must switch the reader to one of the Automatic Modes. See 0 Activating the Automatic Mode A read transponder will be displayed by a blue LED on the reader or by the LED light of the antenna.
  • Page 42 ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B If one or more „holes“ are detected, check the noise values on the Reader (see 0 Checking the Noise Level). The following may result in faulty readings: Antenna improperly installed (orientation, antenna distance, check cabling) The torrid / ring cores are not mounted on the antenna and power cables Metal near the antennas is detuning or interfering with them.

  • Page 43: Setting The Alarm Kit

    ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B Setting the Alarm Kit The solution provided here presumes that the alarm indicator (buzzer) is switched through the digital output 2 /X2 on the ID ISC.LRM2500-B reader and the LED 1 light through output 1 of the Gate People Counter.

  • Page 44: Reader Setting For Indicator

    ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B Reader Setting for Indicator The ISOStart software can be used to set the Reader configuration so that the output 1 X6-1/-2 opens or closes or the outputs of the People Counter closes when a Transponder is read.
  • Page 45 ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B Digital Outputs of People Counter Setting Time: with „Setting Time“ set time of the outputs for alarm duration. (10 means 1 second) (e.g. 10 x 100ms) Set: Output 1 for LED 1 of Antenna 1 to “True”...

  • Page 46: Programming A Transponder With The Afi Byte

    ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B Programming a Transponder with the AFI Byte If the Transponders will remain on the object when leaving the storage location, they must first be disabled. This is generally done by writing to a particular area of the Transponder.

  • Page 47: Activating The Automatic Mode

    ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B To verify, read AFI byte by using the command [0x2B] Get System Information Activating the Automatic Mode The gate has to be used in one of the Automatic Modes (Buffered Read, Notification or Scan Mode) to get a maximum performance. Otherwise the reading performance will be significantly reduced.

  • Page 48: Installation Id Isc.ant.gpc-E

    ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B Installation ID ISC.ANT.GPC-E Content of the ID ISC.ANT.GPC-E 1. 1 piece Radar connection cable 2. 1 piece Radar module 3. 2 piece Jumper 4. 2 piece spilt rivet 3,0mm 5. 1 piece cable-clip Step...
  • Page 49 ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B Set sensitivity of Radar sensor by setting jumper J1 and J2. Sensitivity: JP1+2 open: Low JP1 closed: Middle JP2 closed: High JP1+2 closed: Very high Recommended Sensitivity: High Install Radar module with split rivet...

  • Page 50: Configuration And Test

    ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B Configuration and Test To activate the People Counters the following settings has to be done. Set additional the Jumpers JP10 and J11 of Reader ID ISC.LRM2500-B to configure the RS485 interface. Fig. 23 (see also manual M01111-xde-ID-B , page 54 and 55). The Termination has to be activated via software in the reader configuration.

  • Page 51: Connecting Several People Counter

    ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B Connecting several People Counter When using several People Counters (up to 3), at one reader, have to be on the terminal board with each other in parallel. For the connection you have to use 5 pin shielded, twisted-pair cable.

  • Page 52: Configuration And Test In Iso-Host Or Buffered Read

    ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B Configuration and Test in ISO-Host or Buffered Read Step Action Note Select „Configuration“ Host Interface Set RS485 to “False” „Enable Termination Resistors“ The RS232/485 Settings should be set to: Busaddress=0, Baudrate=38400 baud, Parity = even ,...
  • Page 53 ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B Set by clicking on „Apply“. Test: People Counter Select „Commands“ Select Command - „Get Reader Info“ - Peripheral Devices Confirm with „Send“ Number of Devices should be 1 Select Command „Set People Counter Values“...
  • Page 54 ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B Walk through the gate from both directions. Counter 1 | Counter 2 | Out Select Command „Get People Counter Values“ Confirm with „Send“ Counter values will be displayed. In ISO-Host and Buffered Read the People Counter has to be polled by the Host Application to get the data.

  • Page 55: Configuration And Test In Notification Mode

    ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B Configuration and Test in Notification Mode The following configuration hast o be done: Step Action Note Select „Configuration“ Peripheral Devices/CFG8 Set People Counter and Notify Counter to „True“ Confirm with „Apply“ Operating Mode Select -Notification Mode Confirm with „Apply“...
  • Page 56 ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B A Test could be done with the People Counter Sample. Therefore you will have to set both ports have the same address, at the TCP- Settings. FEIG ELECTRONIC GmbH Seite 56 von 71 M00910-8e-ID-B.doc...

  • Page 57: Using The Trigger Function Of Gate People Counter

    ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B Using the trigger function of Gate People Counter The trigger function could only be used in one of the Automatic Modes. The trigger function works bidirectional, but a 100% safe reading of transponder is only possible form one direction.
  • Page 58 ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B Step Action Note Select „Configuration“ Operating Mode Select -Buffered Read Mode -Notification Mode Confirm with „Apply“ Operating Mode -Trigger enable -Source Input No 2-Trigger Use set to - Start Trigger - Hold Time e.g. 20x100ms =2sec.

  • Page 59: Configure The Reader In Accordance With National Rf Regulations

    ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B Configure the reader in accordance with national RF regulations Configuration of the RFID readers and the maximum transmitting power of the antennas are affected mainly by the country-specific RF regulations. For the entire EU the limits are set forth in the R&TTE Directive and EN 300 330.
  • Page 60 ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B The reader needs to be configured as follows depending on the installation location: Parameter USA / Canada / Europe Air Interface RF-Power: maximum 8 W RF Modulation: Transponder RF Modulation / ISO-MODE / RF Data coding ISO-MODE:...

  • Page 61: Technical Data

    ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B Technical Data Antenna ID ISC.ANT1800/700 Type A and B Mechanical Data Housing UV stabilized ABS and Acrylic Dimensions ( W x H x D ) – Antenna 700 mm x 1798 mm x 71 mm 3 mm –...
  • Page 62 ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B Outputs – 1 Optocoupler 24 V / 30 mA – 1 Optocoupler Reader Synchronization – 3 Relay ( 3 x NO) 24 V / 1 A Inputs – 1 Optocoupler Max. 24 V / 20 mA –...
  • Page 63 ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B Ambient Conditions Temperature range – Operating –25 °C to +50 °C – Storage –25 °C to +70 °C Applicable Standards RF approval – Europe EN 300 330 – USA FCC Part 15 RSS 210...

  • Page 64: People Counter Id Isc.ant1800/700-Gpc And Id Isc.ant.gpc-E

    ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B People Counter ID ISC.ANT1800/700-GPC and ID ISC.ANT.GPC-E Mechanical Data Housing Printed Boards Board Dimensions ( B x H x T ) – People Counter Board 100 mm x 40 mm x 16 mm 1 mm –...

  • Page 65: Approvals

    ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B Approvals As per Section 0 Europe (CE) Antenne ID ISC.ANT1800/700 This RF equipment is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC dated March 99. Equipment Classification according to ETSI EN 300 330 and ETSI EN 301 489: Class 2 The technical data of the ID ISC.LRM2500 Reader built into the ID ISC.ANT1800/700-A an-...

  • Page 66: Usa (Fcc) And Canada (Ic)

    ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B USA (FCC) and Canada (IC) Antenna ID ISC.ANT1800/700 Product name: ID ISC.ANT1800/700 Antenna name: ID ISC.ANT1800/700 Type A and Type B Reader name: ID ISC.LRM2500-B FCC ID: PJMLRM2500 6633A-LRM2500 This device complies with Part 15 of the FCC Rules and with...

  • Page 67: People Counter Id Isc.ant1800/700-Gpc

    ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B People Counter ID ISC.ANT1800/700-GPC FCC : Contains: FCC ID: UXS-IPS154US 6633A-GPC Operation is subject to the following two conditions: Notice for Canada (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.

  • Page 68: Usa And Canada (Ul)

    ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B USA and Canada (UL) The following picture indicates the label position: FEIG ELECTRONIC GmbH Seite 68 von 71 M00910-8e-ID-B.doc...

  • Page 69: Annex A

    ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B Annex A Terminal assignment “Terminal Board” Terminal Acronym Description X1 / LR 24V DC Reader X1 / Pin 1 +24 V DC Reader X1 / Pin 2 GND Reader X2 / I/O 24V DC Input/Output...
  • Page 70 ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B Ground – Power Supply X11 / Pin 2 - / GND X12 / LED2 Connection LED / Alarm light 2. Antenna X12 / Pin 1 + 24 V DC LED2 X12 / Pin 2...

  • Page 71: Internal Wiring

    ® OBID i-scan Installation ID ISC.ANT1800/700-A/-B Internal wiring Terminal Acronym Description X1 / LR 24V DC Reader X1 / Pin 1 X13 +24 V DC Reader (red) X1 / Pin 2 X13 GND Reader (black) X2 / I/O 24V DC Input/Output...

This manual is also suitable for:

Isc.ant1800/700-aIsc.ant1800/700-b
