OWNER'S MANUAL
Safety and Reference
LED TV*
* Disclaimer
LG LED TV applies LCD screen with LED backlights.
Please read this manual carefully before operating your set and retain it for
future reference.
*M F L 7 0 2 6 5 9 3 5*
www.lg.com
(2104-REV00)
Copyright © 2021 LG Electronics Inc. All Rights Reserved.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for LG 32/43LM562
Summary of Contents for LG 32/43LM562
- Page 1 Safety and Reference LED TV* * Disclaimer LG LED TV applies LCD screen with LED backlights. Please read this manual carefully before operating your set and retain it for future reference. *M F L 7 0 2 6 5 9 3 5* www.lg.com...
- Page 2 Title Warning! Safety instructions Connections Preparing Troubleshooting - Lifting and moving the TV Specifications - Mounting on the Table - Mounting to the Wall - Open Source Software Notice Information - Antenna/Cable - Licenses - Satellite dish - How to use the ferrite core Regulatory Starting TV...
- Page 3 India region only. (Below sentence is not applicable for above 1920 x 1080 resolution TV models.) ATTENTION: This product is qualified for the BEE Star rating in the ‘Home’ Mode. The Objectives of Star Labeling Program is designed to promote energy efficient products and practices. When the television is initially set up, it is designed to meet the BEE Star Labeling requirements while maintaining optimum picture quality.
- Page 4 Warning! Safety instructions CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER TO QUALIFIED SERVICE PERSONNEL. This symbol is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
- Page 5 • Use only an authorized attachments / accessories approved • Never touch this apparatus or antenna during a lightning by LG Electronics. Otherwise, this may result in fire, electric storm. You may be electrocuted. shock, malfunction, or product damage.
- Page 6 • Batteries - Store the accessories (battery, etc.) in a safe location out of the reach of children. - Do not short circuit, disassemble, or allow the batteries to overheat. Do not dispose of batteries in a fire. Batteries should not be exposed to excessive heat. - Caution: Risk of fire or explosion if the battery is replaced by an incorrect type.
-
Page 7: Lifting And Moving The Tv
2 Preparing Lifting and moving the TV Please note the following advice to prevent the TV from being scratched or damaged and for safe transportation regardless of its type and size. • It is recommended to move the TV in the box or packing material that the TV originally came in. •... -
Page 8: Mounting On The Table
Mounting on the Table 1 Lift and tilt the TV into its upright position on a table. • Leave a 10 cm (minimum) space from the wall for proper ventilation. 2 Connect the power cord to a wall outlet. (Depending on model) WARNING •... -
Page 9: Mounting To The Wall
LG’s wall mount bracket is easy to move with cables connected. When you do not use LG’s wall mount bracket, please use a wall mount bracket where the device is adequately secured to the wall with enough space to allow connectivity to external devices. - Page 10 Wall Mounting Bracket (Depending on model) Make sure to use screws and wall mount bracket that meet the VESA standard. Standard dimensions for the wall mount kits are described in the following table. 32/43LM562* 32/43LM575* Model 32/43LM635* 32/43LM637* VESA (A x B) (mm)
-
Page 11: Satellite Dish
Antenna/Cable Connect the TV to a wall antenna socket with an RF cable (75 Ω). • Use a signal splitter to use more than 2 TVs. • If the image quality is poor, install a signal amplifier properly to improve the image quality. •... - Page 12 Starting TV Turning on the TV You can simply operate the TV functions, using the button. Using button Power On (Press) 1) All running apps will close, and any recording in progress will stop. Power Off (Press and Hold) 2) You can access and adjust the menu by pressing the button when TV is on.
-
Page 13: Registering Magic Remote Control
Inserting the battery (Depending on model) • When the message [Magic Remote battery is low. Please change the battery.] is displayed, replace the battery. To replace batteries, open the battery cover, replace batteries (1.5 V AA) matching the ends to the label inside the compartment, and close the battery cover. •... -
Page 14: Using Remote Control
4 Using Remote Control Using Magic Remote Control (Depending on model) The descriptions in this manual are based on the buttons on the remote control. Please read this manual carefully and use the TV correctly. Microphone Number buttons Enters numbers. Power Turns the T Accesses the [Quick Help]. - Page 15 OK Selects menus or options and search by entering text in the search bar. con rms your input. You can watch TV or LG Channels. Clears on-screen displays and returns to TV viewing. Control buttons Control buttons for media contents.
- Page 16 Connections Connect various external devices to the TV and switch input modes to select an external device. For more information of external device’s connection, refer to the manual provided with each device. HDMI • When connecting the HDMI cable, the product and external devices should be turned off and unplugged. •...
- Page 17 External Available external devices are: Blu-ray player, HD receivers, DVD players, VCRs, audio systems, USB storage devices, PC, gaming devices, and other external devices. Devices • The external device connection may differ from the model. Note • Connect external devices to the TV regardless of the order of the TV port. •...
-
Page 18: Troubleshooting
6 Troubleshooting Cannot control the • Check the remote control sensor on the product and try again. TV with the remote • Check if there is any obstacle between the product and the remote control. control. • Check if the batteries are still working and properly installed ( to , to ). -
Page 19: Speci Cations
7 Speci cations (Depending on country) (Depending on model) Broadcasting Speci cations Digital TV Analogue TV (Depending on Country) (Depending on Country) PAL B/B, PAL B/G, PAL D/K, PAL-I DVB-T/T2 Television system SECAM B/G, SECAM D/K DVB-T/T2/C/S/S2 NTSC-M VHF, UHF Programme coverage VHF, UHF, CATV C-Band... - Page 20 (Australia and New Zealand region only) The use of the 5,150 – 5,350 MHz band is restricted to indoor use only. This restriction exists in the countries Australia (AU) and New Zealand (NZ). (For Wi-Fi/Bluetooth built-in model or Wi-Fi built-in model) “RF Radiation Exposure Statement Environment condition Operating Temperature...
-
Page 21: Open Source Software Notice Information
In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are available for download. LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, shipping, and handling) upon email request to opensource@lge.com. - Page 22 Regulatory WARNING! (STABILITY HAZARD) A television set may fall, causing serious personal injury or death. Many injuries, particularly to children, can be avoided by taking simple precautions such as: - ALWAYS use cabinets or stands or mounting methods recommended by the manufacturer of the television set. - ALWAYS use furniture that can safely support the television set.
- Page 23 5 To locate a nearest collection centre or call for pick-up (limited area only) for disposal of this appliance, please contact Toll Free No. 1800-315- LGE Internal Use Only 9999 / 1800-180-9999 for details. All collection centre and pick up facilities are done by third parties with LG Electronics India Pvt. Ltd. Merely as a facilitator. For more detailed information, please visit : http://www.lg.com/in...
- Page 24 The model and serial number of the product are located on the back and on one side of the product. Record them below in case you ever need service. Model Serial No.
