- Page 1 July 2019 DG559MB04A1A01 Technical reference manual Date: 01. 07. 2019 Version: 201907...
- Page 2 www.dglight.eu DG559 Technical reference manual All of the contents are protected from copying under the provisions of copyright laws. The copyrights belong to DG Light. Any unauthorized copying, alteration, distribution, transmission, performance, display or other use of this material is prohibited. info@dglight.eu www.dglight.eu page 1...
-
Page 3: Table Of Contents
DG559 Technical reference manual Table of Contents Table of Contents ........................2 1. Product description ......................3 2. Technical data........................4 3. Wiring diagram and description ....................5 4. Installation and precautions....................6 5. Commissioning by SILVAIR ....................7 6. Contact ..........................8 info@dglight.eu www.dglight.eu page 2... -
Page 4: Product Description
DG559 Technical reference manual 1. Product description DG559MB04A1A01 is a wireless Bluetooth Mesh® control unit for lighting drivers with 0-10V dimming interface resulting in an easy and smart way to provide Bluetooth Mesh® network capabilities to 0-10V dimmable lights. info@dglight.eu www.dglight.eu... -
Page 5: Technical Data
DG559 Technical reference manual 2. Technical data Voltage range: 90÷264 VAC Supply Input Frequency: 50÷60 Hz No Load power consumption: 580mW@220VAC 50Hz 0-10 V Output Voltage range: 0-10Vdc Max. load current :20mA Ambient temperature, ta: -20...+50°C Max. case temperature, tc: +70 °C Operating conditions Storage temperature: -25...+70 °C Max. -
Page 6: Wiring Diagram And Description
DG559 Technical reference manual 3. Wiring diagram and description Neutral line mains power supply connector Load line mains power supply connector LED1 Bluetooth mesh status LED (see Note 1) RESET To trigger factory reset, please place a magnet near RESET for at least 5 seconds until LED1 will start blinking as unprovisioned according to Note1 0-10V + Positive 0-10V interface output connector... -
Page 7: Installation And Precautions
Connect wires as shown in wiring diagram paragraph and tighten the connector screw. Make sure to connect the input and outputs correctly. Mains input connector is marked with letters L and N. Connect 0-10V dimmable light to 0-10V DG559MB04A1A01 output connectors paying attentions to the correct polarity. Notes: DG559MAB04A1A01 is a built-in class II device. -
Page 8: Commissioning By Silvair
Silvair mobile app, which is used on site to commission the devices with the commissioning plan set up earlier in Silvair web app. It has the basic features for managing a project so it can also be used to perform any fine-tuning or commissioning small projects. -
Page 9: Contact
DG559 Technical reference manual Contact: info@dglight.eu www.dglight.eu +39 011.9040938 Our office: Via Giaveno, 20 10040 - Cumiana (TO) ITALY info@dglight.eu www.dglight.eu page 8...
