- Page 1 WITH DRIVE UNIT - ONE SIDE RAIL RIGHT with drive unit / one side rail right Manual Installation of Pool Enclosure P8 with drive unit, one side rail right l i n e P R E S T I G E...
- Page 2 COVER POSITION COVER POSITION SEGMENT Xs = Xr RAIL POOL Y1 = Y2 l i n e P R E S T I G E 2/19...
- Page 3 RAILS POSITION RAILS POSITION RIGHT POOL l i n e P R E S T I G E 3/19...
-
Page 4: Rail Mounting
RAIL MOUNTING RAIL MOUNTING 6100 8800 Ø4,2mm 6160 8480 8030 Ø8mm PARTS: 8480 - Ø5x60 8800 6100 8030 - Ø8x60 6160 l i n e P R E S T I G E 4/19... - Page 5 JEDNOKOLEJ PRAVÁ - POHON COLLECTING, GUIDING AND ARETATION ELEMENTS COLLECTING, GUIDING AND ARETATION ELEMENTS FIXED FACADE + TILTING SEAL COVER WITH DRIVE UNIT P8 ONE-SIDE RAIL RIGHT - FIXED FACADE + TILTING SEAL 1205 8800 8590 8590 1715 1735 1735...
- Page 6 JEDNOKOLEJ PRAVÁ - POHON COLLECTING, GUIDING AND ARETATION ELEMENTS COLLECTING, GUIDING AND ARETATION ELEMENTS SEMIAUTOMATIC TILTABLE FRONT + DOORS FACADE COVER WITH DRIVE UNIT P8 ONE-SIDE RAIL RIGHT - SEMIAUTOMATIC TILTABLE FRONT + DOORS FACADE 1205 8800 8590 8590 1715...
- Page 7 PLACING THE HOOK PLACING THE HOOK 1045 8590 PARTS: 8590 - Ø6,3x70 1045 l i n e P R E S T I G E 7/19...
- Page 8 1715 PLACING OF COLLECTING AND GUILDING ELEMENT PLACING OF COLLECTING AND GUIDING ELEMENT 1715 SMALL SEGMENT 1715 SEGMENT 8590 1735 (1738) PARTS: 1715 1735 8590 - Ø6,3x70 1738 l i n e P R E S T I G E 8/19...
- Page 9 PLACING OF COLLECTING AND GUIDING ELEMENTS PLACING OF COLLECTING AND OF GUIDING ELEMENTS 1735 (1738) 2x 8590 PARTS: 1735 8590 - Ø6,3x70 1738 l i n e P R E S T I G E 9/19 8/12...
- Page 10 PLACING OF BLIND PLUG OF PROFILE PLACING OF BLIND PLUG OF PROFILE 2x 8020 6830 2x 8465 PARTS: 6830 8020 - Ø6,4x12x1 8465 - Ø3,9x16 l i n e P R E S T I G E 10/19...
- Page 11 PLACING OF COVER PLATE PLACING OF COVER PLATE 6825 PARTS: 6825 l i n e P R E S T I G E 11/19...
- Page 12 PLACING OF STOP ELEMENTS FOR SEGMENTS PLACING OF STOP ELEMENTS FOR SEGMENTS 2x 8800 1205 Ø4,2mm PARTS: 1205 8800 - Ø4,0 x 10 l i n e P R E S T I G E 12/19 11/12...
- Page 13 PLACING OF BLIND PLUG OF RAIL PLACING OF BLIND PLUG OF RAIL 6345 6335 (6325) PARTS: 6325 6335 6345 l i n e P R E S T I G E 13/19 12/12...
- Page 14 PLACING OF COLLECTING ELEMENTS FACADE P8 - SEMIAUTOMATIC TILTABLE FRONT + DOORS FACADE PLACING OF COLLECTING ELEMENTS FACADE SEMIAUTOMATIC TILTABLE FRONT + DOORS FACADE 8810 1860 PARTS: 8810 - Ø4 x 12 1860 l i n e P R E S T I G E...
- Page 15 MONTAGE OF SOLAR PANEL MONTAGE OF SOLAR PANEL 1 YELLOW - YELLOW 2 BLUE - BLUE 3 RED - RED PARTS: 3241 - 2x l i n e P R E S T I G E 15/19...
- Page 16 INSTALLATION OF CONTROL UNIT COVER AND BATTERY COVER INSTALLATION OF CONTROL UNIT COVER AND BATTERY COVER 6645 6650 4x 8505 PARTS: 6650 6645 8505 - Ø4,8 x 19 l i n e P R E S T I G E 16/19...
- Page 17 INSTALLATION OF DRIVE UNIT CLUTCH INSTALLATION OF DRIVE UNIT CLUTCH 3104 2x "KLICK" = OK 3120 PARTS: 3120 3104 l i n e P R E S T I G E 17/19...
- Page 18 MONTAGE OF INDUCTIVE SENZOR SEGMENT WITH DRIVE - SIDE OF BIG FRONT MONTAGE OF INDUCTIVE SENSOR SEGMENT WITH DRIVE - SIDE OF BIG FRONT 3427 (3428) 3435 3435 3-4 mm !! 3433 (3432) PARTS: 3427 3432 3435 3428 3433 l i n e P R E S T I G E 18/19...
- Page 19 MONTAGE OF INDUCTIVE SENZOR SEGMENT WITH DRIVE - SIDE OF SMALL FRONT MONTAGE OF INDUCTIVE SENSOR SEGMENT WITH DRIVE - SIDE OF SMALL FRONT 3437 (3438) 3435 1735 (1715) 2x 8590 3435 3-4 mm !! 3432 (3433) PARTS: 3432 3435 1735 3437 8590 - Ø6,3x70...
