Home Accents Holiday Headless Horseman Easy Assembly And Operation Instructions

EASY ASSEMBLY AND OPERATION INSTRUCTIONS
5124513 Headless Horseman
Please follow the step by step guide and enjoy your
Headless Horseman!

CARE AND STORAGE INSTRUCTIONS

For best performance operate your item indoors. When not in use, store this product in it's original packing. Keep
away from heat and moisture.

TROUBLE SHOOTING:

• Ensure that the item's adapter is plugged in at the Function Control Box and in the wall.
• Ensure that the switch on the function control box is on the desired setting.
• If not functioning properly, ensure that cables are connected to their corresponding cable as shown in the instruction sheet .
• Be sure nothing is blocking movement or caught in moving parts.
• Ensure that the floor or surface that the item sits on is flat and level.
• Be sure nothing is blocking the sensor.

PARTS LIST

A. Base x1
B. Lower Support Poles x2
C. Back Horse Legs x2
D. Horse Torso Frame x1
E. Horse Head x1
(A fog hose is attached to
inside of Horse Head)
F. Front Horse Legs x2
G. Horse Blanket x1
H. Horse Tail x1
I. Horseman's Pants x1
J. Horseman's Frame x1
K. Horseman's Legs x2
L. Horseman's Boots x2
M. Horseman's Coatx1
(Remove fabric from hook Loop
closures before assembling)
N. Horseman's Right Arm x1
O. Horseman's Left Arm and
Jack O' Lantern Head x1
P. Horseman's Cape x1
Q. Fog Machine Adapter x1
R. Cotter Pins/Cable Ties
(Attached to the D. Horse Torso Frame)
S. Adapter (Included)
Input: 100 - 240VAC 50/60Hz
Output: 5.9V 1.5A
BEFORE ASSEMBLING, REMOVE ALL THE ABOVE PARTS FROM BOX. IF ANY PART IS MISSING, DO NOT ATTEMPT TO ASSEMBLE THE PRODUCT AND CONTACT CUSTOMER
SERVICE FROM 8:30AM TO 5:30PM PST AT 1-877-527-0313.
Right and left are relevant to the
character's sensor position.
Locking Pin
Click
Means It's
Locked
B
B
Right
A
Left
Front
A
G H
N
C
Back
A
1.1
WARNING
This item is not a toy and should be used for decoration only. This item contains small parts that can be a choking
hazard. Keep all plastic and wire parts away from children.
1. Please use the transformer supplied by manufacturer.
2. Please assemble item according to instructions. Connect all wires according to matching color.
3. Children should be supervised by adults. Item should not be grabbed, as it becomes a tipping
hazard. Keep all away from the transformer, as it heats up during operation.
Please view all instructions carefully before assembling. Save this instruction sheet for future reference.
B C
I J
O
P
Note: The 2 rear poles of the (D)
Horse Torso Frame must be assem-
bled to the (C) Back Horse Legs at
the same time before connecting
the (D) Horse Torso Frame to the (B)
Lower Support Pole.
C
1.2
D E
K L
Q
D
E
C C
C C
2.1
USA/ États-Unis 1004189206
Canada 1001122744
YOW 1004126180
TM
F
M
Cotter pins x 2
cable ties x 10
R
R
Cotter pin
2.2
1/4
