Traeger BBQ020LE Owner's Manual

Residential pellet grill-smoker
Hide thumbs

Advertisement

Quick Links

Download this manual
OWNER'S MANUAL
BBQ020LE
RESIDENTIAL PELLET GRILL-SMOKER
FOR OUTDOOR USE ONLY!
"TASTE THE DIFFERENCE"
Please read this entire manual before assembly, installation of your Traeger Pellet Grill. Failure to
follow these instructions could result in property damage, bodily injury or even death. Contact
your local building or fire official about restrictions and installation inspection requirements in
your area.
SAVE THESE INSTRUCTIONS

Advertisement

loading

Related Manuals for Traeger BBQ020LE

Summary of Contents for Traeger BBQ020LE

  • Page 1 FOR OUTDOOR USE ONLY! “TASTE THE DIFFERENCE” Please read this entire manual before assembly, installation of your Traeger Pellet Grill. Failure to follow these instructions could result in property damage, bodily injury or even death. Contact your local building or fire official about restrictions and installation inspection requirements in your area.
  • Page 2 WARNING! Use ONLY TRAEGER BRAND BBQ WOOD PELLETS, which are specifically made to work in our Grills. Traeger wood pellets are rated for 8500 BTU per LBS with an ash content of 2%. CAUTION! Always store wood pellets in a dry location, away from heat-producing appliances and other fuel containers.
  • Page 3 INTRODUCTION Congratulations on your purchase of this Traeger Wood Pellet Grill, Model BBQ020LE. With proper set-up, operation and maintenance, the Grill will provide you with delicious food and years of cooking enjoyment. NOTE: NUMBERS FOLLOWING PART NAMES THROUGHOUT THIS MANUAL REFER TO THE COMPONENT DIAGRAM.

  • Page 4: Section One: Assembly Instructions

    2. Then tighten the bolts till they are snug. Do Not Over Tighten The Bolts. INSTALLING THE DRIP PAN ASSEMBLY AND GRILL: 1. Insert the drip pan assembly (41) onto the inside of the BBQ020LE body and insert into the body cutout.
  • Page 5 DO NOT TOUCH IT! Turn the Switch to off and the Dial Knob to OFF/SHUT DOWN CYCLE. 4) Fill the Pellet Hopper with TRAEGER BBQ PELLETS. WARNING! USE ONLY TRAEGER BRAND BBQ PELLETS, which are specifically made to work in our Grills. NEVER use heating fuel pellets in the Grill.
  • Page 6 Door and set the temperature/Dial to any cooking setting desired. 5) If this procedure is not successful, see Section Six: FREQUENTLY ASKED QUESTIONS for troubleshooting tips or contact Traeger Technical Support (Section Seven) to help diagnose the problem before proceeding to the MANUAL LIGHTING INSTRUCTIONS below.
  • Page 7 3) Remove the Porcelain Grill, Grease Drain Pan and Heat Baffle to expose the Firepot In the bottom of the Grill. 4) Pour 1/2 cup of TRAEGER BBQ PELLETS into the Firepot. 5) Squirt 2 tablespoons of Alcohol Gel fire lighter into the Firepot on top of the Pellets.

  • Page 8: Section Four: Operating Tips

    “hold” foods at approximately 180 to 200 degrees F. 2) WARNING! Your Traeger Pellet Grill should never be moved while it is hot. If you are transporting your Grill in a vehicle after cooking on it, make sure the fire is completely out and the Grill is cold before placing it in any vehicle.
  • Page 9 WARNING! If the fire in the Firepot goes out while smoking, when sufficient Pellets are still in the Pellet Hopper, it is important to follow these steps. Failure to do so may cause a hazardous “over-firing” of your grill due to an excess of unburned pellets in the Firepot. You may need to decrease the “P”...
  • Page 10 Pellet Hopper. Wood pellets, when wet, expand greatly and will jam your Auger. A Traeger Grill Cover to protect the Grill is highly recommended! Covers are available from your Traeger Dealer, or log on to our Web Site –...

  • Page 11: Section Six: Frequently Asked Questions

    If the Auger Drive Motor is operating (check the small fan blade on the back of the motor), the problem is in the Three Speed or Digital Control, which will need to be replaced. Contact your Traeger Dealer or the Traeger Parts Department (SECTION SEVEN) to place an order.
  • Page 12 Switch to the OFF position. This indicates a defective Auger Drive Motor and it will need to be replaced. Contact your Traeger Dealer or the Traeger Parts Department (SECTION SEVEN) to place an order.
  • Page 13 WHERE CAN I GET A NEW PART FOR MY GRILL? Check with your Traeger Dealer. They may have the part in stock or can order the part for you. Or you can contact the Traeger Parts Department (SECTION SEVEN) to place an order.
  • Page 14 Parts are identified in the front of this manual on the COMPONENT DIAGRAM PAGE. To order parts: Call, E-mail or write to your Authorized Traeger Dealer or Traeger Pellet Grills. Please provide your name, phone number, address, Model and Serial Number of the Grill (located on a label inside the Hopper Lid), along with the part identification.
  • Page 15 BBQ020LE COMPONENTS LIST PAGE 1 0F 2...
  • Page 16 BBQ020LE LID COMPONENTS PAGE 2 OF 2...
  • Page 17 BBQ020LE PARTS LIST ITEM# QUANTITY DESCRIPTION PART NUMBER BODY SUB ASSEMBLY SUB441 DOME THERMOMETER 2” BAC256 12” CHROME HANDLE HDW227 TRAEGER NAMEPLATE HDW151 BODY SIDE LEFT BCA598 SCREW 1/4-20 X .375 PPHD ZINC HDW076 WASHER LOCK .250 HDW113 WASHER FLAT .250...
  • Page 18 BBQ020LE WIRING DIAGRAM...
