- Page 1 LT-4100 SYSTEM product sheet LT-4100 SATELLITE COMMUNICATIONS SYSTEM IRIDIUM CERTUS ® designed and built for the demanding and rough environment at sea www.thrane.eu...
- Page 2 Certus 100) is a maritime satellite communication antenna unit. Using a standard coaxial cable, up to 500 product from Lars Thrane A/S. The LT-4100 system meters of separation between the units can be obtained, is designed for the professional market (deep sea,...
- Page 3 INTERFACES CHASSIS GROUND ETHERNET Chassis ground Ethernet LAN (RJ45). ANTENNA connector Connectivity for data, Voice (SIP), service and Coaxial type-N conn (fe- maintenance male). One cable solution supporting power and communication to the antenna AUXILIARY POWER SIM CARD Auxiliary (10-pin) supporting 12 - 24 VDC SIM card behind rubber RS-422, and external ringer...
- Page 4 Coaxial Cable Ø4.9mm (up to 100m) User & Installation Manual P/N: 95-102576 Coaxial Cable Ø10.3mm (up to 500m) Lars Thrane A/S Skovlytoften 33 DK-2840 Holte, Denmark Phone: +45 88 30 10 00 Fax: +45 88 30 10 09 Email: sales@thrane.eu CVR DK-36042443 www.thrane.eu...
