- Page 1 DM-X10 192 Channel DMX Controller Item ref: 154.091UK User Manual Caution: Please read this manual carefully before operating Damage caused by misuse is not covered by the warranty www.avsl.com 154.091UK User Manual...
-
Page 2: Table Of Contents
Contents Getting started 1.1 What is included………………………………………………………………………………………………………………………………………. 3 1.2 Unpacking instructions……………………………………………………………..………………………………………………………………. 3 1.3 Safety instructions............…………..………………………………………………………………. 3 Introduction 2.1 Features............…………..……………………………………………………………….…………… 3 2.2 General overview..........…………..……………………………………………………………….…………… 4 2.3 Product overview..........…………..……………………………………………………………….…………… 4 2.4 Common terms..........…………..……………………………………………………………….……………… 5 Operating instructions 3.1 Setup 3.1.1 Setting up the System.................…………………………………….……………… 5 3.1.2 Fixture Addressing................……………………………………….………………... -
Page 3: Getting Started
Getting started What is included • DM-X10 controller • DC 9-12V 500mA, 90V~240V Power Adapter • Manual Unpacking Instructions Immediately upon receiving a fixture, carefully unpack the carton, check the contents to ensure that all parts are present, and have been received in good condition. Notify the shipper immediately and retain packing material for inspection if any parts appear damaged from shipping or the carton itself shows signs of mishandling. -
Page 4: General Overview
General Overview The DM-X10 is a universal intelligent lighting controller. It allows the control of 12 fixtures composed of 16 channels each and up to 240 programmable scenes. Six chase banks can contain up to 240 steps composed of the saved scenes and in any order. Programs can be triggered by music, automatically or manually. -
Page 5: Common Terms
Primer on DMX see the “DMX Primer” section in the Appendix of this manual. 3.1.2 Fixture addressing The DM-X10 is programmed to control 16 channels of DMX per fixture, therefore the fixtures you wish to control with the corresponding FIXTURE buttons on the unit, must be spaced 16 channels apart. Binary DIP... -
Page 6: Operation
3.2 Operation 3.2.1 Manual Mode The manual mode allows direct control of all fixtures. You are able to move them and change attributes by using the channel faders. Action 1. Select a FIXTURE button 2. Press the AUTO DEL button repeatedly until the MANUAL LED is lit. 3. -
Page 7: Programming
3.3.2 Create a Scene A scene is a static lighting state. Scenes are stored in banks. There are 30 bank memories on the controller and each bank can hold 8 scene memories. The DM-X10 can save 240 scenes total. Action 1. -
Page 8: Editing A Program
3.3.5 Editing a Program Scenes will need to be modified manually Action: 1. Press and hold the PROGRAM button until the LED blinks 2. Use BANK UP/DOWN buttons to change Program banks if necessary 3. Select the desired fixture via the FIXTURES button 4. -
Page 9: Edit Chase (Copy Bank Into Chase)
3.4.9 Delete all Chase Programs Action: 1. Turn the DM-X10 power OFF 2. Press and hold the BANK DOWN and AUTO/DEL buttons together and switch the power back on 3. All LEDs will blink to confirm Chases have been deleted... -
Page 10: Scene Programming (Steps)
1. Press and hold the PROGRAM and BANK DOWN buttons whilst switching the power off 2. Turn the DM-X10 back on and all Scenes will be deleted Caution: This process is irreversible. All scenes with data will be set to 0. -
Page 11: Playback
1. Press and hold the AUTO/DEL button until the AUTO LED is lit 2. If a CHASE button is not pressed, the DM-X10 will automatically run a BANK program 3. Use BANK UP/DOWN buttons to navigate to the bank which is to be run in Auto mode 4. -
Page 12: Appendix 4.1 Dmx Primer
APPENDIX 4.1 DMX Primer There are 512 channels in a DMX-512 connection. Channels may be assigned in any manner. A fixture capable of receiving DMX 512 will require one or a number of sequential channels. The user must assign a starting address on the fixture that indicates the first channel reserved in the controller. -
Page 13: Dmx Dipswitch Quick Reference Chart
4.3 DMX DIP Switch Quick Reference Chart 154.091UK User Manual... -
Page 14: Technical Specifications
4.4 Technical Specifications Power supply 9-12Vdc, 500mA (adaptor included) Max Operating Temperature 45°C DMX output 3-pin XLRF MIDI input 180° 5-pin DIN Data Pinout Pin 1 (GND), Pin 2 (-), Pin 3 (+) Protocol DMX512 USITT Dimensions 482 x 130 x 70mm Weight 3.5kg This product is classed as Electrical or Electronic equipment and should not be disposed with other household or commercial waste at...
