Sony PCG-Z1WAMP1 VAIO User Guide (primary manual) User Manual page 158

Turning the Keyboard
7.
Touch a metal object (such as the connector panel on the back of your computer) to discharge static electricity.
Avoid touching any part of the motherboard or other components inside the computer.
8.
Remove the memory module by pulling out the tabs (see arrows No. 1), and pulling out the module in the
direction of arrow No. 2. See
Rem ov ing a Mem ory Module
To install a memory module
1.
Remove the new memory module from its packaging, and install the memory module by sliding it into the open
slot at a 45-degree angle. See
Installing a New Mem ory Module
2. Push the module down until it snaps into place.
3.
When the module is correctly seated, gently flip the keyboard back over the computer, making sure the keyboard
is also correctly seated.
4. Replace the fastening screws on the bottom of the computer.
To install a memory module
To remove a memory module.
for more information.
Page 158
