Sawyer 273-25 Manual

About Us

We appreciate your business!
Congratulations on your new SAWYER product. We are proud to
have you as our customer and will strive to provide you with the best
service and reliability in the industry. This product is backed by our
extensive warranty and world-wide service network. To locate your
nearest distributor or service agency, please contact us at the phone
number and address listed on the bottom of each page.
You are in good company!
Sawyer Manufacturing Company is the world leader in the design
and manufacture of pipeline and welding equipment and has been
since 1948. Sawyer equipment has become a standard in the industry
and continues to set the benchmark for quality and durability.
This user operation manual has been made to instruct you for the best
use and operation of your Sawyer product. Your satisfaction with our
products is our main goal. Please read this entire manual carefully,
noting all tips, notes and warnings. Safety always comes first.
Parts Diagram
B
G
A. Hydraulic Relief Valve
B. ENERPAC Hydraulic Pump (526-5)
C. Hydraulic Hose Fitting
D. Plunger
E. Die
F. Pressure Gauge (526-27)
Record the following information for warranty purposes:
Where purchased:________________________________________________
Purchase date:___________________________________________________
Equipment Serial #:_______________________________________________
F
A
H
D
Sawyer Manufacturing Company
7799 S. Regency Dr., Tulsa, OK 74131 USA
P
918.834.2550
sawyermfg.com
V1.2
Guided Bend and
Tensile Tester
For 25/55-Ton Applications
C
!
CAUTION:
Company offers a precise weld qualification
test for tensile strength and guided bend
Operations. The buildup of high pressure
inside the hydraulic guided bend and tensile
testing machine can cause injury to personnel
and damage to equipment. To avoid a rapid
discharge, ensure that all pressure hoses are
connected and secure. When the hydraulic
E
pressure does not increase enough to bend
or break the sample, check the hydraulic fluid
levels and add hydraulic fluid as necessary.
Please refer to ENERPAC manual for
maintenance of ENERPAC pump.
G. Jaw Retainer (525AO-B)
H. Plunger "L" Bolt (A110B-C)
I. (4x) Jaws *not included*
J. (1) Jaws Tensioner *not included*
All products manufactured by or for Sawyer Manufacturing Company are
guaranteed against defects due to faulty workmanship or materials for twelve
months from the date of purchase.
This guarantee is limited to the repair or replacement of any parts found to be
defective, and no other liability–expressed, implied, or contingent–is assumed.
F
918.834.0318
info@sawyermfg.com
Manual
Models 273-25 & 273-55
CAUTION
Sawyer Manufacturing

Warranty

!
