Summary of Contents for Asus VP239 Series
- Page 1 VP239 Series LCD Monitor User Guide...
-
Page 2: Table Of Contents
Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the product is defaced or missing. -
Page 3: Notices
Notices Federal Communications Commission Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: • This device may not cause harmful interference, and • This device must accept any interference received including interference that may cause undesired operation. -
Page 4: Safety Information
Safety information • Before setting up the monitor, carefully read all the documentation that came with the package. • To prevent fire or shock hazard, never expose the monitor to rain or moisture. • Never try to open the monitor cabinet. The dangerous high voltages inside the monitor may result in serious physical injury. - Page 5 WARNING Usage of other than specified head- or earphones can result in hearing loss due to excessive sound pressures.
-
Page 6: Care & Cleaning
Care & Cleaning • Before you lift or reposition your monitor, it is better to disconnect the cables and power cord. Follow the correct lifting techniques when positioning the monitor. When lifting or carrying the monitor, grasp the edges of the monitor. Do not lift the display by the stand or the cord. • Cleaning. - Page 7 Refer to the following sources for additional information and for product and software updates. ASUS websites The ASUS websites worldwide provide updated information on ASUS hardware and software products. Refer to http://www.asus.com Optional documentation Your product package may include optional documentation that may have been added by your dealer.
-
Page 8: Welcome
® Thank you for purchasing the ASUS LCD monitor! The latest widescreen LCD monitor from ASUS provides a crisper, broader, and brighter display, plus a host of features that enhance your viewing experience. With these features, you can enjoy the convenience and delightful visual... -
Page 9: Assembling The Monitor
CAUTION Assembling the monitor To assemble the monitor: Place the display flat on a cloth on the table, Then attach the base to the arm and fix with the screw to join them tightly. You can easily tighten the screw by fingers. Adjust the monitor to the angle that is most comfortable for you. -5 ~ 20 Chapter 1: Product Introduction... -
Page 10: Connect Cables
Connect cables 1.4.1 Rear of the LCD monitor HDMI VP239N VP239H AC-IN Port HDMI Port DVI Port VGA Port Audio - in Port Kensington Lock ASUS LCD Monitor VP239 Series... -
Page 11: Monitor Introduction
Monitor introduction 1.5.1 Using the Controls button Use the control button on the back of the monitor to adjust the image settings. VP239H VP239N Auto Power Indicator: • The color definition of the power indicator is as the below table. Status Description White... - Page 12 Shortcut key2 • This is a Shortcut key. The default setting is Blue Light Filter. Auto Button • AUTO Adjust.: Automatically adjust the image to its optimized position, clock, and phase. (Only available for VGA input.) ASUS LCD Monitor VP239 Series...
-
Page 13: Quickfit Function
1.5.2 QuickFit Function The QuickFit function contains three patterns: (1) Grid (2) Document (3) Photo size. Grid pattern: Facilitates designers and users to organize content and layout on one page and achieve a consistent look and feel. Alignment Grid 1 Alignment Grid 2 Document: Provides users to view their documents in real size on the screen. -
Page 14: Detaching The Arm/Stand (For Vesa Wall Mount)
Hold the stand of the monitor while removing the screws. • The VESA wall mount kit ( 100 x 100 mm) is purchased separately. • Use only the UL Listed Wall Mount Bracket with minimum weight/load 28.8 kg (Screw size: M4 x 10 mm). ASUS LCD Monitor VP239 Series... -
Page 15: Adjusting The Monitor
Adjusting the monitor • For optimal viewing, we recommend that you look at the full face of the monitor, then adjust the monitor to the angle that is most comfortable for you. • Hold the stand to prevent the monitor from falling when you change its angle. -
Page 16: Osd (On-Screen Display) Menu
or buttons, according to the indicators on the menu, to make your changes. Select the to return to previous menu or to accept and return to previous menu. ASUS LCD Monitor VP239 Series... -
Page 17: Osd Function Introduction
Splendid This function contains eight sub-functions that you can select for your preference. Each mode has the Reset selection, allowing you to maintain your setting or return to the preset mode. ASUS VP239 Splendid Standard Mode VGA 1920x1080@60Hz Scenery Mode... - Page 18 • Between Level 1 to Level 3, the Brightness function is user-configurable. • Level 4 is optimized setting. It is compliance with TUV Low Blue Light Certification. The Brightness function is not user-configurable. ASUS LCD Monitor VP239 Series...
- Page 19 Color Select the image color you like from this function. ASUS VP239 Color Standard Mode VGA 1920x1080@60Hz Brightness Contrast Saturation Color Temp. Skin Tone Smart View • Brightness: The adjusting range is from 0 to 100. • Contrast: The adjusting range is from 0 to 100.
- Page 20 • Sharpness: Adjusts the picture sharpness. The adjusting range is from 0 to 100. • Aspect Control: Adjusts the aspect ratio to “Full”, “4:3”, “Overscan”. • VividPixel: ASUS Exclusive Technology that brings lifelike visuals for crystal-clear and detail-oriented enjoyment. The adjusting range is from 0 to 100.
- Page 21 Select the input source from VGA, DVI, HDMI(only for VP239H) input signal. ASUS VP239 Input Select Standard Mode VGA 1920x1080@60Hz HDMI System Setup Adjusts the system configuration. ASUS VP239 System Setup Standard Mode VGA 1920x1080@60Hz Splendid Demo Mode Volume GamePlus ECO Mode OSD Setup...
- Page 22 GamePlus-Crosshair GamePlus Crosshair Timer (Practice Mode) GamePlus main-Timer GamePlus main-Timer-Position Position • ECO Mode: Activate the ecology mode for power saving. • OSD Setup: Adjusts the OSD Timeout, DDC/CI, and Transparency of the OSD screen. ASUS LCD Monitor VP239 Series...
- Page 23 • Language: Select OSD language. The selections are: English, French, German, Spanish, Italian, Dutch, , Russian, Poland, Czech, Croacia, Hungary, Romania, Portugal, Turkey, Simplified Chinese, Traditional Chinese, Japanese, Korean, Persian, Thai, Indonesian. • Key Lock: Disable all key functions. Pressing the second button on the right for more than five seconds to disable key lock function.
- Page 24 • Shortcut 2: User can select from “Blue Light Filter” “Splendid”, “Brightness”, “Auto Adjust”(only for VP239H), “Contrast”, “Color Temp.”, “Volume”(only for VP239H), “GamePlus”, and set as shortcut key. The default setting is Blue Light Filter. ASUS LCD Monitor VP239 Series...
-
Page 25: Specifications
3.2 Specifications Model VP239H VP239N Panel Size 23.0”W (58.42 cm) Max. Resolution 1920x1080 Brightness (Typ.) 250cd/m Intrinsic Contrast Ratio (Typ.) 1000:1 Viewing Angle (CR>10) 178°(V) /178°(H) Display Colors 16.7 M(6bit+FRC) 5ms (G To G σ) Response Time Satellite Speaker 1.5W x 2 stereo Sound from HDMI HDMI input DVI input... -
Page 26: Troubleshooting (Faq)
• Adjust the volume settings of both your monitor and computer. • Make sure the computer sound card driver is properly installed and activated. • Make sure the audio source is correct on the OSD. ASUS LCD Monitor VP239 Series 3-11... -
Page 27: Supported Timing List
Supported Timing List PC Supported Primary Timing Resolution Refresh Rate Horizontal Frequency 640x480 60Hz 31.469kHz 640x480 72Hz 37.861kHz 640x480 75Hz 37.5kHz 800x600 56Hz 35.156kHz 800x600 60Hz 37.879kHz 800x600 72Hz 48.077kHz 800x600 75Hz 46.875kHz 1024x768 60Hz 48.363kHz 1024x768 70Hz 56.476kHz 1024x768 75Hz 60.023kHz 1152x864... - Page 28 59.94 / 60Hz 67.433 / 67.5kHz * The modes not listed in the above tables may not be supported. For optimal resolution, we recommend that you choose a mode listed in the above tables. ASUS LCD Monitor VP239 Series 3-13...
