Home Accents Holiday Spellcasting Witch 21SV23075 Easy Assembly And Operation Instructions

Before you begin
Scan
for easy
3D instructions
EASY ASSEMBLY AND OPERATION INSTRUCTIONS
21SV23075 Spellcasting Witch
READ AND SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE
IMPORTANT TIPS:
• Ensure that the item's adapter is plugged in at the Function Control Box and in
the wall.
• Ensure that the switch on the function control box is on the desired setting.
• If not functioning properly (ex: Mouth doesn't move, eyes don't light up, body
doesn't move), ensure that cables are connected to their corresponding cable as
shown in the instruction sheet.
• Be sure nothing is blocking movement or caught in moving parts.
• Ensure that the floor or surface that the item sits on is flat and level.
PARTS LIST
A. Base x 1
B. Lower Support Pole x 2
C. Support Pole x 2
D. Upper Support Pole x 1
E. Function Control Box Pole x 1
F. Hip Hoop x 1
G. Shoulder Frame x 1
H. Costume x 1
I. Head x 1
J. Right Arm x 1
K. Right Hand and Book x 1
L. Left Arm x 1
M. Cape x 1
N. Hat and Hair x 1
O. Adapter * x 1
* Power Adapter Spec
Input: 100 - 240VAC 50/60Hz
Output: 5.9V 1.5A
Click
Means It's
Locking Pin
Locked
B
B
FRONT
A
LEFT
BACK
NOTE: Throughout the instructions, Right
and Left are relative to the character.
A
F
K
C
B
RIGHT
A
1 1
.
BEFORE ASSEMBLING, REMOVE ALL THE ABOVE PARTS FROM BOX. IF ANY
PART IS MISSING OR BROKEN, DO NOT ATTEMPT TO ASSEMBLE THE PRODUCT
AND CONTACT SVI CUSTOMER SERVICE FROM 8:30AM TO 5:30PM PST AT
1-855-428-3921, EMAIL CUSTOMERSERVICE@SVIUS.COM, OR CALL THE
HOME DEPOT CUSTOMER SERVICE AT 1-877-527-0313.
• Ensure that the volume is not all the way down.
• Be sure nothing is blocking the sensor.
• If the item still does not work, contact SVI customer service from 8:30am to
5:30pm PST at 1-855-428-3921, email customerservice@svius.com, or call The
Home Depot customer service at 1-877-527-0313.
B
G
L
D
C
C
B
1 2
.
USA/ États-Unis
C D
L
H I
M
N
Plug the adapter into the
Function Control Box.
E
D
C
ADAPTER
2 1
.
1006140736
YOW 1006033374
TM
E
J
O
F
E
2 2
.
1/3
