- Page 1 Science for healthy air. CALISTAIR C300 QUICK START GUIDE Invented in France Made in Germany www.calistair-C300.com Email: kontakt@calistair.com...
-
Page 2: Safety Instructions
• Improper use can damage the device and cause personal injury. • Operate the device only for the intended purpose and under the permissible conditions. All representations and pictures, © Calistair, September 2020... -
Page 3: Product Overview
1.1. YOUR PERSONAL AIR DECONTAMINATION PLANT Congratulations! With the Calistair C300 you have purchased a high-performance system that uses the innovative Calistair Technology to destroy microorganisms, gases and volatile organic compounds. It is able to clean your room air of almost all air pollutants and thus make a considerable contribution to your general well-being. -
Page 4: System Components
1.3. SYSTEM COMPONENTS Air outlet grid Adjustment wheel Power switch Housing High-performance filter (HEPA filter) Filter drawer UVC fluorescent tubes Housing cover Reactor honeycomb plates Rear air intake Lateral air intake Fixed castors Power connection Prefilter insert... -
Page 5: Indoor Air Quality
1.4. INDOOR AIR QUALITY Air quality is an essential factor for general well-being and can have a major impact on health, power of concentration and performance. An air purifier can significantly improve indoor air quality, but should not be the only measure to do so. In principle, the following additional measures are recommended to improve air quality: •... - Page 6 2. COMMISSIONING 2.1. USE Before commissioning, make sure that the device is completely assembled and free of damage. A. Place device at a suitable location. B. Connect power cable to device (Fig. 1). C. Connect power plug to a grounded socket. D.
-
Page 7: Cleaning The Device
3. MAINTENANCE 3.1. CLEANING THE DEVICE Only clean the outside of the device if necessary. Observe the following instructions for external cleaning: • Switch off the device and unplug the power plug from the socket. • Only use a dry or minimally moistened cloth. •... - Page 8 3.3. CHANGE PREFILTER A. Switch off device. B. Pull power plug. C. Loosen screws on the housing cover with suitable tool. D. Remove housing cover (Fig. 1). E. Pull the prefilter insert out of the mounting on the underside of the housing (Fig. 2). Fig.
- Page 9 3.4. CHANGE HIGH- PERFORMANCE FILTER A. Switch off device. B. Pull power plug. C. Loosen screws on the housing cover with suitable tool. D. Remove housing cover (Fig. 1). E. Pull the filter drawer forward on the metal tab up to the stop (Fig. 2). Fig.
- Page 10 3.5. CHANGE UVC FLUORESCENT TUBES A. Switch off device. B. Pull power plug. C. Let device cool down for at least 30 minutes. D. Loosen screws on the housing cover with suitable tool. E. Remove housing cover (Fig. 1). Fig. 1 F.
- Page 11 G. Hold fluorescent tube with one hand. H. With the other hand, press the red button on the lamp socket completely until the UVC fluorescent tube can be easily removed upwards. I. Remove all fluorescent tubes in this way (Fig. 3). J.
- Page 12 Science for healthy air.
