COMPONENTS – ALB FILTER® DUO
5
6
7
8
9
8
1
2
S/N 0000001 3
4
Active
Alb
®
f i l t e r
Alb 2
®
f i l t e r
10
Made in Germany
Made in Germany
11
12
13
14
15
1. Upper cap
2. Sealing ring (top)
3. Threaded screw connection (upper sealing cap)
4. Filter body with internal thread on top and bottom
5. Threaded connection with ripped union nut and head
seal for water filter fittings with standard connection
M22 x 1 female thread
6. Switching lever: Unfiltered water / filtered water
7. Aerator thread (external thread: M22 x 1)
8. Aerator with head seal (unfiltered water)
9. Inlet bridge for filter housing with 4 mm allen hollow
screw and sealing ring.
10. Threaded screw connection (lower sealing cap)
11. Sealing ring (bottom)
12. Lower cap with faucet aerator thread
13. Wrench width 24 mm for open-end wrench
14. Aerator thread (external thread: M22 x 1)
15. Aerator with head seal (filtered water)
