- Page 1 Ins-30001 Net2 485 TCP/IP Ethernet interface (Rev4) Page 1...
- Page 2 Monday - Friday from 07:00 - 19:00 (GMT) Saturday from 09:00 - 13:00 (GMT) Documentation on all Paxton products can be found on our website - http://www.paxton.co.uk/ The data line must be wired in a single daisy chain. The data converter may be located anywhere along the data line.
- Page 3 Fitting Switchable 120 ohm resistors Keypad 2 Reader 2 Net2 classic Reset to http://paxton.info/107 DHCP mode PLACE SERIAL NUMBER 123456 LABEL HERE 0889 Screen or spare cores from network cable White/Green Green White/O rang e Orang e To next ACU...
- Page 4 When connecting to a LAN The IP address should be assigned a fixed value, or should be given a DHCP reservation. Unreserved IP addresses issued by DHCP servers are not guaranteed to be constant, leading to potential failure of communication between Net2 software and the device. Run the Net2 Server Configuration Utility (Start/Programs/Net2) and Click on TCP/IP nodes.
- Page 5 If the MAC address does not appear when you click;Detect, ensure that the following ports are open on all devices between this unit and the Net2 PC:- 9999 10001 30718 If you still cannot detect the MAC address of the device, call our Technical Support Help line. Connecting to a WAN or different subnet mask If you are connecting this device to a remote subnet which is different from the Net2 software PC, the standard detect mechanism cannot work across the network routers between them.
- Page 6 Technical Help 1 - Cannot detect ACU via a TCP/IP interface. Q1. The TCP/IP interface must be listed in the Net2 Server Configuration Utility, and responds when PINGed from the utility. We recommend that a static IP address is used. Q2.
- Page 7 Here is the list of topics about this product that receive the most technical support enquiries. We list them here to help you speed up the installation and trouble shooting process. 5 - TCP/IP communication over a WAN. QWe need to establish two-way communications between a PC on site A and a QNet2 485 TCP/IP Ethernet interface on Site B.
- Page 8 Cable tie The declaration of conformity is available on request. Contact details are provided at: http://paxton.info/596 © Paxton Access Ltd 2013 11/04/2013 This product is not suitable for retail sale. All warranties are invalid if this product is not installed by a competent person.
