◢MR6121E UHF reader user manual（Ver 1.0）◣
1
MR6121E
UHF Reader User Manual
Shenzhen Marktrace Co., Ltd
Address：
Floor 3/5, Block D,Changyuan New Material Port, No 2 Central 1st Hi-tech Av., Nanshan Shenzhen, P.
R.C.
Post：518057
Phone：0755-2654 6392
FAX：0755-2655 3743
E-mail：technical@marktrace.com
Website：www.marktrace.com
Advertisement
Table of Contents
Related Manuals for Marktrace MR6121E
Summary of Contents for Marktrace MR6121E
- Page 1 ◢MR6121E UHF reader user manual（Ver 1.0）◣ MR6121E UHF Reader User Manual Shenzhen Marktrace Co., Ltd Address： Floor 3/5, Block D,Changyuan New Material Port, No 2 Central 1st Hi-tech Av., Nanshan Shenzhen, P. R.C. Post：518057 Phone：0755-2654 6392 FAX：0755-2655 3743 E-mail：technical@marktrace.com Website：www.marktrace.com...
- Page 2 ◢MR6121E UHF reader user manual（Ver 1.0）◣ Dear Customer： Many thanks for bought Marktrace device. Go through precuts user manual carefully before you operate. To make sure Marktrace device work correct. Any questions, please contact us. We welcome your feedback and comments. Shenzhen Marktrace Co.,Ltd.
- Page 3 Don’t tear up the warranty label or take reader apart to repair by yourself, we reject perform warranty duties if this happened. Shenzhen Marktrace Co.,Ltd have trademark right on the trademark which in this user manual and receive legal protection. DO NOT make free with theses trademarks.
-
Page 4: Table Of Contents
◢MR6121E UHF reader user manual（Ver 1.0）◣ Contents 1 MATTERS NEED ATTENTION..........6 2 READER INSTRUCTION ............ 7 2.1 UHF ..........7 READER INTRODUCTION 2.2 R ............. 7 EADER INSTRUCTION 2.3 R ............ 8 EADER APPLICATIONS 2.4 R ..........8 EADER MAIN FUNCTIONS 2.5 R... - Page 5 ◢MR6121E UHF reader user manual（Ver 1.0）◣ 6.2.1 ISO18000-6B tag Identify ..........26 6.2.2 Multi-tag user data reading ........... 27 6.2.3 Single tag data reading and read with UID ......28 6.2.4 Single tag writing and write with UID ........29 6.2.5 Single tag data lock ..........
-
Page 6: Matters Need Attention
◢MR6121E UHF reader user manual（Ver 1.0）◣ 1 Matters need attention 1、 Dismantle and parts replace：Marktrace has no warranty duties on those faults which caused by dismantle and parts replace by customer .； 2、 Power supply：please use the power adaptor which alone with precuts to get power. -
Page 7: Reader Instruction
◢MR6121E UHF reader user manual（Ver 1.0）◣ 2 Reader instruction 2.1 UHF reader introduction Model Description Parameter Photo Mid-range 9dBi Gain MR6121E integrated antenna reader inside 2.2 Reader instruction This products has the features like multi protocol compatible, multi-tag identify, multi-tag multi area read and write, fast reader speed, can connect to four antennas etc.：... -
Page 8: Reader Applications
◢MR6121E UHF reader user manual（Ver 1.0）◣ 7、 Have RS232、RS485、 Weigand、TCP/IP、Relay etc output interface； 8、 Compatible with tag match function，Reader can identify the tag which match the condition or not identify these condition tags by setting the match conditions.； 10、Compatible with data cache function, Using FRAM (ferroelectric memory) which can save data when power down，memory capacity is 32KBytes，... -
Page 9: Reader Technical Parameter
◢MR6121E UHF reader user manual（Ver 1.0）◣ 2、 Write tag：Can write the same data length in multi-tag’s same area.； 3、 Tag match：Can read match tag or dismatch tag via setting the match conditions； 4、 Make data communicate and change with the connection between standard communication interface and controller or PC,；... -
Page 10: Reader Structure And Interface Explanation
◢MR6121E UHF reader user manual（Ver 1.0）◣ 3 Reader Structure and Interface Explanation 3.1 Reader Structure Explanation 1、 MR6121E integrated reader structure explanation Explanation on the reader communication interface 1. RS232: the Reader provides standard RS232 communication interface as the output port for data modulation. RS232 has 8 data bits format: 1 start bit and 1 stop bit, no parity bit. - Page 11 ◢MR6121E UHF reader user manual（Ver 1.0）◣ 4. RS485：Reader provide RS485 communication interface（10、11 pin） ， work as data main output mode，also can connect with PC via serial port， use RS232-RS485 converter，in this way，RS485 interface support RS232 all supported functions; 5. Programmable output interface ：...
-
Page 12: Quick Start Guide
◢MR6121E UHF reader user manual（Ver 1.0）◣ 4 Quick Start Guide 1、 Connect antenna to reader’s antenna port，connect power adapter to reader and then power on，connect reader to LAN or PC by network cable； 2、 In PC open demo software“MR6100 Demo V1.0”，fill in reader IP address and click“Connect”to connect reader（reader factory default IP address:... - Page 13 ◢MR6121E UHF reader user manual（Ver 1.0）◣ 5, Click “Stop” button to Stop identify operate. Address： Floor 3/5, Block D,Changyuan New Material Port, No 2 Central 1st Hi-tech Av., Nanshan Shenzhen, P. R.C. Post：518057 Phone：0755-2654 6392 FAX：0755-2655 3743 E-mail：technical@marktrace.com Website：www.marktrace.com...
-
Page 14: Reader Parameter Configuration
◢MR6121E UHF reader user manual（Ver 1.0）◣ 5 Reader parameter configuration 5.1 Webpage configuration Reader connect to LAN through TCP/IP port， or directly connect PC， in PC IE browser input reader IP address （ reader factory default IP address: 192.168.1.200） ，after running then open WEB page as below：... - Page 15 ◢MR6121E UHF reader user manual（Ver 1.0）◣ 1） User can configure IP address、 RF power、 frequency、 antenna port、 applied mode、read card indicating etc., 2）Each antenna port RF power can be configurable, range: 0-31dBm； 3）Frequency standard: China Frequency、US Frequency、EU Frequency three type standard hopping frequency selectable；...
- Page 16 ◢MR6121E UHF reader user manual（Ver 1.0）◣ configure between 10-990ms；When in trigger working mod, reading maximum lasting time can be configure as 255s； 2） Read tag type can be 18000-6B or EPC G2， also can be configure read both at same time（expand function）；...
-
Page 17: Demo Software Configuration
◢MR6121E UHF reader user manual（Ver 1.0）◣ ASCII Code Format Hex Format All above configuration will be valid only after click left bottom button“set” button 5.2 Demo software Configuration 5.2.1 Reader connection Click MR6100Demo.exe software, input reader’s IP into the IP input box (Default IP: 192.168.1.200, Port: 100 which is fixed), then click ‘connect’... -
Page 18: Frequency Setting
◢MR6121E UHF reader user manual（Ver 1.0）◣ RF Power on Power setting; Query and set Antenna on Antennas Setting. Take below image for the reference. 2、Set the RF power separately from the range of 0 to 25dBm. 3、On the reader connection, the antenna port will begin self detection, and the connecting Antenna port is on GREEN ICON, Disconnecting Antenna port is on RED ICON. -
Page 19: Buzzer & Led Setting
◢MR6121E UHF reader user manual（Ver 1.0）◣ 2、Favor speed is for single tag or few tags reading with the high speed tag reading rate. Favor Speed working mode is configurated for the applications require high speed tag reading rate (e.g. Not-stop Highway toll) Favor Quantity is for the multi and tense tags reading, Favor Speed working mode is configurated for the applications (e.g. -
Page 20: Gpio Setting
◢MR6121E UHF reader user manual（Ver 1.0）◣ 2、Reader automatically reset when set a new IP address, and need to reconnect the reader with new IP address 5.2.7 GPIO Setting On Setting interface’s Set Out Port menu for the reader output port setting. -
Page 21: Demo Software Demonstration
◢MR6121E UHF reader user manual（Ver 1.0）◣ 6 Demo software demonstration 6.1 EPC Gen2 tag Demonstration 6.1.1 Multi tag Identify 1、On Gen2 EPC Multi Tag interface’s Identify menu for the Multi tag identify, and click Identify ICON to start the reading. EPC code, antenna number and tag reading times displayed on the interface info. -
Page 22: Multi Tag Read & Write
◢MR6121E UHF reader user manual（Ver 1.0）◣ 6.1.2 Multi Tag Read & Write 1、On Gen2 EPC Multi Tag interface’s Multi Tag Read menu for the Multi tag read, Multi tag reader is read tag’s RESERVE Membank, EPC Membank, TID Membank & USER Membank at the same time. The steps are: 1) select the reading Membanks, 2) select the start reading address and the reading word count (EPC tag’s unit is word), and then click ‘Read’... -
Page 23: Tag Filter
◢MR6121E UHF reader user manual（Ver 1.0）◣ Membank, and USER Membank at the same time. The steps are: 1) select the encoding Membank, 2) select the tag start encoding address and the encoding word count (EPC tag’s unit is word), 3) input the encoding value, then click ‘Write’... -
Page 24: Epc Gen2 Tag Lock
◢MR6121E UHF reader user manual（Ver 1.0）◣ with the EPC Gen2 Protocol, RESERVE Membank’s data is invalid for the tag filter rule setting. Please 1) select the EPC tag Membank, 2) the word addr. 3) Word Length, 4) Input the value, then Click ‘Config’ ICON for the Tag filter rule setting. -
Page 25: Epc Gen2 Tag Read And Write With Access Password
◢MR6121E UHF reader user manual（Ver 1.0）◣ 2、EPC Gen2 Tag Lock level are unlock, unlock forever, and secure lock, lock forever 1）Unlock means the tag is not to encrypted the tag 2）Unlock forever means the tag will not be locked forever 3）On Secure Lock, RESERVE Membank only can be read and write with... -
Page 26: Epc Gen2 Tag Kill
◢MR6121E UHF reader user manual（Ver 1.0）◣ Write tag’s Word Addr, and the WordCnt 4、Secure locked Reserve Membank can only be read & write with Access Password, Secure Locked EPC Membank and Secure Locked USER Membank can be encoded with Access Password, while can read without the Access Password. -
Page 27: Multi-Tag User Data Reading
◢MR6121E UHF reader user manual（Ver 1.0）◣ 6.2.2 Multi-tag user data reading Put several 6B tags in the radiation range of antenna，in the ISO 6B operation interface，choose Multi Tag Read to enter into multi-tag data reading interface ， choose the start address of data that you want to read,then click“Read”button to operate multi-tag data reading，... -
Page 28: Single Tag Data Reading And Read With Uid
◢MR6121E UHF reader user manual（Ver 1.0）◣ 6.2.3 Single tag data reading and read with UID 1、In the ISO 6B operation interface，choose Single Tag to enter into single tag operation interface，choose the start address of data you want to read in the ISO Read menu item，click“Read”button to start reading data，the... -
Page 29: Single Tag Writing And Write With Uid
◢MR6121E UHF reader user manual（Ver 1.0）◣ 6.2.4 Single tag writing and write with UID 1、 Single Tag operation interface， choose the data address you want to write in the ISO Write menu item，click“Write”button to write data； 2、 When operate writing data with UID， except for inputting the single byte data that needs to write，it also needs to put the UID number of tag，choose the... - Page 30 ◢MR6121E UHF reader user manual（Ver 1.0）◣ return query result in “Result” column，like“Had locked”and“Not lock”； Address： Floor 3/5, Block D,Changyuan New Material Port, No 2 Central 1st Hi-tech Av., Nanshan Shenzhen, P. R.C. Post：518057 Phone：0755-2654 6392 FAX：0755-2655 3743 E-mail：technical@marktrace.com Website：www.marktrace.com...
-
Page 31: Reader Struction And Installation Sketch Map
◢MR6121E UHF reader user manual（Ver 1.0）◣ 7 Reader struction and installation sketch map 1、MR6121E integrated reader installation sketch map： Address： Floor 3/5, Block D,Changyuan New Material Port, No 2 Central 1st Hi-tech Av., Nanshan Shenzhen, P. R.C. Post：518057 Phone：0755-2654 6392 FAX：0755-2655 3743... -
Page 32: Secondary Development
◢MR6121E UHF reader user manual（Ver 1.0）◣ 8 Secondary development User can make secondary development for reader application software if needing. We provide SDK，which supports VC++、C#、JAVA and so on，the use of SDK,please refer to《MR6100 serial reader SDK instruction》 。 Address： Floor 3/5, Block D,Changyuan New Material Port, No 2 Central 1st Hi-tech Av., Nanshan Shenzhen, P. -
Page 33: Common Faults And Exclusion Methods
◢MR6121E UHF reader user manual（Ver 1.0）◣ 9 Common faults and exclusion methods Failure Description Simple exclusion methods ■make sure the power adapter indicator light is on Unable to start reader ■make sure the reader power interface is connected well Unable connect ■make sure the reader IP address is correct...
